Keysight Technologies, Inc.- Power Supplies and Modules

Keysight Technologies, Inc. is a global leader in electronic test and measurement equipment and software. The company was spun off from Agilent Technologies in 2014, originally tracing its roots to Hewlett-Packard's test and measurement division founded in 1939. Headquartered in Santa Rosa, California, Keysight designs and manufactures instruments that help engineers and scientists measure, test, and validate electronic designs. Its core product lines include advanced oscilloscopes such as the Infiniium and InfiniiVision series, signal and spectrum analyzers like the N9040B UXA, network analyzers (PNA and ENA families), logic analyzers, and precision multimeters. The company also offers modular instruments (PXIe, AXIe), handheld field instruments, and extensive software solutions for design, data analysis, and automation. Keysight serves a wide range of industries including telecommunications, semiconductor, automotive, aerospace and defense, and industrial IoT. It is recognized as a top-tier player in the test and measurement market, competing with Tektronix and Rohde & Schwarz, and holding a significant share in high-frequency and wireless test. The company is known for its innovative contributions to 5G, 6G research, quantum computing, and automotive radar testing. With over 15,000 employees worldwide, Keysight continues to drive technological progress through precision measurement science and robust R&D investment.

Power Supplies and Modules - 型号列表

67 parts in total

Mfr Part #	Quantity Available	Power - Rated	Voltage Rating	Current - Output	Number of Outputs	Voltage - Supply	SVHC	Tariff No	Output Type	Current - Output (Typ)	Voltage - Output (Max)	Voltage - Output (Min/Fixed)	Width	Height	Length	Weight	Warranty	Plug Type	Voltage - Input (Min)	Approval Agency	Load Regulation	Type	Operating Temperature	Maximum Temperature Limit	Number of Positions	RoHS	Calibration	Current - Output 2	Current - Output 3	Voltage - Output 3	Voltage - Output 2 (Adj Range)
6623A 105W 3 Output Digital Bench Power Supply, 0 to 7, 0 to 20, 0 to 50V, 0 to 0.8, 0 to 2, 0 to 4, 0 to 5, 0 to 10A DCPOWERSUPPLY,TRIPLE-OUTPUT.7V/5A,20V/2A,7V/10A.GPIB Keysight Technologies, Inc.	-	105W	0 → 20 V, 0 → 50 V, 0 → 7 V	0 → 0.8 A, 0 → 10 A, 0 → 2 A, 0 → 4 A, 0 → 5 A	3	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Digital	0°C	+55°C	2	-	-	-	-	-	-
6543A 210W 1 Output Digital Bench Power Supply, 0 to 35V, 5.1, 5.4A DCpowersupply,0-35V,0-6A,200W.Manuallycontrolled Keysight Technologies, Inc.	-	210W	0 → 35V	5.1 A, 5.4 A	1	120 V ac, 220 V ac	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Digital	0°C	+55°C	2	-	-	-	-	-	-
6554A 540W 1 Output Digital Bench Power Supply, 0 to 60V, 7.7, 8.1A Keysight Technologies, Inc.	-	540W	0 → 60V	7.7 A, 8.1 A	1	120 V ac, 220 V ac	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Digital	0°C	+55°C	2	-	-	-	-	-	-
6575A RSCAL(6909411) DC P/S,0-120V,0-18A,2160W UKAS(6909411) DC P/S,0-120V,0-18A,2160W 2160W 1 Output Digital Bench Power Supply, 0 to 120V, 0 to 18A DCPOWERSUPPLY,0-120V,0-18A,2160W.MANUALLYCONTROLLED. Keysight Technologies, Inc.	-	2160W	0 → 120V	0 → 18A	1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Digital	0°C	+55°C	2	Exempt	RSCAL	-	-	-	-
6542A 200W 1 Output Digital Bench Power Supply, 0 to 20V, 8.5, 9A DCPOWERSUPPLY,0-20V,0-10A,200W.MANUALLYCONTROLLED. Keysight Technologies, Inc.	-	200W	0 → 20V	8.5 A, 9 A	1	120 V ac, 220 V ac	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Digital	0°C	+55°C	2	-	-	-	-	-	-
6573A-832 2100W 1 Output Digital Bench Power Supply, 0 to 35V, 0 to 60A Keysight Technologies, Inc.	-	2100W	0 → 35V	0 → 60A	1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Digital	0°C	+55°C	2	-	-	-	-	-	-
