Manufacturer Part Number:

90760-1

OneIC Part Number:

35-90760-1

Manufacturer:

te connectivity / amp

Description:

Connector Accessories Socket/Pin Die Set Tool

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Type	Die Set
Family	90760
Standard Package	Bulk
Product Category	Crimpers
RoHS	Not Applicable
Product	Crimpers
Factory Pack Quantity	1
Subcategory	Hardware Tools
Lead Time	21 Days
Tool Type	Hand Crimper
Features	Side Entry, Ratchet
For Use With/Related Products	Rectangular Contacts, 16-20 AWG
rohs	Not applicable / Not applicable
Connector Type	Mate-N-Lock Contact
Maximum Wire Size	16 AWG
Minimum Wire Size	20AWG
系列	PRO-CRIMPER III
压接连接器类型	微型通用 MATE-N-LOK 触点
最小线规格	20AWG
线规格	20 → 16 AWG
最大线规格	16AWG
Tool Grade	Commercial Crimp Tooling
校准证书	否
模具组类型	可拆卸/可互换
电源类型	手动, 电气, 电池
棘轮配置	操作人员可拆除和进行调节
压接形式-压线筒类型	开式压线筒 - F 压接
Specification Type	TE Product Specification (114-)

Documents & Media

RESOURCE TYPE	LINK
Datasheets	Connector/Terminal-to-Tool Ref
Datasheets	90760-(1,2) Instr Sheet
Datasheets	PRO-CRIMPER III Hand Crimping Tool Assembly 90760-1 with Die Assemblly 90760-2
Datasheets	PRO-CRIMPER II Hand Tool Assembly 90760-1 w/Die Assembly 90760-2
Datasheets	PRO-CRIMPER II Hand Tool Assembly 90760-1 w/Die Assembly 90760-2
