DIP Switches
E-Switch, Inc.- DIP Switches
DIP Switches - 型号列表
366 parts in total| Mfr Part # | Quantity Available | Price | Standard Package | Circuit | Contact Rating @ Voltage | Orientation | Actuator Type | Mounting Type | Actuator Level | Number of Positions | Washable | Contact Resistance | Dielectric Strength | Insulation Resistance | Termination | Type | Card Standard | Ratings | Mechanical Life | Operating Force | Operating Temperature | Other Names | Series | Packaging | Contact Finish | Connector Impedance | Seal | Travel Range | Housing Color | Number of Contacts | Contact Layout, Typical | Features | Tape Included | Vibration | Temperature Range | Base Type | Contact Type | Shell Size - Insert | Seal Rating | Base Oil | Edge Contacts | Actuator Diameter | Contact Termination | RoHS | Contact Form | Termination Style | Switch Type | Standard Pack |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KAJ09LAGT DIP Switches / SIP Switches DIP SWITCH DIP LOW PRO 9 POS GOLD DIP Switch Type: Low Profile Ratings: 25mA @ 24 VDC Number of Positions: 9 Termination: Splayed Pins E-Switch | 10 | 1: ¥9.792 | 22 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Raised | 9 | No | initial 50m? typical @ 2-4 VCD, 100mA | 500 V rms @ sea level between adjacent terminals | 100 M? min. | Splayed Pins | Low Profile | DIP Switch | 25mA @ 24 VDC | 2,000 cycles, typical | - | -40° C to 85° C | EG4445 | - | Standard Tape | Gold | - | - | - | - | - | - | - | - | - | - | PPS UL94 V0, black finish | Gold-plated copper alloy | PPS UL94 V0, black finish | Tape Seal: | - | - | - | - | - | - | - | - | - |
 KAJ02TGGT DIP Switches / SIP Switches DIP SWITCH DIP LOW PRO 2 POS GOLD DIP Switch Type: Low Profile Ratings: 25mA @ 24 VDC Number of Positions: 2 Termination: Gull Wing E-Switch | - | 100 | SPST | 0.025 A | Top Actuated | Standard | Surface Mount | Recessed | 2 | Yes | initial 50m? typical @ 2-4 VCD, 100mA | 500 V rms @ sea level between adjacent terminals | 100 M? min. | Gull Wing | Low Profile | DIP Switch | 25mA @ 24 VDC | 2,000 cycles, typical | - | - 40 C to + 85 C | EG4420 | - | Standard Tape | Gold | - | - | - | - | - | - | - | - | - | - | PPS UL94 V0, black finish | Gold-plated copper alloy | PPS UL94 V0, black finish | Tape Seal: | - | - | - | - | Lead free / RoHS Compliant | SPST | Gull Wing | DIP | - | |
 KAS1112RT DIP Switches / SIP Switches DIP SW DIP SLIDE SPST 12 POS SEALD DIP Switches / SIP Switches 12 Position PC Pin Recessed Tape Sealed DIP Switch Type: Slide Ratings: 25mA @ 24V DC Number of Positions: 12 Termination: PC Pin E-Switch | 10 | 1008: ¥7.548 | 14 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Recessed | 12 | Yes | Initial:50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Slide | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | - | EG4505 | KAS | - | - | Phosphor Bronze with gold plate over nickel plate | Top Tape Sealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | Operating/Storage: -40° C to 85° C | - | - | - | - | - | - | - | - | - | - | - | - | - |
 KAR03LHGT DIP Switches / SIP Switches DIP SW DIP PIANO SEALED 3POS GOLD DIP Switch Type: Piano DIP / Low Profile Ratings: 25mA @ 24V DC Number of Positions: 3 Termination: Straight Pins E-Switch | 10 | 1: ¥5.44 | 58 | SPST | 0.025A @ 24VDC | Side Actuated | Piano | Through Hole | Raised | 3 | Yes | Initial: 50 milliohms max, After Life: 100 milliohms max | 500 VAC for 60 seconds | 1,000 Megaohms min @ 100VDC | Straight Pins | Switches | DIP Switch | 25 mA @ 24 VDC | 2000 make-and-break cycles, each circuit | 500gf max | -30C to +85C | - | - | Standard Tube Qty | Gold | - | - | - | - | - | - | - | - | - | - | - | - | - | - | PPS, UL94-V0 | Copper alloy with gold over tin plate | Extended | Brass with PACKAGING gold over tin plate | - | - | - | - | - |
