cigen-APSK2R5ELL
APSK2R5ELL polymer capacitor Series
Aluminum capacitors for 2.5V applications
The APSK2R5ELL series from Nippon Chemi-Con Corporation is a lineup of aluminum polymer film capacitors designed specifically for 2.5V applications. These capacitors are commonly found in a variety of low-voltage circuits, particularly in power supplies, decoupling, and filtering applications within consumer electronics, telecommunications equipment, and automotive systems.
One thing worth noting is their reliability and stability over a wide temperature range, making them ideal for use in environments that experience significant temperature fluctuations. Engineers tend to reach for these capacitors when they need components that can handle lower voltages with high capacitance values while maintaining good ESR (Equivalent Series Resistance) performance. They offer a balance between cost and performance, which is crucial in many cost-sensitive designs. Additionally, the polymer film construction provides excellent stability and low leakage current, which is beneficial in precision circuits. If you're working on projects that require reliable operation under varying conditions and don't need the high voltage ratings of traditional aluminum electrolytic capacitors, the APSK2R5ELL series is definitely worth considering.
Series Images (1)
Documents & Media
Frequently Asked Questions
APSK2R5ELL polymer capacitor - Part List
6 parts in total| Mfr Part # | Quantity Available | Price | Category | Product | Tradename | Product Category | RoHS | Tolerance | Capacitance | Voltage Rating | Dissipation Factor (DF) | Ripple Current @ High Frequency | ESR (Equivalent Series Resistance) | Diameter | Packaging | Lead Spacing | Package / Case | Termination Style | Series | Product Type | Rated Life | Operating Temperature | Rad Hardened | Voltage | DC Cold Resistance | Depth | Height | Mounting Style | Length - Overall | Diameter - Small Outside | Type | Failure Rate | Electrical Life |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
APSK2R5ELL471ME08S CAP ALUM 470UF 2.5V 20% RADIAL Aluminum Organic Polymer Capacitors 2.5Volts 470uF 0.2 Cap Aluminum 470uF 2.5V 20% (5 X 8mm) Radial 2mm 0.007 Ohm 4350mA 5000h 105C Bulk Cap Aluminum 470uF 2.5V 20% (5 X 8mm) Radial 2mm 0.007 Ohm 4350mA 5000h 105°C Bulk United Chemi-Con | 1000 | 1: ¥10.132 | - | Organic Polymer Aluminum - Radial Capacitors | NPCap | Aluminum Organic Polymer Capacitors | RoHS Compliant | 20 % | 470 uF | 2.5 V | 0.1 | 4350 mA | 7 mOhms | 5 mm | Bulk | 2 mm | 8 mm | Radial | PSK | Can | 5000 h | - 55 C to + 105 C | No | 2.5VDC | 500 uA | Not Required mm | 8 mm | Through Hole | Not Required mm | 0.45 mm | Polymer | Not Required | 5000 hr |
APSK2R5ELL561ME08S CAP ALUM 560UF 2.5V 20% RADIAL Aluminum Organic Polymer Capacitors 2.5Volts 560uF 0.2 Cap Aluminum 560uF 2.5V 20% (5 X 8mm) Radial 2mm 0.007 Ohm 4350mA 5000h 105C Bulk Cap Aluminum 560uF 2.5V 20% (5 X 8mm) Radial 2mm 0.007 Ohm 4350mA 5000h 105°C Bulk United Chemi-Con | 4198 | 1: ¥2.2576 | - | Organic Polymer Aluminum - Radial Capacitors | NPCap | Aluminum Organic Polymer Capacitors | RoHS Compliant | 20 % | 560 uF | 2.5 V | 0.1 | 4350 mA | 7 mOhms | 5 mm | Bulk | 2 mm | 8 mm | Radial | PSK | Can | 5000 h | - 55 C to + 105 C | No | 2.5VDC | 500 uA | Not Required mm | 8 mm | Through Hole | Not Required mm | 0.45 mm | Polymer | Not Required | 5000 hr |
APSK2R5ELL221ME08S CAP ALUM 220UF 2.5V 20% RADIAL Aluminum Organic Polymer Capacitors 2.5Volts 220uF 0.2 Cap Aluminum 220uF 2.5V 20% (5 X 8mm) Radial 2mm 0.007 Ohm 4350mA 5000h 105°C Bulk United Chemi-Con | 1000 | 1: ¥2.2304 | - | Organic Polymer Aluminum - Radial Capacitors | NPCap | Aluminum Organic Polymer Capacitors | RoHS Compliant | 20 % | 220 uF | 2.5 V | 0.1 | 4350 mA | 7 mOhms | 5 mm | Bulk | 2 mm | 8 mm | Radial | PSK | Can | 5000 h | - 55 C to + 105 C | - | - | - | - | - | - | - | - | - | - | - |
APSK2R5ELL331ME08S CAP ALUM 330UF 2.5V 20% RADIAL Aluminum Organic Polymer Capacitors 2.5Volts 330uF 0.2 Cap Aluminum 330uF 2.5V 20% (5 X 8mm) Radial 2mm 0.007 Ohm 4350mA 5000h 105°C Bulk United Chemi-Con | 10 | 1: ¥2.8608 | - | Organic Polymer Aluminum - Radial Capacitors | NPCap | Aluminum Organic Polymer Capacitors | RoHS Compliant | 20 % | 330 uF | 2.5 V | 0.1 | 4350 mA | 7 mOhms | 5 mm | Bulk | 2 mm | 8 mm | Radial | PSK | Can | 5000 h | - 55 C to + 105 C | - | - | - | - | - | - | - | - | - | - | - |
| 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | ||
| 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
