Manufacturer Part Number:

IRAM136-1060A

OneIC Part Number:

176-IRAM136-1060A

Manufacturer:

International Rectifier

Description:

Motor / Motion / Ignition Controllers & Drivers 10A 600V ING PWR HYBRID IC

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
RoHS	RoHS Compliant
Mounting Style	Through Hole
Package / Case	SIP-29
Packaging	Tube
Standard Package Name	SIP
EU RoHS	Not Compliant
Maximum Operating Temperature	125
Package Height	5.5
Mounting	Through Hole
PCB	29
Package Width	26.5
Supplier Package	SIP
Package Length	44
Minimum Operating Temperature	-40
Pin Count	29
Lead Shape	Through Hole
Type	IGBT
Current	10A
Voltage	600V
Standard Package	110
Configuration	3 Phase
Voltage - Isolation	2000Vrms
rohs	Lead free / RoHS Compliant
Application	Advanced Appliance Motor Driver
Dimensions	44 x 26.5 x 5.5mm
Height	5.5mm
Inverter Power Rating	25W
Length	44mm
Maximum Collector Emitter Voltage	600 V
Maximum IGBT Collector Current	10A
Maximum Isolation Rating	2000Vrms
Maximum Operating Supply Voltage	600 V
Maximum Operating Temperature	+100 °C
Minimum Operating Supply Voltage	-0.3 V
Minimum Operating Temperature	-20 °C
Mounting Type	Surface Mount
Package Type	SIP-5
Typical Switching Frequency	20kHz
Width	26.5mm
