American Technical Ceramics Corp.- Fixed Inductors

American Technical Ceramics Corp. (ATC) is a renowned manufacturer of high-performance electronic components, founded in 1962 and headquartered in Huntington Station, New York, USA. The company designs, develops, and produces multilayer ceramic capacitors (MLCCs), single-layer capacitors (SLCs), custom thin film products, resistive components, and inductors for RF, microwave, and millimeter-wave applications. ATC's products are critical enablers in wireless communications infrastructure, fiber optic networks, medical electronics, semiconductor manufacturing equipment, defense systems, aerospace, and satellite communications. The company is recognized for its industry-leading Q factor, ultra-low equivalent series resistance (ESR), and exceptional reliability in demanding environments. ATC's multilayer capacitors include the 100 Series, 600 Series, and 700 Series, widely used in matching, tuning, and coupling applications. Single-layer capacitors, such as the 900 Series, offer high-frequency performance and high-voltage handling. Custom thin film circuits and precision resistors, including the 470 Series, serve niche applications requiring tight tolerances. With ISO 9001 and ISO 14001 certifications, ATC maintains state-of-the-art manufacturing facilities to ensure product consistency. In 2007, ATC became a subsidiary of AVX Corporation, and later, as AVX merged into the KYOCERA group, ATC's expertise has been integrated into the global KYOCERA AVX Components Corporation, strengthening its market reach. The company holds a leading position in the RF capacitor segment, serving major OEMs and defense contractors worldwide.

