AAAF5060 standard leds - smd Series - Part List, Specs & Da…

The AAAF5060 series from Kingbright is a line of Surface Mount Device (SMD) LEDs that come in both RGB and full color variants. These LEDs are commonly used in a variety of electronic projects and systems, including LED lighting, signage, and display panels. If you're working on any application that requires high-quality, compact lighting solutions, these SMD LEDs are a solid choice.

One thing worth noting is their efficiency. Given their SMD design, they offer excellent thermal management, which is crucial for maintaining brightness and longevity in densely packed circuits. Engineers tend to reach for these LEDs when they need a reliable, small form factor light source that can be easily integrated into tight spaces without compromising performance.

Another practical aspect is their wide color range, which makes them versatile for creating dynamic lighting effects or color-changing displays. Whether you're building a custom LED strip, a digital sign, or an interactive display, the AAAF5060 series provides the flexibility needed to achieve the desired visual output. Their robust construction also ensures durability under various operating conditions, making them a go-to component for many projects.

Mfr Part #	Quantity Available	Price	Category	Product Category	RoHS	Optic Size	Viewing Angle	LED Forward Current	Wavelength - Dominant	Packaging	Package / Case	Other Names	Standard Package	Current - Output	Voltage - Supply	Wavelength - Peak	Millicandela Rating	Color	Height	Mounting Type	Lens Style/Size	Size / Dimension	Lens Type	Mechanical Life	Power - Rated	LED Forward Voltage	Illumination Color	Operating Temperature	Luminous Flux @ Current/Temperature	Factory Pack Quantity	Lens Color
AAAF5060QBFSEEZGS Standard LEDs - SMD RGB 621/525/465nm 1300/1000/400mcd Kingbright	2067	1: ¥12.648	-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100 deg	20 mA	621 nm, 525 nm, 465 nm	Reel	6 mm x 5 mm x 2.3 mm	-	-	-	-	-	-	-	-	-	-	-	-	-	350 mW	2 V, 3.3 V, 3.3 V	RGB	+ 85 C	1300 mcd, 1000 mcd, 400 mcd	-	Water Clear
4 AAAF5060QBDZGSEEC Standard LEDs - SMD RGB Full Color LED 5.0X6.0MM BL/GRN/ORG CLR SMD Kingbright	10	1: ¥9.589	-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100 deg	20 mA	470 nm, 525 nm, 621 nm	Reel	6 mm x 5 mm x 2.3 mm	754-1329-2	500	50mA, 30mA, 30mA	2V Red, 3.3V Green, 3.3V Blue	630nm, 515nm, 468nm	1000mcd Orange, 650mcd Green, 250mcd Blue	Red, Green, Blue (RGB)	2.30mm	Surface Mount	Round with Flat Top, 4mm	5.00mm L x 6.00mm W	Clear	End of Life: Scheduled for obsolescence and will be discontinued by the manufacturer.	350 mW	3.3 V, 3.3 V, 2 V	RGB	+ 85 C	250 mcd, 650 mcd, 1000 mcd	500	-
AAAF5060QBDZGSEES Standard LEDs - SMD RGB 621/525/470nm 1300/1000/250mcd LED RGB ROUND CLEAR SMD Kingbright	270	1: ¥17.376	-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100 deg	20 mA	621 nm, 525 nm, 470 nm	Tape & Reel (TR)	6 mm x 5 mm x 2.3 mm	754-1510-2	500	50mA, 30mA, 30mA	2V Red, 3.3V Green, 3.3V Blue	630nm, 515nm, 468nm	1300mcd Red, 1000mcd Green, 250mcd Blue	Red, Green, Blue (RGB)	2.30mm	Surface Mount	Round with Flat Top, 4mm	6.00mm L x 5.00mm W	Clear	-	350 mW	2 V, 3.3 V, 3.3 V	RGB	+ 85 C	1300 mcd, 1000 mcd, 250 mcd	-	Water Clear
