Fluke
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
| Type | Description |
|---|---|
| Specifications | Measures AC Current to 400A, Banana Interface |
| Standard Package | 1 |
| Type | Current Clamp, Probe (Add On) |
| Ratings | CAT III 1000V, CAT IV 600V |
| Absolute Maximum AC Current Measurement | 1000A ac |
| Best AC Current Accuracy | ±2% + 0.15 A |
| Clamp Meter Type | Current |
| Dimensions | 150 x 70 x 30mm |
| Functions Measured | AC Current |
| Height | 30mm |
| Length | 150mm |
| Maximum Conductor Size | 32mm |
| Maximum Operating Temperature | +50°C |
| Minimum Operating Temperature | 0°C |
| Safety Category | CAT III 1000 V, CAT IV 600 V |
| Safety Category Level | CAT III, CAT IV |
| Safety Category Voltage | 1000 V, 600 V |
| Weight | 114g |
| Width | 70mm |
| rohs | Not Applicable |
| Factory Pack Quantity | 1 |
| Display Type | AC Current Clamp |
| Product Category | Clamp Multimeters & Accessories |
| Part # Aliases | 2277225 |
| Accuracy | +/- 2 % |
| RoHS | RoHS Compliant By Exemption |
| Standard Pack: | 1 |
| CableOuterDiameter | 1.25in. |
| ConductorSize | 750MCM(Max.) |
| Current,Rating | 400A(Nom.) |
| Voltage,Rating | 1000VAC(RMS) |
| Brand Name | Fluke |
| Accessory Type | Current Clamp |
| For Use With | Scopemeter, Power Quality Meter, Digital Multimeter, Clamp Meter |
| Frequency range | 45 Hz...3 kHz |
| Description | AC current clamp 400 A |
| Safety to EN61010-2 | CAT III 1000 V |
| Max conductor ø | 32 |
| Output cable | 1.5 m, banana plug |
| Output level | 1 mA/A |
| Measuring error, AC ampere | 2% +0.15 A |
| Measurement range, AC ampere | 5...400 AAC |
| 最佳交流电流精确度 | ±2% +0.15 A |
| 最高工作温度 | +50°C |
| 安全类别 | CAT III 1000 V, CAT IV 600 V |
| 功能测量 | 交流电流 |
| 安全类别等级 | CAT III， CAT IV |
| 高度 | 30mm |
| 最低工作温度 | 0°C |
| 绝对最大交流电流测量 | 400A 交流 |
| 宽度 | 70mm |
| 型号 | I400 |
| 最大导体尺寸 | 32mm |
| 长度 | 150mm |
| 安全类别电压 | 600 V, 1000 V |
| 尺寸 | 150 x 70 x 30mm |
| 重量 | 114g |
| 钳形表类型 | 电流 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets | I400 Instruction Sheet |
| Datasheets | Test Tool Catalog |
