Inductors

Talema Group- Inductors
03
Inductors - 型号列表
22 parts in total| Mfr Part # | Quantity Available | Price | Other Names | Standard Package | RoHS | Inductance | Test Frequency | DC Resistance (DCR) | Current Rating (Max) | Packaging | Shielding | Mounting Type | Package / Case | Size / Dimension | Type | Operating Temperature | Core Type | Resistance | Width | Weight | Diameter | Package Quantity | Spg | Number of Units | Application Specifics | Size | Series | Output Configuration |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 10 | 1: ¥14.824 | 1295-1161 | 125 | Lead free / RoHS Compliant | 220µH | 10kHz | 215 mOhm Max | 500mA | Tray | Unshielded | Through Hole | Radial | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | Toroidal | -40°C ~ 125°C | wire | 215mΩ | 9mm | 6.01 g | 15mm | 100 | 100 | 1 | EMI/RFI filters, switched mode power supplies | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | DP | Through Hole | |
| 119 | 1: ¥15.708 | 1295-1159 | 125 | Lead free / RoHS Compliant | 100µH | 10kHz | 140 mOhm Max | 500mA | Tray | Unshielded | Through Hole | Radial | 0.551" Dia x 0.315" W (14.00mm x 8.00mm) | Toroidal | -40°C ~ 125°C | wire | 140mΩ | 8mm | 5.58 g | 14mm | 100 | 100 | 1 | EMI/RFI filters, switched mode power supplies | 0.551" Dia x 0.315" W (14.00mm x 8.00mm) | DP | Through Hole | |
| 119 | 1: ¥16.252 | 1295-1165 | 125 | Lead free / RoHS Compliant | 150µH | 10kHz | 123 mOhm Max | 1A | Tray | Unshielded | Through Hole | Radial | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | Toroidal | -40°C ~ 125°C | wire | 123mΩ | 9mm | 6.96 g | 15mm | 258 | 258 | 1 | EMI/RFI filters, switched mode power supplies | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | DP | Through Hole | |
| 70 | 1: ¥16.592 | 1295-1169 | 70 | Lead free / RoHS Compliant | 150µH | 10kHz | 106 mOhm Max | 2A | Tray | Unshielded | Through Hole | Radial | 0.984" Dia x 0.472" W (25.00mm x 12.00mm) | Toroidal | -40°C ~ 125°C | - | - | - | - | - | - | - | - | - | - | - | - | |
| 14 | 1: ¥18.904 | 1295-1166 | 125 | Lead free / RoHS Compliant | 220µH | 10kHz | 196 mOhm Max | 1A | Tray | Unshielded | Through Hole | Radial | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | Toroidal | -40°C ~ 125°C | wire | 196mΩ | 9mm | 6.68 g | 15mm | 25 | 25 | 1 | EMI/RFI filters, switched mode power supplies | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | DP | Through Hole | |
| 791 | 1: ¥18.904 | 1295-1171 | 70 | Lead free / RoHS Compliant | 100µH | 10kHz | 80 mOhm Max | 3A | Tray | Unshielded | Through Hole | Radial | 0.984" Dia x 0.472" W (25.00mm x 12.00mm) | Toroidal | -40°C ~ 125°C | wire | 80mΩ | 12mm | 0.02 kg | 25mm | 40 | 40 | 1 | EMI/RFI filters, switched mode power supplies | 0.984" Dia x 0.472" W (25.00mm x 12.00mm) | DP | Through Hole | |
| 10 | 1: ¥18.02 | 1295-1162 | 125 | Lead free / RoHS Compliant | 330µH | 10kHz | 265 mOhm Max | 500mA | Tray | Unshielded | Through Hole | Radial | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | Toroidal | -40°C ~ 125°C | wire | 265mΩ | 9mm | 6.33 g | 15mm | 50 | 50 | 1 | EMI/RFI filters, switched mode power supplies | 0.591" Dia x 0.354" W (15.00mm x 9.00mm) | DP | Through Hole | |
| 460 | 1: ¥19.516 | 1295-1178 | 70 | Lead free / RoHS Compliant | 68µH | 10kHz | 55 mOhm Max | 5A | Tray | Unshielded | Through Hole | Radial | 1.024" Dia x 0.472" W (26.00mm x 12.00mm) | Toroidal | -40°C ~ 125°C | wire | 55mΩ | 12mm | 0.02 kg | 26mm | 100 | 100 | 1 | EMI/RFI filters, switched mode power supplies | 1.024" Dia x 0.472" W (26.00mm x 12.00mm) | DP | Through Hole | |
| 10 | 1: ¥18.564 | 1295-1172 | 70 | Lead free / RoHS Compliant | 150µH | 10kHz | 107 mOhm Max | 3A | Tray | Unshielded | Through Hole | Radial | 0.984" Dia x 0.472" W (25.00mm x 12.00mm) | Toroidal | -40°C ~ 125°C | wire | 107mΩ | 12mm | 0.02 kg | 25mm | 10 | 10 | 1 | EMI/RFI filters, switched mode power supplies | 0.984" Dia x 0.472" W (25.00mm x 12.00mm) | DP | Through Hole | |