AAAF5060QBFSURZGS Standard LEDs - SMD RGB 630/525/465nm 800/1000/400mcd LED RGB ROUND CLEAR SMD Kingbright	4500	500: ¥5.6413	-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100°	20 mA	630nm, 525nm, 465nm	Tape & Reel (TR)	6 mm x 5 mm x 2.3 mm	754-1509-2	500	50mA, 30mA, 30mA	1.9V Red, 3.3V Green, 3.3V Blue	650nm, 515nm, 461nm	800mcd Red, 1000mcd Green, 400mcd Blue	Red, Green, Blue (RGB)	2.30mm	Surface Mount	Round with Flat Top, 4mm	6.00mm L x 5.00mm W	Clear	-	-	-	-	-	-	-	-
AAAF5060BESEEVGA Standard LEDs - SMD CHAMELEON FULL COLOR Kingbright	0		-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100 deg	20 mA	470 nm, 621 nm, 525 nm	Reel	6 mm x 5 mm x 2.3 mm	-	-	-	-	-	-	-	-	-	-	-	-	Obsolete	-	3.7 V, 2 V, 3.2 V	Orange, Green, Blue	+ 85 C	250 mcd, 1000 mcd, 350 mcd	500	Water Clear
4 AAAF5060PBESEEVGEC Standard LEDs - SMD RGB Full Color LED 5.0X6.0MM BL/GRN/ORG CLR SMD Kingbright	10	1: ¥13.94	-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100°	20 mA	470 nm, 621 nm, 525 nm	Reel	6 mm x 5 mm x 2.3 mm	754-1328-2	500	30mA, 30mA, 50mA	3.2V Blue, 3.2V Green, 2V Orange	468nm, 520nm, 630nm	250mcd Blue, 600mcd Green, 1000mcd Orange	Blue, Green, Orange	2.30mm	Surface Mount	Round with Flat Top, 4mm	5.00mm L x 6.00mm W	Clear	Obsolete	350 mW	-	-	-	-	100	-
4 AAAF5060PBESURVGEC Standard LEDs - SMD RGB Full Color LED 5.0X6.0MM RGB CLR SMD Kingbright	10	1000: ¥5.95	-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100 deg	20 mA	470 nm, 628 nm, 525 nm	Reel	6 mm x 5 mm x 2.3 mm	754-1332-2	500	50mA, 30mA, 30mA	1.9V Red, 3.2V Green, 3.2V Blue	640nm, 520nm, 468nm	500mcd Red, 600mcd Green, 250mcd Blue	Red, Green, Blue (RGB)	2.30mm	Surface Mount	Round with Flat Top, 4mm	5.00mm L x 6.00mm W	Clear	Obsolete	350 mW	3.2 V, 1.9 V, 3.2 V	RGB	+ 85 C	250 mcd, 500 mcd, 600 mcd	500	-
4 AAAF5060QBFSURZGC Standard LEDs - SMD RGB 630/525/465nm 500/650/330 mcd LED RED/GREEN/BLUE WTR CLEAR SMD Kingbright	10	1000: ¥4.6444	-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100°	20 mA	630nm, 525nm, 465nm	Tape & Reel (TR)	6 mm x 5 mm x 2.3 mm	754-1494-2	500	50mA, 30mA, 30mA	1.9V Red, 3.3V Green, 3.3V Blue	650nm, 515nm, 461nm	500mcd Red, 650mcd Green, 350mcd Blue	Red, Green, Blue (RGB)	2.30mm	Surface Mount	Round with Flat Top, 4mm	6.00mm L x 5.00mm W	Clear	Obsolete	-	-	-	-	-	-	-
4 AAAF5060QBFSEEZGC Standard LEDs - SMD RGB 621/525/465nm 1000/650/350 mcd LED RED/GREEN/BLUE WTR CLEAR SMD Kingbright	0		-	Standard LEDs - SMD	RoHS Compliant	6 mm x 5 mm x 2.3 mm	100°	20 mA	621nm, 525nm, 465nm	Cut Tape (CT)	6 mm x 5 mm x 2.3 mm	754-1495-1	1	50mA, 30mA, 30mA	2V Red, 3.3V Green, 3.3V Blue	630nm, 515nm, 461nm	1000mcd Red, 650mcd Green, 350mcd Blue	Red, Green, Blue (RGB)	2.30mm	Surface Mount	Round with Flat Top, 4mm	6.00mm L x 5.00mm W	Clear	Obsolete	-	-	-	-	-	-	-
