Manufacturer Part Number:

SST11LP12-QCF

OneIC Part Number:

260-SST11LP12-QCF

Manufacturer:

microchip

Description:

RF Amp Chip Single Power Amp 5.8GHz 4.2V 16-Pin WQFN EP

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Package	16WQFN EP
Number of Channels per Chip	1
Type	Power Amplifier
Typical Output Power	23@5800MHz dBm
Typical Power Gain	27@5800MHz dB
Maximum Operating Frequency Range	5000 to 10000 MHz
Typical Single Supply Voltage	3.3 V
Maximum Supply Current	400@3.3V mA
Standard Package	Tape & Reel
RoHS	RoHS Compliant
Operating Frequency	5.8 GHz
Power Gain Typ	32 dB
Supply Current	400 mA
Maximum Operating Temperature	+ 85 C
Mounting Style	SMD/SMT
Packaging	Reel
Minimum Operating Temperature	- 40 C
Factory Pack Quantity	3000
Unit Pack	3000
MOQ	3000
Supplier Device Package	16-WQFN (3x3)
RF Type	WLAN
Current - Supply	400mA
Voltage - Supply	2.7 V ~ 3.6 V
Gain	30dB
Frequency	4.9GHz ~ 5.8GHz
Package/Case	16-WFQFN Exposed Pad
rohs	Lead free / RoHS Compliant
Other Names	SST11LP12-QCFCT
Amplifier Type	Power
Dimensions	3 x 3 x 0.75mm
Height	0.75mm
Length	3mm
Maximum Operating Frequency	5.8 GHz
Maximum Operating Supply Voltage	3.6 V
Minimum Operating Supply Voltage	3 V
Mounting Type	Surface Mount
Package Type	WQFN
Pin Count	16
Width	3mm
Number of Channels	1 Channel
Frequency Min	:4.9GHz
Frequency Max	:5.8GHz
RF IC Case Style	:QFN
No. of Pins	:16
Supply Voltage Min	:3V
Supply Voltage Max	:3.6V
Operating Temperature Min	:-40°C
Operating Temperature Max	:85°C
MSL	:MSL 1 - Unlimited
SVHC	:No SVHC (16-Dec-2013)
Frequency Range	:4.9GHz to 5.8GHz
Operating Temperature Range	:-40°C to +85°C
Supply Voltage Range	:3V to 3.6V
Weight (kg)	0.0002
Tariff No.	85423300
Case	QFN16
Mounting	SMD
Integrated circuit type	power amplifier
Transmission band frequency	5.9GHz
Gross weight	0.21 g
Operating temperature	-40...85°C
Number of channels	1
Supply voltage	3...3.6V DC
Multiplicity	10
Collective package [pcs]	50
spg	50