| 10 | 5000: ¥2.9648 | 5,000 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | * | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Lead free / RoHS Compliant | - | - | - | - |
 KAR05LGGT DIP Switches / SIP Switches DIP SW PIANO DIP 5 POS SEALED SMT DIP Switch Type: Piano DIP / Low Profile Ratings: 25mA @ 24V DC Number of Positions: 5 Termination: Gull Wing E-Switch | - | 35 | SPST | 0.025A @ 24VDC | Side Actuated | Piano | Surface Mount | Raised | 5 | Yes | Initial: 50 milliohms max, After Life: 100 milliohms max | 500 VAC for 60 seconds | 1,000 Megaohms min @ 100VDC | Gull Wing | Switches | DIP Switch | 25 mA @ 24 VDC | 2000 make-and-break cycles, each circuit | 500gf max | -30C to +85C | EG4478 | - | Standard Tube Qty | Gold | - | - | - | - | - | - | - | - | - | - | - | - | - | - | PPS, UL94-V0 | Copper alloy with gold over tin plate | Extended | Brass with PACKAGING gold over tin plate | - | - | - | - | - | |
 KAS1112ET DIP Switches / SIP Switches DIP SW DIP SLIDE SPST 12 POS SEALED DIP Switches / SIP Switches 12 Position PC Pin Extended Tape Sealed DIP Switch Type: Slide Ratings: 25mA @ 24V DC Number of Positions: 12 Termination: PC Pin E-Switch | 10 | 1008: ¥7.548 | 14 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Raised | 12 | Yes | Initial:50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Slide | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | - | EG4504 | KAS | - | - | Phosphor Bronze with gold plate over nickel plate | Top Tape Sealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | Operating/Storage: -40° C to 85° C | - | - | - | - | - | - | - | - | - | - | - | - | - |
| - | 190 | SPST | 0.025 A | Top Actuated | Standard | Through Hole | Raised | 1 | No | - | - | - | - | - | - | - | - | - | - 40 C to + 85 C | EG4415 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Lead free / RoHS Compliant | SPST | Solder Pin | DIP | - | |
 KAP1107VT DIP Switches / SIP Switches DIP SW DIP PIANO SPST 7 POS SEALED DIP Switches / SIP Switches 7 Position Extended Topside On Top Seal DIP Switch Type: Piano DIP Ratings: 25mA @ 24V DC Number of Positions: 7 Termination: PC Pins E-Switch | 10 | 1008: ¥6.664 | 24 | SPST | 0.025A @ 24VDC | Side Actuated | Piano | Through Hole | Recessed | 7 | Yes | Initial: 50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Piano DIP | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | Operating/Storage: -40° C to 85° C | - | KAP | - | - | Phosphor Bronze with gold plate over nickel plate | Top Tape Sealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 KAJ07SGGT DIP Switches / SIP Switches DIP SW DIP LOW PRO 7 POS GOLD DIP Switch Type: Low Profile Ratings: 25mA @ 24 VDC Number of Positions: 7 Termination: Gull Wing E-Switch | - | 800 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Surface Mount | Recessed | 7 | No | initial 50m? typical @ 2-4 VCD, 100mA | 500 V rms @ sea level between adjacent terminals | 100 M? min. | Gull Wing | Low Profile | DIP Switch | 25mA @ 24 VDC | 2,000 cycles, typical | - | -40° C to 85° C | - | - | Standard Tape | Gold | - | - | - | - | - | - | - | - | - | - | PPS UL94 V0, black finish | Gold-plated copper alloy | PPS UL94 V0, black finish | Tape Seal: | - | - | - | - | - | - | - | - | - | |