| 95 | 1: ¥20.536 | 1295-1167 | 100 | Lead free / RoHS Compliant | 330µH | 10kHz | 193 mOhm Max | 1A | Tray | Unshielded | Through Hole | Radial | 0.787" Dia x 0.354" W (20.00mm x 9.00mm) | Toroidal | -40°C ~ 125°C | wire | 193mΩ | 9mm | 0.01 kg | 20mm | 100 | 100 | 1 | EMI/RFI filters, switched mode power supplies | 0.787" Dia x 0.354" W (20.00mm x 9.00mm) | DP | Through Hole | |
| 124 | 1: ¥20.944 | 1295-1160 | 125 | Lead free / RoHS Compliant | 150µH | 10kHz | 173 mOhm Max | 500mA | Tray | Unshielded | Through Hole | Radial | 0.591" Dia x 0.315" W (15.00mm x 8.00mm) | Toroidal | -40°C ~ 125°C | wire | 173mΩ | 8mm | 5.57 g | 15mm | 400 | 400 | 1 | EMI/RFI filters, switched mode power supplies | 0.591" Dia x 0.315" W (15.00mm x 8.00mm) | DP | Through Hole | |
| 10 | 1: ¥21.896 | 1295-1164 | 125 | Lead free / RoHS Compliant | 100µH | 10kHz | 97 mOhm Max | 1A | Tray | Unshielded | Through Hole | Radial | 0.591" Dia x 0.315" W (15.00mm x 8.00mm) | Toroidal | -40°C ~ 125°C | wire | 97mΩ | 8mm | 6.11 g | 15mm | 200 | 200 | 1 | EMI/RFI filters, switched mode power supplies | 0.591" Dia x 0.315" W (15.00mm x 8.00mm) | DP | Through Hole | |
| 10 | 1: ¥23.732 | 1295-1174 | 50 | Lead free / RoHS Compliant | 220µH | 10kHz | 134 mOhm Max | 3A | Tray | Unshielded | Through Hole | Radial | 1.142" Dia x 0.512" W (29.00mm x 13.00mm) | Toroidal | -40°C ~ 125°C | wire | 134mΩ | 13mm | 0.04 kg | 29mm | 60 | 60 | 1 | EMI/RFI filters, switched mode power supplies | - | - | - | |
| 10 | 1: ¥25.704 | 1295-1177 | 50 | Lead free / RoHS Compliant | 100µH | 10kHz | 59 mOhm Max | 5A | Tray | Unshielded | Through Hole | Radial | 1.181" Dia x 0.512" W (30.00mm x 13.00mm) | Toroidal | -40°C ~ 125°C | wire | 59mΩ | 13mm | 0.04 kg | 30mm | 100 | 100 | 1 | EMI/RFI filters, switched mode power supplies | 1.181" Dia x 0.512" W (30.00mm x 13.00mm) | DP | Through Hole | |
| 10 | 1: ¥28.696 | 1295-1175 | 50 | Lead free / RoHS Compliant | 330µH | 10kHz | 142 mOhm Max | 3A | Tray | Unshielded | Through Hole | Radial | 1.181" Dia x 0.551" W (30.00mm x 14.00mm) | Toroidal | -40°C ~ 125°C | wire | 142mΩ | 14mm | 0.04 kg | 30mm | 50 | 50 | 1 | EMI/RFI filters, switched mode power supplies | 1.181" Dia x 0.551" W (30.00mm x 14.00mm) | DP | Through Hole | |
| 93 | 1: ¥16.184 | 1295-1173 | 100 | Lead free / RoHS Compliant | 22µH | 10kHz | 50 mOhm Max | 3A | Tray | Unshielded | Through Hole | Radial | 0.551" Dia x 0.315" W (14.00mm x 8.00mm) | Toroidal | -40°C ~ 125°C | wire | 50mΩ | 8mm | 5.77 g | 14mm | 50 | 50 | 1 | EMI/RFI filters, switched mode power supplies | 0.551" Dia x 0.315" W (14.00mm x 8.00mm) | DP | Through Hole | |
| 80 | 1: ¥19.992 | 1295-1168 | 100 | Lead free / RoHS Compliant | 100µH | 10kHz | 109 mOhm Max | 2A | Tray | Unshielded | Through Hole | Radial | 0.748" Dia x 0.315" W (19.00mm x 8.00mm) | Toroidal | -40°C ~ 125°C | - | - | - | - | - | - | - | - | - | - | - | - | |
| 99 | 1: ¥20.468 | 1295-1176 | 100 | Lead free / RoHS Compliant | 47µH | 10kHz | 212 mOhm Max | 3A | Tray | Unshielded | Through Hole | Radial | 0.787" Dia x 0.315" W (20.00mm x 8.00mm) | Toroidal | -40°C ~ 125°C | wire | 48mΩ | 8mm | 0.01 kg | 20mm | 20 | 20 | 1 | EMI/RFI filters, switched mode power supplies | 0.787" Dia x 0.315" W (20.00mm x 8.00mm) | DP | Through Hole | |
| 91 | 1: ¥21.42 | 1295-1163 | 100 | Lead free / RoHS Compliant | 470µH | 10kHz | 322 mOhm Max | 500mA | Tray | Unshielded | Through Hole | Radial | 0.787" Dia x 0.354" W (20.00mm x 9.00mm) | Toroidal | -40°C ~ 125°C | wire | 322mΩ | 9mm | 0.01 kg | 20mm | 100 | 100 | 1 | EMI/RFI filters, switched mode power supplies | 0.787" Dia x 0.354" W (20.00mm x 9.00mm) | DP | Through Hole | |
| 99 | 1: ¥21.896 | 1295-1170 | 100 | Lead free / RoHS Compliant | 68µH | 10kHz | 89 mOhm Max | 2A | Tray | Unshielded | Through Hole | Radial | 0.591" Dia x 0.315" W (15.00mm x 8.00mm) | Toroidal | -40°C ~ 125°C | - | - | - | - | - | - | - | - | - | - | - | - |
Page 1 / 2