Fixed Inductors - 型号列表

22 parts in total

Mfr Part #	Quantity Available	Price	Resistance - Initial (Ri) (Min)	Tolerance	Inductance	Current Rating (Max)	Package / Case	Size / Dimension	Operating Temperature	RoHS	Packaging	Other Names	Standard Package	Test Frequency	DC Resistance (DCR)	Shielding	Mounting Type	Material - Core	Height - Seated (Max)	Type	Product	Width	Termination Style	Series	Q @ Freq	Frequency - Self Resonant	Depth	Height	Length	Core Material	Part # Aliases
1008WL681J 1008 WL Series SMT inductor, 680nH ATC	18037	1: ¥3.2504	1.47Ω	±5%	680 nH	540mA	1008	2.92 x 2.79 x 2.1mm	+125°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	45	375MHz	2.79mm	2.1mm	2.92mm	Ceramic	-
0805WL3R3J 0805 WL Series SMT inductor, 3.3nH ATC	18037	1: ¥3.2504	80mΩ	±5%	3.3 nH	600mA	0805	2.29 x 1.73 x 1.52mm	+125°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	50	7.9GHz	1.73mm	1.52mm	2.29mm	Ceramic	-
0402WL5R1J 0402 WL Series SMT inductor, 5.1nH ATC	15262	1: ¥3.8488	83mΩ	±5%	5.1 nH	800mA	0402	1.27 x 0.76 x 0.61mm	+125°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	20	5.8GHz	0.76mm	0.61mm	1.27mm	Ceramic	-
1008WL751J 1008 WL Series SMT inductor, 750nH ATC	18037	1: ¥3.2504	1.54Ω	±5%	750 nH	360mA	1008	2.92 x 2.79 x 2.1mm	+125°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	45	360MHz	2.79mm	2.1mm	2.92mm	Ceramic	-
0805WL270J 0805 WL Series SMT inductor, 27nH ATC	18037	1: ¥3.2504	250mΩ	±5%	27 nH	500mA	0805	2.29 x 1.73 x 1.52mm	+125°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	55	2.5GHz	1.73mm	1.52mm	2.29mm	Ceramic	-
1008WL102J 1008 WL Series SMT inductor, 1uH ATC	49603	1: ¥1.1832	1.75Ω	±5%	1 μH	370mA	1008	2.92 x 2.79 x 2.1mm	+125°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	35	290MHz	2.79mm	2.1mm	2.92mm	Ceramic	-
1008WL222J 1008 WL Series SMT inductor, 2.2uH ATC	18037	1: ¥3.2504	2.8Ω	±5%	2.2 μH	280mA	1008	2.92 x 2.79 x 2.1mm	+125°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	28	160MHz	2.79mm	2.1mm	2.92mm	Ceramic	-
506WLSN1R47KT694T Fixed Inductors 1.47uH 10% Broadband Inductor IND 1.47UH 10% SMD American Technical Ceramics (ATC)	10	1: ¥295.664	0.33 Ohms	10 %	1.47 uH	694 mA	6.233 mm	3.378 mm W x 6.233 mm L x 2.972 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1320-2	100	1 MHz	330 mOhm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	3.378 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSN2R00KT494T Fixed Inductors 2.0uH 10% Broadband Inductor Inductor Broadband Conical Wirewound 2uH 10% 1MHz Powdered Iron 494mA 650mOhm DCR T/R IND 2UH 10% SMD American Technical Ceramics (ATC)	30	1: ¥201.348	0.65 Ohms	10 %	2 uH	494 mA	6.233 mm	3.378 mm W x 6.233 mm L x 2.972 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1321-2	100	1 MHz	650 mOhm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	3.378 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSM2R00KT277T Fixed Inductors 2.0uH 10% Broadband Inductor IND 2UH 10% SMD American Technical Ceramics (ATC)	320	1: ¥175.984	1.6 Ohms	10 %	2 uH	277 mA	3.226 mm	2.032 mm W x 3.226 mm L x 2.67 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1318-2	100	1 MHz	1.6 Ohm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	2.032 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSM0R70KT619T Fixed Inductors 0.7uH 10% Broadband Inductor IND 0.7UH 10% SMD American Technical Ceramics (ATC)	345	1: ¥195.50	0.32 Ohms	10 %	700 nH	619 mA	3.226 mm	2.032 mm W x 3.226 mm L x 2.67 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1316-2	100	1 MHz	320 mOhm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	2.032 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSN3R30KT350T Fixed Inductors 3.3uH 10% Broadband Inductor Inductor Broadband Conical Wirewound 3.3uH 10% 1MHz Powdered Iron 350mA 1.15Ohm DCR T/R IND 3.3UH 10% SMD American Technical Ceramics (ATC)	130	1: ¥201.348	1.15 Ohms	10 %	3.3 uH	350 mA	6.233 mm	3.378 mm W x 6.233 mm L x 2.972 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1322-2	100	1 MHz	1.2 Ohm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	3.378 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSM3R80KT182T Fixed Inductors 3.8uH 10% Broadband Inductor IND 3.8UH 10% SMD American Technical Ceramics (ATC)	114	1: ¥201.348	3.7 Ohms	10 %	3.8 uH	182 mA	3.226 mm	2.032 mm W x 3.226 mm L x 2.67 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1319-2	100	1 MHz	3.7 Ohm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	2.032 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSM1R10KT438T Fixed Inductors 1.1uH 10% Broadband Inductor Inductor Broadband Conical Wirewound 1.1uH 10% 1MHz Powdered Iron 438mA 640mOhm DCR T/R IND 1.1UH 10% SMD American Technical Ceramics (ATC)	145	1: ¥196.384	0.64 Ohms	10 %	1.1 uH	438 mA	3.226 mm	2.032 mm W x 3.226 mm L x 2.67 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1317-2	100	1 MHz	640 mOhm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	2.032 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSM0R47KT815T Fixed Inductors 0.47uH 10% Broadband Inductor Inductor Broadband Conical Wirewound 470nH 10% 1MHz Powdered Iron 815mA 190mOhm DCR T/R IND 0.47UH 10% SMD American Technical Ceramics (ATC)	481	1: ¥175.984	0.19 Ohms	10 %	470 nH	815 mA	3.226 mm	2.032 mm W x 3.226 mm L x 2.67 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1315-2	100	1 MHz	190 mOhm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	2.032 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
506WLSN6R00KT236T Fixed Inductors 6.0uH 10% Broadband Inductor IND 6UH 10% SMD American Technical Ceramics (ATC)	27	1: ¥201.348	2.85 Ohms	10 %	6 uH	236 mA	6.233 mm	3.378 mm W x 6.233 mm L x 2.972 mm H	- 55 C to + 125 C	RoHS Compliant	Cut Tape	1284-1323-2	100	1 MHz	2.8 Ohm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Ultra Broadband Inductor	Inductors	3.378 mm	SMD/SMT	506WLS	-	-	-	-	-	-	-
0402WL390JT Fixed Inductors 39nH 5% American Technical Ceramics (ATC)	10	1: ¥2.584	400 mOhms	-	-	-	-	-	-	RoHS Compliant	Reel	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	ATC0402WL390JT
0805WL820JT Fixed Inductors 82nH 5% American Technical Ceramics (ATC)	10	1: ¥3.944	400 mOhms	-	-	-	-	-	-	RoHS Compliant	Reel	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	ATC0805WL820JT
506WLSN10R7KT150T Fixed Inductors 10.7uH 10% Broadband Inductor Inductor Broadband Conical Wirewound 10.7uH 10% 1MHz Powdered Iron 150mA 7.1Ohm DCR T/R IND 10.7UH 10% SMD American Technical Ceramics (ATC)	10	100: ¥193.80	400 mOhms	±10%	10.7µH	150mA	Non Standard	0.127" L x 0.080" W (3.23mm x 2.03mm)	-55°C ~ 125°C	RoHS Compliant	Cut Tape	1284-1324-2	100	1MHz	7.1 Ohm	Unshielded	Surface Mount	Powdered Iron Core	0.105" (2.67mm)	Wirewound	-	-	-	-	-	-	-	-	-	-	ATC506WLSN10R7KT150T
0805WL151J WIRE WOUND CHIP INDUCTORS, WITH LOW DC RESISTANCE American Technical Ceramics	-		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
