te connectivity / amp
Image shown is a representation only. Exact specifications should be obtained from the product datasheet.
| Type | Description |
|---|---|
| Number of Positions | 8 |
| Mounting | Through Hole |
| Pole Throw Configuration | SPST |
| Switch Configuration | OFF ON |
| Actuator Style | Raised Rocker |
| Terminal Type | PC Pins |
| Maximum Current Rating | 0.06@5VDC A |
| Maximum DC Voltage Rating | 24 V |
| Operating Temperature | -55 to 105 °C |
| Standard Package | Rail / Tube |
| Product Length | 22.35 |
| EU RoHS | Compliant |
| Maximum Operating Temperature | 105 |
| Contact Plating | Gold/Nickel |
| Product Depth | 9.65 |
| Body Orientation | Straight |
| Product Height | 8.64 |
| Maximum DC Voltage Rating | 24 |
| Terminal Pitch | 2.54 |
| Seal | Strippable Transparent |
| Minimum Operating Temperature | -55 |
| Maximum Current Rating | 0.06@5VDC |
| Contact Material | Copper Alloy |
| Comment | All switches are bottom sealed. |
| RoHSELV Compliance | RoHS compliant, ELV compliant |
| Lead Free Solder Processes | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c |
| Auto-Insertable | No |
| Series | 7100 |
| Brand | Alcoswitch |
| Number of Switches | 4 |
| Packaging Quantity | 25 |
| Centerline (mm in) | 2.54 [0.100] |
| Housing Material | Polyester |
| Configuration (Pole-Throw) | Single Pole - Single Throw |
| PCB Mount Style | Thru Hole |
| Housing Color | Blue |
| Sealed | No |
| Contact Mating Area Plating Material | Gold (30) over Nickel (50) |
| Product Type | DIP Switch |
| RoHSELV Compliance History | Always was RoHS compliant |
| Termination (Solder) Post Length (mm (in)) | 3.56 [0.140] |
| Washable | No |
| Actuator Type | Rocker |
| Mounting Type | Through Hole |
| Circuit | SPST |
| Contact Rating @ Voltage | 0.06A @ 5VDC |
| Orientation | Top Actuated |
| Actuator Level | Raised |
| rohs | Lead free / RoHS Compliant |
| Factory Pack Quantity | 25 |
| Product Category | DIP Switches / SIP Switches |
| Terminal Pitch | 2.54 mm |
| Switch Type | DIP |
| Contact Form | SPST |
| Termination Style | Through Hole |
| Actuator | Rocker |
| RoHS | RoHS Compliant |
| Contact Configuration | :SPST |
| No. of Switch Positions | :4 |
| Pitch Spacing | :2.54mm |
| Contact Current DC Max | :1A |
| Contact Current Max | :60mA |
| Weight (kg) | 0.002 |
| Tariff No. | 85365005 |
| ActuatorType | Rocker |
| ContactForm | SPSTx4 |
| Current,Rating | 60mA |
| MountingHoleSize | 0.035In. |
| MountingType | PCB |
| Operation | OnOff |
| Termination | PCBPins |
| Type | DIP |
| Voltage,Rating | 5VDC |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets | 5435640 Drawing |
| Datasheets | SWITCH ASSY, DIP, TYPE C, 7100 SERIES, SPST, STANDARD |
| Datasheets | 3D PDF |
| Datasheets | Dual In-Line Package (DIP) Programming Switches (7000 and 7100 Series) |
| Datasheets | Dual In-Line Package (DIP) Programming Switches (7000 and 7100 Series) |
