Manufacturer Part Number:

AD8312ACBZ-P7

OneIC Part Number:

1-AD8312ACBZ-P7

Manufacturer:

analog devices

Description:

SP Amp LOG Amp Single 5.5V 6-Pin WLCSP T/R

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Package	6WLCSP
Type	Logarithmic Amplifier
Number of Channels per Chip	1
Power Supply Type	Single
Minimum Single Supply Voltage	2.7 V
Maximum Single Supply Voltage	5.5 V
Mounting	Surface Mount
Operating Temperature	-40 to 85 °C
Standard Package	Cut Tape
Supplier Package	WLCSP
Standard Package Name	BGA
Typical Single Supply Voltage	3
EU RoHS	Compliant
Maximum Operating Temperature	85
Minimum Single Supply Voltage	2.7
Maximum Single Supply Voltage	5.5
Rail to Rail	No
Packaging	Tape and Reel
Number of Elements per Chip	1
Maximum Power Dissipation	200
Maximum Input Resistance	0.013@3V
Minimum Operating Temperature	-40
Pin Count	6
Maximum Input Bias Current	75@3V
Accuracy	±1dB
RF Type	Cellular, GSM, CDMA, W-CDMA
Input Range	-45dBm ~ 0dBm
Current - Supply	5.7mA
Voltage - Supply	2.7 V ~ 5.5 V
Frequency	50MHz ~ 3.5GHz
Package/Case	6-UFBGA, CSPBGA
rohs	Lead free / RoHS Compliant
Other Names	AD8312ACBZ-P7CT
Operating Supply Voltage	3 V
Mounting Style	SMD/SMT
Product	Power Amplifiers
Input Voltage Range - Max	224 mV
Available Set Gain	10 dB
Series	AD8312
Operating Temperature Range	- 40 C to + 85 C
Power Dissipation	200 mW
Bandwidth	3.5 GHz
Number of Channels	1 Channel
Package / Case	WLCSP-6
Factory Pack Quantity	3000
Supply Current	4.2 mA
RoHS	RoHS Compliant
Operating Temp Range	-40C to 85C
Package Type	WLCSP
Number of Elements	1
Operating Temperature Classification	Industrial
Input Resistance	0.013 MOhm
Dual Supply Voltage (Typ)	Not Required V
Input Bias Current	75000 nA
Power Supply Requirement	Single
Dual Supply Voltage (Min)	Not Required V
Rail/Rail I/O Type	No
Rad Hardened	No
Single Supply Voltage (Min)	2.7 V
Single Supply Voltage (Max)	5.5 V
Single Supply Voltage (Typ)	3 V
Dual Supply Voltage (Max)	Not Required V
Frequency Min	:50MHz
Frequency Max	:3.5GHz
Input Power Min	:-45dBm
Input Power Max	:0dBm
Sensitivity	:0.0073dB/°C
RF IC Case Style	:WLCSP
No. of Pins	:6
Input Current	:4.2mA
Weight (kg)	0
Tariff No.	85423990

Documents & Media

RESOURCE TYPE	LINK
Datasheets	AD8312
