Siemens Energy AG- Digital Timers

Siemens Energy AG is a global energy technology company headquartered in Munich, Germany. It was spun off from Siemens AG in 2020 and operates as an independent publicly listed entity. The company focuses on the entire energy value chain, including power generation, transmission, and industrial applications. Its portfolio encompasses gas and steam turbines, generators, transformers, and grid solutions. Through its majority stake in Siemens Gamesa Renewable Energy, it is a leading player in wind power. Siemens Energy is also a key provider of high-voltage direct current (HVDC) transmission systems and flexible alternating current transmission systems (FACTS). The company leverages digital technologies like its Omnivise hybrid power plant control system for optimized energy management. With a strong emphasis on decarbonization, Siemens Energy is actively involved in hydrogen technologies and power-to-X solutions. It serves utilities, independent power producers, and industrial sectors worldwide, playing a pivotal role in the global energy transition.

Digital Timers - 型号列表

42 parts in total

Mfr Part #	Quantity Available	Price	Delay Time	Voltage - Supply	Power Supply Type	Switch Function/Rating	Mounting Type	Terminal Type	Contact Layout, Typical	Number of Macrocells	Operating Range	Voltage - Max	Current Rating (Max)	Depth	Width	Length	Number of Contacts	Voltage - Supply (Min)	Operating Mode	CAD Drawing	Weight	Range deg/s	Delay Time - OFF	Connector Type	Switch Type	Number of Timers	Operating Temperature	SVHC	Tariff No	Delay Time - ON	Voltage - Input (Max)	Series	Other Specifications	Timing Adjustment Method	Number of Units	Module/Board Type
3RP1505-1AW30 3RP1505-1AW30 250 V dc, 400 V ac 24-240VAC&VDCMULTI-FUNCTION(8)TIMER 西门子(SIEMENS) 时间继电器 Siemens	10	1: ¥1,257.98	Seconds	24 → 240 V ac/dc	External	SPDT	DIN Rail	Screw	NO/NC	Multi Function	1.5 → 30 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	1	24 V ac/dc	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1505-1BT20 3RP1505-1BT20 250 V dc, 400 V ac MULTI-FTIMER2SPDT,400-440V 西门子(SIEMENS) 时间继电器 Siemens	10	1: ¥448.936	Minutes	400 → 440 V ac	External	DPDT	DIN Rail	Screw	2NO/2NC	Multi Function	1.5 → 30 min	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1505-1BQ30 3RP1505-1BQ30 250 V dc, 400 V ac MULTI-FTIMER2SPDT,24V/120V 西门子(SIEMENS) 时间继电器 Siemens	5000	1: ¥1,258.00	Seconds	100 → 127 V ac, 24 V dc	External	DPDT	DIN Rail	Screw	2NO/2NC	Multi Function	5 → 100 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1505-1BW30 3RP1505-1BW30 250 V dc, 400 V ac MULTI-FTIMER2SPDT,24V/240V 西门子(SIEMENS) 时间继电器 Siemens	5000	1: ¥1,530.00	Minutes	24 → 240 V ac/dc	External	DPDT	DIN Rail	Screw	2NO/2NC	Multi Function	0.5 → 10 min	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1505-2AW30 3RP1505-2AW30 250 V dc, 400 V ac MULTI-FTIMER,CAGECLMP,AC/DC24V...240V 西门子(SIEMENS) 时间继电器 Siemens	10	1: ¥528.70	Seconds	24 → 240 V ac/dc	External	SPDT	DIN Rail	Spring	NO/NC	Multi Function	1.5 → 30 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	1	24 V ac/dc	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1525-1BQ30 3RP1525-1BQ30 250 V dc, 400 V ac 西门子(SIEMENS) 时间继电器 Siemens	5000	1: ¥809.20	Seconds	100 → 127 V ac, 24 V dc	External	DPDT	DIN Rail	Screw	2NO/2NC	Single	1.5 → 30 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	ON Delay	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1505-1AQ30 3RP1505-1AQ30 250 V dc, 400 V ac MULTI-FTIMER1SPDT,24V/120V 西门子(SIEMENS) 时间继电器 Siemens	5000	1: ¥1,072.02	Seconds	100 → 127 V ac, 24 V dc	External	SPDT	DIN Rail	Screw	NO/NC	Multi Function	0.15 → 3 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	1	24 V ac/dc	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1513-1AP30 3RP1513-1AP30 250 V dc, 400 V ac ON-DELAY,5-100S,24V/240V 西门子(SIEMENS) 时间继电器 Siemens	10	1: ¥574.124	Seconds	200 → 240 V ac, 24 V ac/dc	External	SPDT	DIN Rail	Screw	NO/NC	Single	5 → 100 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	1	24 V ac/dc	ON Delay	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1555-1AP30 3RP1555-1AP30 250 V dc, 400 V ac CLOCKPULSETIMER,24V/240V 西门子(SIEMENS) 时间继电器 Siemens	10	1: ¥1,256.00	Seconds	200 → 240 V ac, 24 V ac/dc	External	SP	DIN Rail	Screw	NO/NC	Single	0.5 → 10 