Manufacturer Part Number:

TC1046VNBTR

OneIC Part Number:

260-TC1046VNBTR

Manufacturer:

microchip

Description:

Temp Sensor Analog 3-Pin SOT-23B T/R

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Package	3SOT-23B
Sensor Gain	6.25 mV/°C
Accuracy	±0.5 °C
Function	Temp Sensor
Operating Supply Voltage	2.7 to 4.4 V
Output Type	Analog
Mounting	Surface Mount
Standard Package	Tape & Reel
Sensing Temperature	-40°C ~ 125°C
Supplier Device Package	SOT-23-3
Packaging	Tape & Reel (TR)
Voltage - Supply	2.7 V ~ 4.4 V
Package/Case	TO-236-3, SC-59, SOT-23-3
rohs	Lead free / RoHS Compliant
Other Names	TC1046VNBTRDKR
Dimensions	3.05 x 1.4 x 1.02mm
Height	1.02mm
Length	3.05mm
Maximum Operating Supply Voltage	4.4 V
Maximum Operating Temperature	+125 °C
Minimum Operating Supply Voltage	2.7 V
Minimum Operating Temperature	-40 °C
Mounting Type	Surface Mount
Package Type	SOT-23B
Pin Count	3
Width	1.4mm
Factory Pack Quantity	3000
Product Category	Board Mount Temperature Sensors
Output Current	100 uA
Series	TC1046
Package / Case	SOT-23B-3
Mounting Style	SMD/SMT
Supply Voltage - Max	4.4 V
Gain	6.25 mV / C
Shutdown	No
Device Function	Temperature Sensor
Supply Voltage - Min	2.7 V
Configuration	Local
Supply Current	60 uA
RoHS	RoHS Compliant
IC Output Type	:Voltage
Sensing Accuracy Range	:± 2°C
Sensing Temperature Min	:-40°C
Sensing Temperature Max	:+125°C
Supply Voltage Min	:2.7V
Supply Voltage Max	:4.4V
Sensor Case Style	:SOT-23
No. of Pins	:3
MSL	:MSL 1 - Unlimited
SVHC	:No SVHC (16-Dec-2013)
Base Number	:1046
IC Generic Number	:1046
Lead Spacing	:2.05mm
Logic Function Number	:1046
Operating Temperature Max	:125°C
Operating Temperature Range	:-40°C to +125°C
Output Voltage	:580mV
Output Voltage per °C	:6.25mV/°C
Row Pitch	:2.64mm
Sensor / Transducer Type	:Temperature
Supply Voltage	:7V
Supply Voltage Range	:2.7V to 4.4V
Temperature Sensing Range	:-40°C to +125°C
Termination Type	:SMD
Weight (kg)	0.000033
Tariff No.	85423990
BodyStyle	SOT-23
Current,Supply	60μA
MountingType	SMD
OutputType	Voltage
PrimaryType	Temperature
Range,Measurement	125°C
SensorType	Temperature
Temperature,Range	-40to125°C
Termination	SurfaceMount
Type	Temperature
Voltage,Range	2.7-4.4V
Voltage,Supply	2.7-4.4VDC
Case	SOT23B
Kind of temperature sensor	temperature transducer
Multiplicity	1
Integrated circuit type	temperature sensor
Gross weight	0.8 g
Tolerance	0,5°C
Operating voltage	2.7...4.4V
Temperature measuring range	-40...125°C
Collective package [pcs]	100
spg	100
