microchip
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
| Type | Description |
|---|---|
| Type | Adapter Tool |
| Family | PIC16F627A |
| Standard Package | Boxed |
| Product Category | In-Circuit Debuggers |
| RoHS | RoHS Compliant |
| Product | In-Circuit Debugger Kits |
| Tool Is For Evaluation Of | PIC MCUs, dsPIC DSCs |
| For Use With | 07-00024, AC164113 |
| Core | dsPIC, PIC |
| Interface Type | USB |
| Operating Supply Voltage | 3 V to 5 V |
| Description/Function | MPLAB ICD 3 in-circuit debugger system is Microchip's most cost effective high-speed hardware debugger/programmer for Microchip flash digital signal controller (DSC) and microcontroller (MCU) devices |
| Factory Pack Quantity | 1 |
| EU RoHS | Supplier Unconfirmed |
| Matchcode | MPLAB ICD3 |
| Unit Pack | 1 |
| Standard Leadtime | 6 weeks |
| MOQ | 1 |
| Leadfree Defin. | RoHS-conform |
| Developmenttool | DEBUGGER |
| For Use With/Related Products | MPLAB™ ICD 2 headers |
| Contents | In-circuit debugger/programmer unit, Cables and Software |
| rohs | Not applicable / Not applicable |
| Classification | Programmer |
| Core Type | PIC |
| Kit Contains | CD with Documentation & Software, Interface Test Module, MPLAB ICD 3 In-Circuit Debugger, RJ11 Cable, USB Cable |
| Technology | 16 bit |
| Silicon Family Name | :(Not Available) |
| Core Architecture | :PIC, dsPIC |
| Core Sub-Architecture | :(Not Available) |
| IC Product Type | :In-Circuit Debugger |
| Kit Contents | :MPLAB ICD 3 module, USB cable, RJ-11 cable, Interface test module, No CD |
| Features | :Real-time Debugging, Ruggedized Probe Interface, Portable, USB-Powered |
| SVHC | :No SVHC (20-Jun-2013) |
| Supported Devices | :Flash PIC MCUs, dsPIC DSCs (8/16/32-bit) |
| Weight (kg) | 1.24 |
| Tariff No. | 49019900 |
| Gross weight | 0.49 kg |
| Multiplicity | 1 |
| Type of ICs programmer | microcontrollers |
| Communication with PC | USB |
| Number of diodes | 3 |
