APA1606 standard leds - smd Series - Part List, Specs & Dat…

The APA1606 LED series from Kingbright is a standard surface-mount device (SMD) LED that comes in a variety of colors and specifications, making it a versatile choice for a wide range of applications. If you're working on lighting projects, automotive interiors, or any system requiring small, bright, and color-specific LEDs, these are a solid option. One thing worth noting is their excellent light output for their size, which makes them ideal for densely packed arrays or areas where space is limited. Engineers tend to reach for this when they need a reliable, high-performance LED that fits into tight spaces without compromising on brightness or color quality. They are also quite durable, which is crucial for environments where LEDs might be subjected to mechanical stress or harsh conditions. Another practical use case is in RGB lighting solutions, where the ability to switch between different colors on demand is essential. Overall, if you're looking for a dependable SMD LED that can handle a variety of tasks, the APA1606 from Kingbright is definitely worth considering.

Mfr Part #	Quantity Available	Price	Category	RoHS	Optic Size	Power - Rated	Viewing Angle	LED Forward Current	LED Forward Voltage	Lens Color	Package / Case	Illumination Color	Operating Temperature	Luminous Flux @ Current/Temperature	Product Category	Factory Pack Quantity	Wavelength - Dominant	Packaging	Standard Package	Current - Output	Voltage - Supply	Wavelength - Peak	Millicandela Rating	Color	Height	Mounting Type	Lens Style/Size	Size / Dimension	Lens Type	Other Names	Luminous Flux	Current - Peak Pulse (10/1000us)	Contact Finish	Mounting Style	Mechanical Life	Current Rating (Max)	MSCP (Mean Spherical Candle Power)	Size	Output Configuration
5 APA1606ZGC Standard LEDs - SMD Green 525nm Water Clear 250mcd LED 1.6X0.6MM 525NM GRN RA SMD 1.6X0.6MMGREENSMDLED,SMDLED,T&R Kingbright	14000	2000: ¥1.4586	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	10.2 5 mW	110 deg	20 mA	3.3 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Green	+ 85 C	400 mcd	Standard LEDs - SMD	2000	525 nm	Reel	2,000	20mA	3.3V	515nm	250mcd	Green	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.2mm x 0.6mm	1.60mm L x 1.20mm W	Clear	754-1056-2	250mcd	25mA	Transparent	SurfaceMount	-	20mA	250mcd	1.60mm L x 1.20mm W	Surface Mount, Right Angle
5 APA1606SYCK Standard LEDs - SMD Yellow 590nm Water Clear 150mcd LED 1.6X0.6MM 590NM YLW RA SMD 1.6X0.6MMYELLOWSMDLED,SMDLED,T&R Kingbright	14171	1: ¥1.632	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	75 mW	110 deg	20 mA	2 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Yellow	+ 85 C	150 mcd	Standard LEDs - SMD	2000	590 nm	Reel	2,000	20mA	2V	590nm	150mcd	Yellow	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.2mm x 0.6mm	1.60mm L x 1.20mm W	Clear	754-1055-2	150mcd	30mA	Transparent	SurfaceMount	-	-	-	-	-
5 APA1606SURCK Standard LEDs - SMD Red 630nm Water Clear 250mcd LED 1.6X0.6MM 630NM RED RA SMD 1.6X0.6MMREDSMDLED,SMDLED,T&R Kingbright	5976	90: ¥0.6233	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	75 mW	110 deg	20 mA	1.95 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Red	+ 85 C	220 mcd	Standard LEDs - SMD	2000	630 nm	Reel	2,000	20mA	1.95V	650nm	250mcd	Red	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.2mm x 0.6mm	1.60mm L x 1.20mm W	Clear	754-1054-2	250mcd	30mA	Transparent	SurfaceMount	-	-	-	-	-
