Manufacturer Part Number:

FFSD-05-D-06.00-01-N

OneIC Part Number:

302-FFSD-05-D-06-00-01-N

Manufacturer:

samtec inc.

Description:

Cable Assembly Flat Ribbon 0.152m 30AWG 10 POS IDC Connector to 10 POS IDC Connector F-F IDT-IDT Bulk

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Connector Type	10POS IDC Connector to 10POS IDC Connector
Cable Type	Flat Ribbon
Gender	F-F
Cable Length	0.152 m
Termination Method	IDT-IDT
Standard Package	Bulk
Wire Size	30
EU RoHS	Compliant
Connector Type B	10POS IDC Connector
Connector Type A	10POS IDC Connector
Maximum Current Rating	0.5
Packaging	Bulk
Contact Plating	Gold Over Nickel
Cable Length	0.152
Contact Material	Beryllium Copper
Pitch - Cable	0.025" (0.635mm)
Shielding	Unshielded
Color	Gray, Ribbon
Contact Finish	Gold
Cable Termination	IDC
Length	0.500' (152.40mm, 6.00")
Number of Rows	2
Contact Finish Thickness	10µin (0.25µm)
Number of Positions	10
Pitch - Connector	0.050" (1.27mm)
rohs	Lead free / RoHS Compliant
Operating Temp Range	-40C to 105C
Current Rating (Max)	0.5 A
Wire Gauge	30
No. of Conductors	:10
Pitch Spacing	:1.27mm
Cable Length - Imperial	:6"
Cable Length - Metric	:152.4mm
Jacket Colour	:Grey
SVHC	:No SVHC (20-Jun-2013)
Connector A Contact Material	:Beryllium Copper
Connector A Contact Plating	:Gold
Connector B Contact Material	:Beryllium Copper
Connector B Contact Plating	:Gold
Material	:PBT
Operating Temperature Max	:105°C
Operating Temperature Min	:-40°C
Weight (kg)	0.074
Tariff No.	85444290

Documents & Media

RESOURCE TYPE	LINK
Datasheets	FFSD,FFMD Spec
Datasheets	FFSD-xx-x-xx.xx-01-x-x-zzz
