Manufacturer Part Number:

CAT16-270J4LF

OneIC Part Number:

18-CAT16-270J4LF

Manufacturer:

bourns

Description:

Res Thick Film Array 27 Ohm 5% ISOL Molded 8-Pin 1206 Concave SMD Paper T/R

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Package Type	SMD
Number of Resistors	4
Number of Terminals	8
Type	Array
Circuit Designator	ISOL
Technology	Thick Film
Operating Temperature	-55 to 125 °C
Resistance Value	27 Ohm
Standard Package	Tape & Reel
Resistance Value	27
EU RoHS	Compliant
Power Rating per Resistor	0.063 (1/16)
Product Depth	1.55
Tolerance	5%
Termination Style	Concave
Product Length	3.2
Product Height	0.5
Packaging	Paper Tape and Reel
Mounting	Surface Mount
Case Style	Molded
Terminal Pitch	0.8
Package/Case	1206(4 X 0603)
Resistance (Ohms)	27
Power Per Element	62.5mW
Mounting Type	Surface Mount
Circuit Type	Isolated
Supplier Device Package	1206
Height	0.024" (0.60mm)
Size / Dimension	0.126" L x 0.061" W (3.20mm x 1.55mm)
Number of Pins	8
rohs	Lead free / RoHS Compliant
Other Names	CAT16-270J4LFCT
Depth	1.6mm
Dimensions	3.2 x 1.6 x 0.5mm
Length	3.2mm
Maximum Operating Temperature	+125°C
Minimum Operating Temperature	-55°C
Power Rating per Resistor	62mW
Resistance	27Ω
Resistor Values	27 Ohms
Factory Pack Quantity	5000
Product Category	Resistor Networks & Arrays
Operating Temperature Range	- 55 C to + 125 C
Series	CAT/CAY 16
Temperature Coefficient	200 PPM / C
Case Length	3.2 mm
Case Height	0.5 mm
Case Width	1.6 mm
Product Type	Arrays
RoHS	RoHS Compliant By Exemption
Power Rating per Element	:62mW
Voltage Rating	:50V
No. of Elements	:4
Resistor Case Style	:1206 [3216 Metric]
Resistance Tolerance	:± 5%
MSL	:-
SVHC	:No SVHC (16-Dec-2013)
Power Rating	:62mW
Resistor Mounting	:SMD
Weight (kg)	0.00001
Tariff No.	85332100
Brand/Series	CAT16Series
Circuit	IsolatedArray
PackageType	SMT
Power,Rating	0.248W
