Panasonic
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
| Type | Description |
|---|---|
| EU RoHS | RoHS Not Applicable |
| Maximum Operating Temperature | 60 |
| Non-Rechargeable/Rechargeable | Rechargeable |
| Package Height | 2.35 |
| Mounting | Surface Mount |
| Charge Current | 0.01 |
| Memory Effect | No |
| Number of Cells | 1 |
| Package Diameter | 6.8 |
| PCB | 2 |
| Shape | Coin |
| Product Weight | 0.23 |
| Capacity | 0.005 |
| Battery Type | Secondary |
| Minimum Operating Temperature | -20 |
| Chemistry | Lithium Manganese |
| Pin Count | 2 |
| Voltage | 3 |
| Size / Dimension | 0.27" Dia x 0.09" H (6.8mm x 2.2mm) |
| Capacity | 5mAh |
| Weight | 0.01 oz (0.28g) |
| Voltage - Rated | 3V |
| Battery Cell Size | Coin, 6.8mm |
| Discharge Rate | 10µA |
| Termination Style | Requires Holder |
| Standard Charge Current | 600µA |
| Battery Chemistry | Lithium |
| Standard Package | 2,000 |
| Shipping Info | Due to possible restrictions, a change in ship method may be required. |
| rohs | Lead free / RoHS compliant by exemption |
| Factory Pack Quantity | 2000 |
| Product Category | Coin Cell Battery |
| Battery Size | ML621 |
| Operating Temperature Range | - 20 C to + 60 C |
| Rechargeable/Non-Rechargeable | Rechargeable |
| Output Voltage | 3 V |
| Part # Aliases | ML-621S/ZTN |
| Type | Rechargeable Coin Cell Battery |
| RoHS | Not Applicable |
| Brand/Series | ML-ManganeseLithium |
| ChemicalSystem | ManganeseLithium |
| Diameter | 6mm |
| DrainCapacity | 2.5mAh |
| Height | 2.1mm |
| PrimaryType | Rechargeable |
| Size | Coin/Button |
| SpecialFeatures | Rechargeable |
| Voltage | 3V |
| Voltage,Rating | 3V |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets | ML614S, ML621S |
| Datasheets | ML Series Charging Info |
| Datasheets | Preventing Quality Issues |
| Datasheets | ML614S, ML621S Datasheet |
