Manufacturer Part Number:

AMMC-5026-W10

OneIC Part Number:

9-AMMC-5026-W10

Manufacturer:

avago technologies

Description:

RF Amp Module Single GP Amp 35GHz 10V Chip Tray

Customer Reference:

Datasheet:

Image shown is a representation only. Exact specifications should be obtained from the product datasheet.

Product Attributes

Type	Description
Type	General Purpose Amplifier
Typical Output Power	24@10000MHz dBm
Typical Power Gain	10.5@35000MHz dB
Typical Output Intercept Point	31@10000MHz dBm
Maximum Output Return Loss	15(Typ)@35000MHz dB
Maximum Input Return Loss	17(Typ)@35000MHz dB
Maximum Supply Voltage	10 V
Maximum Supply Current	450@7V mA
Standard Package	DIE
Product Category	RF Amplifier
RoHS	RoHS Compliant
Operating Frequency	35 GHz
Output Intercept Point	31 dBm
Power Gain Typ	10.5 dB
Operating Supply Voltage	10 V
Supply Current	450 mA
Packaging	Bulk
Input Return Loss	17 dB
Isolation dB	26 dB
Minimum Operating Temperature	- 55 C
Factory Pack Quantity	10
Function	Amplifier
rohs	Lead free / RoHS Compliant
Number of Channels	1 Channel
Operating Supply Current	450 mA
Frequency Range	2 GHz to 35 GHz
Package / Case	DIE
Brand	Broadcom / Avago
Gain	10.5 dB
Maximum Operating Temperature	+ 150 C
P1dB - Compression Point	22 dBm
Supply Voltage - Max	10 V
OIP3 - Third Order Intercept	31 dBm
Mounting Style	SMD/SMT
NF - Noise Figure	3.6 dB
Amplifier Type	MMIC
