APV-35 optoelectronic Series

The APV-35 series from MEAN WELL is a line of power supplies specifically designed for driving LEDs. These units offer a range of voltages and currents to accommodate different LED requirements, making them versatile for a variety of lighting applications. If you're working on commercial lighting projects, such as retail displays or office environments, these power supplies can be a great fit due to their flexibility and efficiency.

One thing worth noting is the series' ability to handle a wide range of input voltages, which is crucial in environments where the mains voltage might fluctuate. This feature ensures consistent performance across different geographical locations. Additionally, engineers tend to reach for this when they need a reliable solution that can handle high current demands without overheating or causing issues with the LED lifespan. The APV-35 series is particularly useful in scenarios where thermal management is critical, as it includes features like forced-air cooling to maintain optimal operating temperatures.

Mfr Part #	Quantity Available	Price	Category	Product	Product Category	RoHS	Protection	Input	Noise	Output	Operation	Efficiency	Power - Max	Output Power	Power (Watts)	Power - Rated	Operating Mode	Voltage Rating	Line Regulation	Load Regulation	Current - Output	Voltage - Supply	Number of Outputs	Power Supply Type	Current Rating (Max)	Voltage - Input (Min)	Current - Output / Channel	Depth	Width	Length	Weight	Size - Body	Cable Length	Mounting Style	Package Quantity	Panel Mount Type	Size / Dimension	Type	Series	Features	Application	Stock Status	Electrical Life	Number of Units	Application Specifics	Operate Time	Ingress Protection	Operating Temperature	Maximum Temperature Limit	Power - Output	Mounting Type	Primary Material	Manufacturer	Configuration
4 APV-35-15 LED Driver, 15V, 2.4A Power Supply, 36W LED Drivers Power Supplies 36W 15V 2.4A CV LED PS AC/DC Power Supply Single-OUT 15V 2.4A 36W 4-Pin Pwr sup.unit: pulse; for LED diodes; 36W; 15VDC; 2.4A; 90÷264VAC APV-35-15 from Mean Well, 35 Watt, Single Output Mean Well LED 驱动器 , 15V, 2.4A, 36W Mean Well	18	1: ¥78.472	-	Switching Supplies	LED Drivers Power Supplies	RoHS Compliant	overload, voltage growth	90-264 VAC	150mV Pk-Pk	15.0V @ 2.40A	恒定电压	84%	36W	36 W	35 W	36W	Constant Voltage (CV)	127 → 370 V dc, 90 → 264 V ac	±1%	±2%	2.4A	90...264V AC, 127...370V DC	1	pulse	2.4A	15 V	2.4 A	29.5mm	57mm	84mm	0.18kg	84 x 57 x 29.5mm	150mm	Chassis	PLASTIC3.31 x 2.24 x 1.16"	Enclosed	84 mm L x 57 mm W x 29.5 mm H	Switch Mode	APV-35	rated parameters obtained at full load	Commercial	109	150mm wires	1	for LED diodes	692.8kh	IP30	-30°C	+70°C	-	-	-	-	-