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	1	24 V ac/dc	Clock Pulse	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1527-1EM30 3RP1527-1EM30 250 V dc, 400 V ac ON-DELAY,MULTIPLES,90-240V Siemens	164	1: ¥357.034	Seconds	90 → 240 V ac/dc	External	SPST	DIN Rail	Screw	NO	Single	0.2 → 4 s	250 V dc, 400 V ac	0.6 A	90mm	22.5mm	83mm	1	24 V ac/dc	ON Delay	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1576-1NP30 3RP1576-1NP30 250 V dc, 400 V ac Y-DTIMER,3-60S,24V/240V 西门子(SIEMENS) 时间继电器 Siemens	20	1: ¥4,352.00	Seconds	200 → 240 V ac, 24 V ac/dc	External	DP	DIN Rail	Screw	NO	Single	3 → 60 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	WYE Delta	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP15051BP30 Time Delay Relay Siemens 3RP15051BP30, 0.5 to 10s Screw SPDT TIMER, MULTIFUNCTION, 0.05S-100H, 240VAC Siemens	77	1: ¥759.9068	Seconds	200 → 240 V ac, 24 V ac, 24 V dc	External	SPDT	:DIN Rail	Screw	2NO/2NC	Multi Function	0.5 → 10 s	-	-	-	-	-	-	-	-	3D CAD Model	0.157	-	-	-	-	-	-	:No SVHC (19-Dec-2012)	85364900	:5s	:240V	:3RP15	:100h	:Screwdriver Slot	-	-
3RP20051AQ30 Time Delay Relay Siemens 3RP20051AQ30, 0.05 to 100, 0.05 to 100, 0.05 to 100s, h, min Screw SPDT 250V ac/dc Siemens PXW-2-24 多功能计时继电器, 0.05 → 100 s、0.05 → 100 h、0.05 → 100 min, 单刀双掷, 1触点, SPDT Siemens	10	1: ¥1,824.304	Hours, Minutes, Seconds	100 → 127 V ac, 24 V ac/dc	External	SPDT	DIN Rail	Screw	NO/NC	Multi Function	0.05 → 100 h, 0.05 → 100 min, 0.05 → 100 s	250 V ac/dc	1 (dc) A, 3 (ac) A	73mm	45mm	57mm	1	-	Additive ON Delay with Auxiliary Voltage, Flash Start with Interval, OFF Delay with Auxiliary Voltage, ON Delay, ON Delay and OFF Delay with Auxiliary Voltage, Passing Break Contact with Auxiliary Voltage, Passing Make Contact, Pulse Former with Auxiliary	3D CAD Model	-	0.05 → 100 s、0.05 → 100 h、0.05 → 100 min	小时，分钟，秒	螺钉	SPDT	多功能	+60°C	-	-	-	-	-	-	-	-	-
3RP1531-1AP30 3RP1531-1AP30 250 V dc, 400 V ac 西门子(SIEMENS) 时间继电器 Siemens	10	1: ¥423.844	Seconds	200 → 240 V ac, 24 V ac/dc	External	SPDT	DIN Rail	Screw	NO/NC	Single	0.5 → 10 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	1	24 V ac/dc	OFF Delay	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP20251AP30 Time Delay Relay Siemens 3RP20251AP30, 0.05 to 100, 0.05 to 100, 0.05 to 100h, min, s Screw SPDT 250V ac/dc Siemens ERS-8HP/C1006 单计时继电器, 0.05 → 100 s、0.05 → 100 h、0.05 → 100 min, 单刀双掷, 1触点, SPDT Siemens	14	1: ¥424.22	Hours, Minutes, Seconds	110 → 240 V ac, 24 V ac/dc	External	SPDT	DIN Rail	Screw	NO/NC	Single	0.05 → 100 h, 0.05 → 100 min, 0.05 → 100 s	250 V ac/dc	1 (dc) A, 3 (ac) A	73mm	45mm	57mm	1	-	ON Delay	3D CAD Model	-	0.05 → 100 s、0.05 → 100 h、0.05 → 100 min	小时，分钟，秒	螺钉	SPDT	单	+60°C	-	-	-	-	-	-	-	-	-
3RP1505-1RW30 3RP1505-1RW30 250 V dc, 400 V ac MULTI-FTIMERRELAY,AC/DC24V..240V 西门子(SIEMENS) 接线端子隔板 Siemens	10	1: ¥769.828	Seconds	24 → 240 V ac/dc	External	DPDT	DIN Rail	Screw	2NO/2NC	Multi Function	0.05 → 1 h	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1525-1AQ30 3RP1525-1AQ30 250 V dc, 400 V ac 西门子(SIEMENS) 时间继电器 Siemens	5000	1: ¥740.18	Seconds	100 → 127 V ac, 24 V dc	External	SPDT	DIN Rail	Screw	NO/NC	Single	0.05 → 1 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	1	24 V ac/dc	ON Delay	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
2 3RP1560-1SP30 3RP1560-1SP30 250 V dc, 400 V ac SSTIMERLY,W/STAR-DLTA,24VDC,200-240VAC 西门子(SIEMENS) 时间继电器 Timer; 24÷230VAC; 24VDC; Operation modes: star delta; DIN Siemens	5000	1: ¥1,533.128	Seconds	200 → 240 V ac, 24 V ac/dc	External	3P	DIN Rail	Screw	3NO	Single	1 → 20 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	3	24 V ac/dc	WYE Delta	-	0.16 kg	-	-	-	-	-	-	-	-	-	-	-	-	-	1	timer
3RP1525-1BP30 3RP1525-1BP30 250 V dc, 400 V ac 西门子(SIEMENS) 时间继电器 Siemens	5000	1: ¥809.20	Minutes	200 → 240 V ac, 24 V ac/dc	External	DPDT	DIN Rail	Screw	2NO/2NC	Single	0.05 → 1 min	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	ON Delay	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
3RP1574-1NQ30 3RP1574-1NQ30 250 V dc, 400 V ac Y-DTIMER,1-20S,24V/120V 西门子(SIEMENS) 时间继电器 Siemens	5000	1: ¥754.80	Seconds	100 → 127 V ac, 24 V dc	External	DP	DIN Rail	Screw	NO	Single	1 → 20 s	250 V dc, 400 V ac	1 (dc) A, 3 (ac) A	90mm	22.5mm	83mm	2	24 V ac/dc	WYE Delta	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
