Manufacturer Part Number:

NUD4700SNT1G

OneIC Part Number:

277-NUD4700SNT1G

Manufacturer:

on semiconductor

Description:

Circuit Protection Misc LED Shunt Protector

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Family	NUD4700
Minimum Operating Temperature	-40 °C
Maximum Operating Temperature	150 °C
Standard Package	Tape & Reel
Product Category	LED Protection Devices
RoHS	RoHS Compliant
Breakdown Voltage	7.5 V
On-State Voltage	1.2 V
Rated Repetitive Off-State Voltage VDRM	10 V
On-State RMS Current (It RMS)	0.1 mA
Holding Current (Ih Max)	12 mA
Packaging	Reel
Mounting Style	SMD/SMT
Off-State Leakage Current @ VDRM IDRM	1.3 A
Product	LED Protector
Factory Pack Quantity	3000
EU RoHS	Compliant
Voltage - Working	5.5V
Supplier Device Package	Powermite
Applications	LED Protection
Power (Watts)	1.56W
Technology	Mixed Technology
Number of Circuits	1
Package/Case	DO-216AA
rohs	Lead free / RoHS Compliant
Other Names	NUD4700SNT1GOSCT
Peak Repetitive Off-State Voltage, Vdrm	:10V
Current It av	:1.3A
On State RMS Current IT(rms)	:1A
Holding Current Max Ih	:12mA
Operating Temperature Min	:-40°C
Operating Temperature Max	:150°C
Thyristor Case	:457-04
No. of Pins	:2
MSL	:MSL 1 - Unlimited
SVHC	:No SVHC (20-Jun-2013)
Operating Temperature Range	:-40°C to +150°C
Reference Voltage	:1V
Topology	:Shunt
Voltage Reference Case Style	:POWERMITE
Weight (kg)	0.002
Tariff No.	85423990
