Littelfuse
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
| Type | Description |
|---|---|
| Product Category | Resettable Fuses |
| RoHS | RoHS Compliant |
| Current Rating | 3 A |
| Resistance | 18 Ohms |
| Maximum Voltage DC | 600 V |
| Hold Current | 0.16 A |
| Mounting Style | Through Hole |
| Termination Style | Radial |
| Trip Current | 0.32 A |
| Lead Spacing | 5.1 mm |
| Series | 600R |
| Operating Temperature Range | - 40 C to + 85 C |
| Current Rating (Max) | 3 A |
| Dimensions | 12.6 mm L x 16 mm W x 6 mm H |
| Maximum Voltage | 600 VDC |
| Packaging | Ammo |
| Factory Pack Quantity | 500 |
| Type | PolyFuse Resettable PTC |
| Lead Diameter | 0.65 |
| Mounting | Through Hole |
| Maximum Current Rating | 3 |
| Typical Power Dissipation | 1 |
| Application | Alarm Systems|Central Office Equi... |
| Maximum Post Trip Resistance | 18 |
| Terminal Pitch | 5.1(Typ) |
| EU RoHS | Compliant |
| Maximum Voltage Rating | 60VDC|600VAC |
| Minimum Initial Resistance | 4 |
| Minimum Operating Temperature | -40 |
| Wire Form | Opposing Crimp Standoff |
| Product Length | 16(Max) |
| Maximum Operating Temperature | 85 |
| Maximum Trip Time | 10@1A |
| Seated Plane Height | 12.6(Max) |
| Product Depth | 6(Max) |
| Number of Terminals | 2 |
| Trip Current | 0.32 |
| Product Height | 12.6(Max) |
| Hold Current | 0.16 |
| Agency Approvals | cULus/TUV |
| Unit Pack | 0 |
| MOQ | 1 |
| Current - Max | 3A |
| Voltage - Max | 600V |
| Time to Trip | 18s |
| Standard Package | 500 |
| R Min/Max | 4.000 ~ 18.00 Ohm |
| Current - Hold (Ih) (Max) | 160mA |
| Current - Trip (It) | 320mA |
| Package/Case | Radial |
| rohs | Lead free / RoHS Compliant |
| Other Names | F5556CT |
| Current Rating - Max | 3 A |
| 系列 | POLYFUSE® 600R |
| 跳闸时间 | 18s |
| 电流 - 跳闸 (It) | 320mA |
| 电流 - 保持 (Ih)（最大值） | 160mA |
| 封装/外壳 | Radial |
| 电流 - 最大值 | 3A |
| R（最小/最大值） | 4.000 ~ 18.00 Ohm |
| 电压 - 最大值 | 600V |
| Brand | Littelfuse |
| Height | 6 mm |
| Length | 12.6 mm |
| Pd - Power Dissipation | 1 W |
| I(MAX) | 3 A |
| Automotive | NO |
| I(HOLD) | 0.16 A |
| Approvals | UR/TUV |
| Version | radial |
| Voltage | 600 V |
| Pitch | 5.1 mm |
| Termination | THT |
| Dimension | 13,5x12,6 |
| Leadfree Defin | RoHS-conform |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets | 600R Series |
