texas instruments
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
| Type | Description |
|---|---|
| Product Category | RFID Transponders |
| RoHS | RoHS Compliant |
| Memory Size | 2 kbit |
| Operating Temperature Range | - 25 C to + 70 C |
| Mounting Style | SMD/SMT |
| Package / Case | RFIDN-0 |
| Frequency | 13.56 MHz |
| Function | Read/Write |
| Maximum Operating Temperature | + 70 C |
| Minimum Operating Temperature | - 25 C |
| Factory Pack Quantity | 5000 |
| Features | ISO15693, ISO18000-3, 2kbits |
| Supplier Device Package | 0-RFIDN |
| RF Type | Read / Write |
| Packaging | Tape & Reel (TR) |
| Standard Package | 5,000 |
| Package/Case | 24.2mm Dia |
| rohs | Lead free / RoHS Compliant |
| Other Names | 481-1095-1 |
| Series | RI-I16-112A-03 |
| Rad Hardened | No |
| Product Length (mm) | 24.2 mm |
| Product Depth (mm) | 24.2 mm |
| Tag Type | :Inlay - Circular |
| Module Interface | :(Not Available) |
| SVHC | :No SVHC (20-Jun-2013) |
| Accessory Type | :RFID Transponder |
| Frequency Range | :13.56MHz |
| Weight (kg) | 0.02 |
| Tariff No. | 85423190 |
| Status | ACTIVE |
| Temp (oC) | -25 to 70 |
| Package | Pins | RFIDN (TFC) | 0 |
| Package QTY | Carrier | 5000 |
| Data Rate Downlink (kbits/s) | |
| Minimum Antenna Input Voltage @ ftx (Volts) | |
| Anticollision | Yes |
| Storage Temperature (°C) | -40 to 85 |
| Programming Cycles | 100000 |
| Dimensions (mm) | 24.2 |
| User programmable Memory (bits) | 2048 |
| Package Group | RFIDN |
| Standard | ISO 15693 ISO 18000-3 |
| Modulation Technique | |
| Case Material | |
| Die Processing | |
| Operating Temperature Range (°C) | -20 to 70 |
| Security Features | ECC Compatible Factory Memory Lock User Memory Lock |
| Package | Inlay |
| Protection Class | |
| Recommended Operating Enviroment | Paper laminated PVC laminated |
| Transmission Principle | ASK FSK |
| Datasheet | SCBS826B |
| Write Time (ms) | |
| Read Time (ms) | |
| Chip Thickness (micrometers) | |
| Output Impedance | |
| Factory Programmed Read Only Number (bits) | 64 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets | RI-I116-112A-03 |