 KAS1112E DIP Switches / SIP Switches DIP SW DIP SLIDE SPST 12POS UNSEALD DIP Switches / SIP Switches 12 Position PC Pin Extended Unsealed DIP Switch Type: Slide Ratings: 25mA @ 24V DC Number of Positions: 12 Termination: PC Pin E-Switch | 10 | 1008: ¥7.208 | 14 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Raised | 12 | No | Initial:50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Slide | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | - | EG4503 | KAS | - | - | Phosphor Bronze with gold plate over nickel plate | Standard Unsealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | Operating/Storage: -40° C to 85° C | - | - | - | - | - | - | - | - | - | - | - | - | - |
 KAR10LGGT DIP Switches / SIP Switches DIP SW PIANO DIP 10 POS SEALED SMT DIP Switch Type: Piano DIP / Low Profile Ratings: 25mA @ 24V DC Number of Positions: 10 Termination: Gull Wing E-Switch | - | 18 | SPST | 0.025A @ 24VDC | Side Actuated | Piano | Surface Mount | Raised | 10 | Yes | Initial: 50 milliohms max, After Life: 100 milliohms max | 500 VAC for 60 seconds | 1,000 Megaohms min @ 100VDC | Gull Wing | Switches | DIP Switch | 25 mA @ 24 VDC | 2000 make-and-break cycles, each circuit | 500gf max | -30C to +85C | EG4484 | - | Standard Tube Qty | Gold | - | - | - | - | - | - | - | - | - | - | - | - | - | - | PPS, UL94-V0 | Copper alloy with gold over tin plate | Extended | Brass with PACKAGING gold over tin plate | - | - | - | - | - | |
KAJ04SGGR DIP Switches / SIP Switches DIP SW DIP LOW PRO 4 POS GOLD DIP Switch Type: Low Profile Ratings: 25mA @ 24 VDC Number of Positions: 4 Termination: Gull Wing E-Switch | - | 1,000 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Surface Mount | Recessed | 4 | No | initial 50m? typical @ 2-4 VCD, 100mA | 500 V rms @ sea level between adjacent terminals | 100 M? min. | Gull Wing | Low Profile | DIP Switch | 25mA @ 24 VDC | 2,000 cycles, typical | - | -40° C to 85° C | - | - | Tape and Real | Gold | - | - | - | - | - | - | - | - | - | - | PPS UL94 V0, black finish | Gold-plated copper alloy | PPS UL94 V0, black finish | Tape Seal: | - | - | - | - | - | - | - | - | - | |
 KAS2103ET DIP Switches / SIP Switches 3 PositionR/A PC Pin Extended Tape Sealed SWITCH 3 POS DIP RT ANG SLIDE Switch DIP OFF ON SPST 3 Raised Slide 0.025A 24VDC PC Pins 2.54mm Thru-Hole Tube DIP Switch Type: Slide Ratings: 25mA @ 24V DC Number of Positions: 3 Termination: PC Pin (Right Angle) E-Switch | 890 | 1: ¥7.208 | 50 | SPST | 0.025A @ 24VDC | Side Actuated | Standard | Through Hole | Raised | 3 | Yes | Initial:50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins (Right Angle) | Slide | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | - | Q1156892 | KAS | - | - | Phosphor Bronze with gold plate over nickel plate | Top Tape Sealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | Operating/Storage: -40° C to 85° C | - | - | - | - | - | - | - | - | - | - | - | - | - |
KAR04LHGT DIP Switches / SIP Switches DIP SW DIP PIANO SEALED 4POS GOLD DIP Switch Type: Piano DIP / Low Profile Ratings: 25mA @ 24V DC Number of Positions: 4 Termination: Straight Pins E-Switch | 513 | 4: ¥8.67 | 42 | SPST | 0.025A @ 24VDC | Side Actuated | Piano | Through Hole | Raised | 4 | Yes | Initial: 50 milliohms max, After Life: 100 milliohms max | 500 VAC for 60 seconds | 1,000 Megaohms min @ 100VDC | Straight Pins | Switches | DIP Switch | 25 mA @ 24 VDC | 2000 make-and-break cycles, each circuit | 500gf max | -30C to +85C | - | - | Standard Tube Qty | Gold | - | - | - | - | - | - | - | - | - | - | - | - | - | - | PPS, UL94-V0 | Copper alloy with gold over tin plate | Extended | Brass with PACKAGING gold over tin plate | - | - | - | - | - |
