Manufacturer Part Number:

STGIPN3H60

OneIC Part Number:

390-STGIPN3H60

Manufacturer:

STMicroelectronics

Description:

Power Driver ICs SLIMM Nano 3A 600V 3-Phase IGBT Bridge

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Supplier Package	NDIP
EU RoHS	Compliant
Pin Count	26
Lead Shape	Through Hole
Voltage - Isolation	1000VDC
Package / Case	26-DIP Module (0.846", 21.48mm)
Current	3A
Voltage	600V
Standard Package	17
Configuration	3 Phase Inverter
Type	IGBT
Other Names	497-12114
rohs	Lead free / RoHS Compliant
Mounting Style	Through Hole
Product	Driver ICs - Various
Product Category	Gate Drivers
Output Current	3 A
Maximum Power Dissipation	8 W
Packaging	Tube
Supply Voltage - Max	18 V
Minimum Operating Temperature	- 40 C
Supply Current	1 mA
Supply Voltage - Min	13.5 V
Maximum Operating Temperature	+ 150 C
RoHS	RoHS Compliant
Mounting	Through Hole
Operating Temperature (Max)	150C
Operating Temperature (Min)	-40C
Screening Level	Automotive
Case Height	3.1 mm
Rad Hardened	No
IPM Power Device	:IGBT
Voltage Rating (Vces / Vdss)	:600V
Current Rating (Ic / Id)	:3A
Isolation Voltage	:1kV
IPM Mounting Type	:PCB
IPM Case Style	:NDIP
IPM Series	:SLLIMM-nano
SVHC	:No SVHC (20-Jun-2013)
Weight (kg)	0.0001
Tariff No.	85412900