66101A 128W 1 Output Digital Bench Power Supply, 0 to 8V, 0 to 16A DC POWER MODULE - 8 V, 16 A, 128 W DCPOWERMODULE-8V,16A,128W Keysight Technologies, Inc.	-	128W	0 → 8V	0 → 16A	1	120 V ac, 230 V ac	:No SVHC (20-Jun-2013)	85043180	:Adjustable	:0A	:8V	:0V	:425.7mm	:192mm	:677.93mm	:2.8kg	:3 Years	:-	-	:CSA, IEC, UL	-	Digital	0°C	+55°C	-	-	-	-	-	-	-
6680A-400-862 POWER SUPPLY, 5V, 875A, 5000W. GPIB Keysight Technologies, Inc.	-	:5kW	:360V AC to 440V AC	:875A	:1	:400V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:5V	:0V	:425.5mm	:221.5mm	:674.7mm	:51.3kg	:3 Years	:-	:360V to 440V	-	:0.002%	-	-	-	-	-	-	-	-	-	-
6035A-230-833 POWER SUPPLY, 500VDC, 5A, 105W GPIB Keysight Technologies, Inc.	-	:1.05kW	:207V AC to 253V AC	:5A	:1	:230V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:500V	:0V	:425.5mm	:132.6mm	:503.7mm	:16.3kg	:3 Years	:-	:207V to 253V	:CSA, EN, IEC, UL	:0.01%	-	-	-	-	-	-	-	-	-	-
6573A-240-902 POWER SUPPLY, 0-35 V, 0-60 A, 2100W Keysight Technologies, Inc.	-	:2kW	:209V AC to 264V AC	:60A	:1	:240V AC	:No SVHC (20-Jun-2013)	85043180	:Adjustable	:0A	:35V	:0V	:425.5mm	:132.6mm	:640mm	:28.2kg	:3 Years	:-	:209V to 264V	:CSA, IEC, UL	:0.002%	-	-	-	-	-	-	-	-	-	-
6612C-240-PLG POWER SUPPLY, 20V, 2A 40W GPIB RS232 Keysight Technologies, Inc.	-	:40W	:209V AC to 264V AC	:2A	:1	:240V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:20V	:0V	:212.8mm	:88.1mm	:368.3mm	:8.2kg	:3 Years	:Euro, UK	:209V to 264V	-	-	-	-	-	-	-	-	-	-	-	-
6626A-230-902 POWER SUPPLY, 4 OUTPUT, GPIB Keysight Technologies, Inc.	-	:150W	:207V AC to 253V AC	:2A	:4	:230V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:50V	:0V	:425.5mm	:132.6mm	:497.8mm	:17.4kg	:3 Years	:Euro, UK	:207V to 253V	:IEC, UL	-	-	-	-	-	-	-	:200mA	:2A	:16V	:16V
6652A-240-PLG POWER SUPPLY, 20V, 25A, 500W, GPIB Keysight Technologies, Inc.	-	:500W	:209V AC to 264V AC	:25A	:1	:240V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:20V	:0V	:425.5mm	:132.6mm	:497.8mm	:25kg	:3 Years	:Euro, UK	:209V to 264V	:IEC, UL	-	-	-	-	-	-	-	-	-	-	-
6681A-400-862 POWER SUPPLY, 8V, 580A, 5000W, GPIB Keysight Technologies, Inc.	-	:5kW	:360V AC to 440V AC	:580A	:1	:400V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:8V	:0V	:425.5mm	:221.5mm	:674.7mm	:51.3kg	:3 Years	:-	:360V to 440V	-	:0.002%	-	-	-	-	-	-	-	-	-	-
6645A-240-PLG POWER SUPPLY, 120V, 1.5A, 180W, GPIB Keysight Technologies, Inc.	-	:180W	:209V AC to 264V AC	:1.5A	:1	:240V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:120V	:0V	:425.5mm	:88.1mm	:439mm	:14.2kg	:3 Years	:Euro, UK	:209V to 264V	:IEC, UL	-	-	-	-	-	-	-	-	-	-	-
6675A-230-832 POWER SUPPLY, 120V, 18A, 2160W, GPIB Keysight Technologies, Inc.	-	:2.16kW	:191V AC to 250V AC	:18A	:1	:230V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:120V	:0V	:425.5mm	:132.6mm	:640mm	:28.2kg	:3 Years	:Euro	:191V to 250V	:CSA, IEC, UL	:0.002%	-	-	-	-	-	-	-	-	-	-
6674A-230-832 POWER SUPPLY, 60V, 35A, 2100W, GPIB Keysight Technologies, Inc.	-	:2.1kW	:191V AC to 250V AC	:35A	:1	:230V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:60V	:0V	:425.5mm	:132.6mm	:640mm	:28.2kg	:3 Years	:Euro	:191V to 250V	:CSA, IEC, UL	:0.002%	-	-	-	-	-	-	-	-	-	-
6644A-240-PLG POWER SUPPLY, 60V, 3.5A, 210W, GPIB Keysight Technologies, Inc.	-	:210W	:209V AC to 264V AC	:3.5A	:1	:240V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:60V	:0V	:425.5mm	:88.1mm	:439mm	:14.2kg	:3 Years	:Euro, UK	:209V to 264V	:IEC, UL	-	-	-	-	-	-	-	-	-	-	-
6030A-230-833 POWER SUPPLY, 200VDC, 17A 120W GPIB Keysight Technologies, Inc.	-	:1.2kW	:207V AC to 253V AC	:17A	:1	:230V AC	:No SVHC (20-Jun-2013)	85043180	:Adjustable	:0A	:200V	:0V	:425.5mm	:132.6mm	:503.7mm	:16.3kg	:3 Years	:-	:207V to 253V	:CSA, EN, IEC, UL	:0.01%	-	-	-	-	-	-	-	-	-	-
6031A-230-833 POWER SUPPLY, 20VDC, 120A 1064W GPIB Keysight Technologies, Inc.	-	:1.064kW	:207V AC to 253V AC	:120A	:1	:230V AC	:Bis (2-ethylhexyl)phthalate (DEHP) (20-Jun-2013)	85043180	:Adjustable	:0A	:20V	:0V	:425.5mm	:132.6mm	:503.7mm	:17.2kg	:3 Years	:-	:207V to 253V	:CSA, EN, IEC, UL	:0.01%	-	-	-	-	-	-	-	-	-	-