 KAS1108RT DIP Switches / SIP Switches 8 Position PC Pin Recessed Tape Sealed SW DIP SLIDE SPST 8 POS SEAL 24V DIP Switch Type: Slide Ratings: 25mA @ 24V DC Number of Positions: 8 Termination: PC Pin E-Switch | 587 | 1: ¥11.152 | 21 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Recessed | 8 | Yes | Initial:50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Slide | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | - | EG4501 | KAS | - | - | Phosphor Bronze with gold plate over nickel plate | Top Tape Sealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | Operating/Storage: -40° C to 85° C | - | - | - | - | - | - | - | - | - | - | - | - | 21 |
 KAJ10SHGT DIP Switches / SIP Switches DIP SW DIP LOW PRO 10 POS GOLD DIP Switch Type: Low Profile Ratings: 25mA @ 24 VDC Number of Positions: 10 Termination: Straight Pins E-Switch | - | 20 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Recessed | 10 | No | initial 50m? typical @ 2-4 VCD, 100mA | 500 V rms @ sea level between adjacent terminals | 100 M? min. | Straight Pins | Low Profile | DIP Switch | 25mA @ 24 VDC | 2,000 cycles, typical | - | -40° C to 85° C | - | - | Standard Tape | Gold | - | - | - | - | - | - | - | - | - | - | PPS UL94 V0, black finish | Gold-plated copper alloy | PPS UL94 V0, black finish | Tape Seal: | - | - | - | - | - | - | - | - | - | |
 KAS1106E DIP Switches / SIP Switches 6 Position PC Pin Extended Unsealed SW DIP SLIDE SPST 6 POS UNSEALD DIP Switch Type: Slide Ratings: 25mA @ 24V DC Number of Positions: 6 Termination: PC Pin E-Switch | 318 | 1: ¥9.656 | 27 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Raised | 6 | No | Initial:50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Slide | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | - | EG4496 | KAS | - | - | Phosphor Bronze with gold plate over nickel plate | Standard Unsealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | Operating/Storage: -40° C to 85° C | - | - | - | - | - | - | - | - | - | - | - | - | - |
 KAP1108ET DIP Switches / SIP Switches 8 Position Extended Topside Off Top Seal SW DIP PIANO SPST 8 POS SEALED DIP Switch Type: Piano DIP Ratings: 25mA @ 24V DC Number of Positions: 8 Termination: PC Pins E-Switch | 10 | 1: ¥9.656 | 23 | SPST | 0.025A @ 24VDC | Side Actuated | Piano | Through Hole | Raised | 8 | Yes | Initial: 50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Piano DIP | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | Operating/Storage: -40° C to 85° C | - | KAP | - | - | Phosphor Bronze with gold plate over nickel plate | Top Tape Sealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | - | - | - | - | - | - | - | - | - | - | - | - | - | 23 |
 KAS1103R DIP Switches / SIP Switches 3 Position PC Pin Recessed Unsealed SW DIP SLIDE SPST 3 POS UNSEALD DIP Switch Type: Slide Ratings: 25mA @ 24V DC Number of Positions: 3 Termination: PC Pin E-Switch | 10 | 1071: ¥5.7217 | 51 | SPST | 0.025A @ 24VDC | Top Actuated | Standard | Through Hole | Recessed | 3 | No | Initial:50 m? typical @ 2-4V DC @ 100mA, After Life: 100m? typical @ 2-4 DC @ 100mA | 500V RMS min. @ sea level between adjacent terminals | 100 M? Min. @ 500V DC | PC Pins | Slide | DIP Switch | 25 mA @ 24 VDC | 2,000 make-and-break cycles, each circuit | 1000 gf max. | - | - | KAS | - | - | Phosphor Bronze with gold plate over nickel plate | Standard Unsealed | 2.0 mm typical | Glass filled polyester (PBT) UL94-V0 | Phosphor Bronze with gold plate over nickel plate | SPST | Wave: 500 F (260 C) for 5s max; Hand: 30W soldering iron @ 608 F (320 C) for 2s typical. Keep all switches in the OFF position during soldering and cleaning process. | Mylar | To MIL-STD-202F, Method 201 A | Operating/Storage: -40° C to 85° C | - | - | - | - | - | - | - | - | - | - | - | - | - |