4 APV-35-24 LED Driver, 24V, 1.5A Power Supply, 36W LED Drivers Power Supplies 36W 24V 1.5A CV LED PS AC/DC Power Supply Single-OUT 24V 1.5A 36W 4-Pin Power Supply; AC-DC; 24V@1.5A; 100-264V In; Enclosed; Panel Mount; APV Series Pwr sup.unit: pulse; for LED diodes; 36W; 24VDC; 1.5A; 90÷264VAC APV-35-24 from Mean Well, 35 Watt, Single Output Mean Well LED 驱动器 , 24V, 1.5A, 36W Mean Well	112	1: ¥78.472	-	Switching Supplies	LED Drivers Power Supplies	RoHS Compliant	overload, voltage growth	90-264 VAC	180mV Pk-Pk	24VDC@1.5A	Switching	84%	36W	36 W	35 W	36W	Constant Voltage (CV)	127 → 370 V dc, 90 → 264 V ac	±1%	±2%	1.5A	90...264V AC, 127...370V DC	1	pulse	1.5A	24 V	1.5 A	29.5mm	57mm	84mm	0.18kg	84 x 57 x 29.5mm	150mm	Chassis	PLASTIC3.31 x 2.24 x 1.16"	Enclosed	84 mm L x 57 mm W x 29.5 mm H	Switch Mode	APV-36	rated parameters obtained at full load	Commercial	50	150mm wires	1	for LED diodes	692.8kh	IP30	-30°C	+70°C	36 W	Panel	AC-DC	APV Series	Enclosed
4 APV-35-12 LED Driver, 12V, 3A Power Supply, 36W LED Drivers Power Supplies 36W 12V 3A CV LED PS AC/DC Power Supply Single-OUT 12V 3A 36W 4-Pin Power Supply; AC-DC; 12V@3A; 100-264V In; Enclosed; Panel Mount; APV Series Pwr sup.unit: pulse; for LED diodes; 36W; 12VDC; 3A; 90÷264VAC APV-35-12 from Mean Well, 35 Watt, Single Output Mean Well LED 驱动器 , 12V, 3A, 36W Mean Well	561	1: ¥78.472	-	Switching Supplies	LED Drivers Power Supplies	RoHS Compliant	overload, voltage growth	90-264 VAC	150mV Pk-Pk	12VDC@3A	Switching	83%	36W	36 W	35 W	36W	Constant Voltage (CV)	127 → 370 V dc, 90 → 264 V ac	±1%	±2%	3A	90...264V AC, 127...370V DC	1	pulse	3A	12 V	3 A	29.5mm	57mm	84mm	0.18kg	84 x 57 x 29.5mm	150mm	Chassis	PLASTIC3.31 x 2.24 x 1.16"	Enclosed	84 mm L x 57 mm W x 29.5 mm H	Switch Mode	APV-36	rated parameters obtained at full load	Commercial	43	150mm wires	1	for LED diodes	692.8kh	IP30	-30°C	+70°C	36 W	Panel	AC-DC	APV Series	Enclosed
4 APV-35-36 LED Driver, 36V, 1A Power Supply, 36W LED Drivers Power Supplies 36W 36V 1A CV LED PS Pwr sup.unit: pulse; for LED diodes; 36W; 36VDC; 1A; 90÷264VAC APV-35-36 from Mean Well, 35 Watt, Single Output Mean Well LED 驱动器 , 36V, 1A, 36W Mean Well	90	1: ¥76.16	-	Switching Supplies	LED Drivers Power Supplies	RoHS Compliant	overload, voltage growth	90-264 VAC	180mV Pk-Pk	36.0V @ 1.00A	恒定电压	85%	36W	36 W	35 W	36W	Constant Voltage (CV)	127 → 370 V dc, 90 → 264 V ac	±1%	±2%	1A	90...264V AC, 127...370V DC	1	pulse	1A	36 V	1 A	29.5mm	57mm	84mm	0.18kg	84 x 57 x 29.5mm	150mm	Chassis	PLASTIC3.31 x 2.24 x 1.16"	Enclosed	84 mm L x 57 mm W x 29.5 mm H	Switch Mode	APV-35	rated parameters obtained at full load	Commercial	23	150mm wires	1	for LED diodes	692.8kh	IP30	-30°C	+70°C	-	-	-	-	-
4 APV-35-5 LED Driver, 5V, 5A Power Supply, 25W LED Drivers Power Supplies 25W 5V 5A CV LED PS AC/DC Power Supply Single-OUT 5V 5A 25W 4-Pin Pwr sup.unit: pulse; for LED diodes; 25W; 5VDC; 5A; 90÷264VAC; IP30 APV-35-5 from Mean Well, 35 Watt, Single Output Mean Well LED 驱动器 , 5V, 5A, 25W Mean Well	33	1: ¥89.828	-	Switching Supplies	LED Drivers Power Supplies	RoHS Compliant	overload, voltage growth	90-264 VAC	120mV Pk-Pk	5.0V @ 5.00A	恒定电压	76.5%	25W	25 W	35 W	25W	Constant Voltage (CV)	127 → 370 V dc, 90 → 264 V ac	±1%	±2%	5A	90...264V AC, 127...370V DC	1	pulse	5A	5 V	5 A	29.5mm	57mm	84mm	0.18kg	84 x 57 x 29.5mm	150mm	Chassis	PLASTIC3.31 x 2.24 x 1.16"	Enclosed	84 mm L x 57 mm W x 29.5 mm H	Switch Mode	APV-36	rated parameters obtained at full load	Commercial	85	150mm wires	1	for LED diodes	692.8kh	IP30	-30°C	+70°C	-	-	-	-	-