5 APA1606SECK Standard LEDs - SMD Red 601nm Water Clear 250mcd LED 1.6X0.6MM 601NM ORN RA SMD 1.6X0.6MMORANGESMDLED,SMDLED,T&R Kingbright	6998	1: ¥1.632	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	75 mW	110 deg	20 mA	2.1 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Orange	+ 85 C	250 mcd	Standard LEDs - SMD	2000	601 nm	Reel	2,000	20mA	2.1V	610nm	250mcd	Orange	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.2mm x 0.6mm	1.60mm L x 1.20mm W	Clear	754-1053-2	250mcd	30mA	Transparent	SurfaceMount	-	-	-	-	-
4 APA1606QBC/D Standard LEDs - SMD Blue 470nm Water Clear 90mcd LED 1.6X0.6 470NM BL WTR CLR SMD 1.6X0.6MMBLUESMDLED,SMDLED,T&R Kingbright	30000	2000: ¥0.8078	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	120 mW	110 deg	20 mA	3.3 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Blue	+ 85 C	90 mcd	Standard LEDs - SMD	2000	470 nm	Reel	2,000	20mA	3.3V	468nm	90mcd	Blue	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.2mm x 0.6mm	1.60mm L x 1.20mm W	Clear	754-1424-1	90mcd	30mA	Transparent	SurfaceMount	-	-	-	-	-
APA1606MGC Standard LEDs - SMD Green 570nm Water Clear 80mcd Kingbright	3860	1: ¥3.40	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	75 mW	110 deg	20 mA	2.1 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Green	+ 85 C	80 mcd	Standard LEDs - SMD	2000	570 nm	Reel	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
5 APA1606CGCK Standard LEDs - SMD Green 570nm Water Clear 60mcd LED 1.6X0.6MM RA 570NM GRN SMD 1.6X0.6MMGREENSMDLED,SMDLED,T&R Kingbright	538	1: ¥1.19	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	75 mW	110 deg	20 mA	2.1 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Green	+ 85 C	60 mcd	Standard LEDs - SMD	2000	570 nm	Reel	2,000	20mA	2.1V	574nm	60mcd	Green	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.2mm x 0.6mm	1.60mm L x 1.20mm W	Clear	754-1051-2	60mcd	30mA	Transparent	SurfaceMount	-	-	-	-	-
APA1606SGC Standard LEDs - SMD RA Grn 568nm 15mcd 110deg Water Clr LED RA 565NM GRN 1.6X1.0MM SMD Kingbright	4375	1: ¥1.564	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	62.5 mW	110 deg	20 mA	2.2 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Green	+ 85 C	15 mcd	Standard LEDs - SMD	2000	568 nm	Reel	2,000	20mA	2.2V	565nm	15mcd	Green	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.6mm x 0.6mm	1.60mm L x 1.20mm W	Clear	-	-	-	-	-	-	-	-	-	-
APA1606QWF/G Standard LEDs - SMD Kingbright	10	900: ¥3.3184	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	120 mW	110 deg	20 mA	3.3 V	Yellow Fluorescent	1.6 mm x 1.2 mm x 0.6 mm	White	+ 85 C	350 mcd	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
APA1606VGC/A Standard LEDs - SMD Green 525nm Water Clear 180mcd Kingbright	0		-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	120 mW	110 deg	20 mA	3.2 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Green	+ 85 C	180 deg	Standard LEDs - SMD	2000	525 nm	Reel	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Obsolete	-	-	-	-
4 APA1606PBC/A Standard LEDs - SMD Blue 470nm Water Clear 60mcd LED 1.6X0.6MM 470NM BLUE RA SMD Kingbright	10	2000: ¥1.1356	-	RoHS Compliant	1.6 mm x 1.2 mm x 0.6 mm	120 mW	110 deg	20 mA	3.2 V	Water Clear	1.6 mm x 1.2 mm x 0.6 mm	Blue	+ 85 C	60 mcd	Standard LEDs - SMD	2000	470 nm	Reel	2,000	20mA	3.2V	468nm	60mcd	Blue	0.60mm	Surface Mount, Right Angle	Rectangle with Flat Top, 1.2mm x 0.6mm	1.60mm L x 1.20mm W	Clear	754-1052-2	-	-	-	-	Obsolete	-	-	-	-
APA1606PYC 1.6X0.6MM YELLOW SMD LED with 110° viweing angle KINGBRIGHT	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
APA1606ZGCK KINGBRIGHT	0		-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
