Eaton Corporation plc- Miniature Circuit Breakers

Eaton Corporation plc is a global power management company founded in 1911 by Joseph O. Eaton. Headquartered in Dublin, Ireland, with its operational base in Cleveland, Ohio, USA, Eaton operates in over 175 countries. Its core business areas include electrical products, systems and services, aerospace, hydraulics, and vehicle. Within electronic components, Eaton offers a comprehensive range of power quality, distribution, and protection products. Key product lines include Bussmann series fuses and circuit breakers, PowerStor supercapacitors, Coiltronics inductors and transformers, and a variety of surge protective devices. The company also manufactures Uninterruptible Power Supply (UPS) systems, power distribution units (PDUs), and sensors for pressure, temperature, and fluid monitoring. Eaton enhances system reliability and energy efficiency through these components, serving data centers, industrial automation, aerospace, and automotive markets. In the power management and electrical components industry, Eaton holds a leading position, recognized for its extensive portfolio and innovation. The company consistently ranks among the Fortune 500 and has a strong manufacturing presence in China with 27 facilities and approximately 10,000 employees. With over 92,000 employees globally, Eaton continues to drive advancements in safe and sustainable power management solutions.

Miniature Circuit Breakers - 型号列表

683 parts in total

Mfr Part #	Quantity Available	Number of Poles	Voltage - Rated AC	Current Rating (Max)	Mounting Style	Voltage - Rated DC	Voltage - Supply (Min)	Depth	Width	Length	Operating Force	Sensitivity	Voltage - Supply	Type	For Use With/Related Products	CAD Drawing
PXL-D15/3 3P 15A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type D Tripping Characteristics Eaton Corporation plc	-	3P	400 V	15 A	DIN Rail Mount	48V	10 kA	60mm	80mm	52.5mm	Type D	-	-	-	-	-
PLSM-B13-DW 1P 13A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type B Tripping Characteristics Eaton Corporation plc	-	SP	230 V, 400 V	13 A	DIN Rail Mount	48V	10 kA	69.5mm	80mm	17.5mm	Type B	-	-	-	-	-
PXL-C63/2 2P 63A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type C Tripping Characteristics Eaton Corporation plc	-	DP	400 V	63 A	DIN Rail Mount	48V	10 kA	60mm	80mm	35mm	Type C	-	-	-	-	-
PLS6-B25/2 2P 25A MCB, Breaking Capacity 6kA, DIN Rail Mount, Type B Tripping Characteristics Eaton Corporation plc	-	DP	230 V, 400 V	25 A	DIN Rail Mount	48V	6 kA	60mm	35mm	80mm	Type B	-	-	-	-	-
PLSM-B6-DW 1P 6A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type B Tripping Characteristics Eaton Corporation plc	-	SP	230 V, 400 V	6 A	DIN Rail Mount	48V	10 kA	69.5mm	80mm	17.5mm	Type B	-	-	-	-	-
ZM-6-PKZ2 Motor protect trip block,4-6A FLC range Motor Protection Modules Eaton Corporation plc	-	-	-	-	-	-	-	-	-	-	-	-	220 → 240 V ac	Overload Release, Short Circuit Release	ZM-PKZ2 Series	-
PXF-63/2/003-A 2P 63A RCD, Trip Sensitivity 30mA, DIN Rail Mount Eaton Corporation plc	-	DP	230 V	63 A	DIN Rail	-	-	-	-	-	-	30mA	-	-	-	-
PLSM-B16-DW 1P 16A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type B Tripping Characteristics Eaton Corporation plc	-	SP	230 V	16 A	DIN Rail Mount	48V	10 kA	69.5mm	80mm	17.5mm	Type B	-	-	-	-	-
PXF-16/2/05-A 2P 16A RCD, Trip Sensitivity 500mA, DIN Rail Mount Eaton Corporation plc	-	DP	230 V	16 A	DIN Rail	-	-	-	-	-	-	500mA	-	-	-	-
2 U-PKZ0(240V50HZ) Motor starter under voltage trip,240V Eaton 欠压释放, 使用于PKE 系列、PKM0 系列、PKZM0 系列、PKZM01 系列、PKZM0-T 系列、PKZM4 系列 Eaton Corporation plc	-	-	-	-	-	-	-	-	-	-	-	-	240 V ac	Undervoltage Release	PKE Series, PKM0 Series, PKZM0 Series, PKZM01 Series, PKZM0-T Series, PKZM4 Series	3D CAD 模型
PLSM-B10-DW 1P 10A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type B Tripping Characteristics Eaton Corporation plc	-	SP	230 V, 400 V	10 A	DIN Rail Mount	48V	10 kA	69.5mm	80mm	17.5mm	Type B	-	-	-	-	-
PXF-25/2/01-A 2P 25A RCD, Trip Sensitivity 100mA, DIN Rail Mount Eaton Corporation plc	-	DP	230 V	25 A	DIN Rail	-	-	-	-	-	-	100mA	-	-	-	-
PXF-100/4/03-A 4P 100A RCD, Trip Sensitivity 300mA, DIN Rail Mount Eaton Corporation plc	-	4P	400 V	100 A	DIN Rail	-	-	-	-	-	-	300mA	-	-	-	-
PXF-100/4/01-A 4P 100A RCD, Trip Sensitivity 100mA, DIN Rail Mount Eaton Corporation plc	-	4P	400 V	100 A	DIN Rail	-	-	-	-	-	-	100mA	-	-	-	-
PXL-C3/3 3P 3A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type C Tripping Characteristics Eaton Corporation plc	-	3P	400 V	3 A	DIN Rail Mount	48V	10 kA	60mm	80mm	52.5mm	Type C	-	-	-	-	-
PLSM-B25-DW 1P 25A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type B Tripping Characteristics Eaton Corporation plc	-	SP	230 V	25 A	DIN Rail Mount	48V	10 kA	69.5mm	80mm	17.5mm	Type B	-	-	-	-	-
PLSM-C13-DW 1P 13A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type C Tripping Characteristics Eaton Corporation plc	-	SP	230 V, 400 V	13 A	DIN Rail Mount	48V	10 kA	69.5mm	80mm	17.5mm	Type C	-	-	-	-	-
PXF-80/4/03-A 4P 80A RCD, Trip Sensitivity 300mA, DIN Rail Mount Eaton Corporation plc	-	4P	400 V	80 A	DIN Rail	-	-	-	-	-	-	300mA	-	-	-	-
PXL-D1/3 3P 1A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type D Tripping Characteristics Eaton Corporation plc	-	3P	400 V	1 A	DIN Rail Mount	48V	10 kA	60mm	80mm	52.5mm	Type D	-	-	-	-	-
PXL-C1,6/3 3P 1.6A MCB, Breaking Capacity 10kA, DIN Rail Mount, Type C Tripping Characteristics Eaton Corporation plc	-	3P	400 V	1.6 A	DIN Rail Mount	48V	10 kA	60mm	80mm	52.5mm	Type C	-	-	-	-	-
