cigen-BRC1608T
BRC1608T passive component Series
taiyo-yudenSMD 0603 wirewound inductors for various applications
The BRC1608T series from TAIYO YUDEN is a lineup of surface mount device (SMD) 0603 wirewound inductors designed for a wide range of electronic circuits. These components are particularly useful in power supply designs, RF circuits, and filter applications where precise inductance values are required.
If you're working on a project that demands high-frequency stability and low loss, these inductors are a great choice. They offer excellent temperature characteristics, making them suitable for both high-temperature and high-reliability environments. Engineers tend to reach for this type of component when they need to implement a stable and reliable inductor in tight spaces, which is common in mobile devices, automotive electronics, and industrial control systems.
One thing worth noting is their compact size. Despite being small, they can handle significant current, thanks to their wirewound design. This makes them ideal for applications where space is at a premium but performance isn't compromised. Another practical benefit is their ability to maintain consistent inductance over time, which is crucial for maintaining circuit performance in long-term deployments.
Overall, the BRC1608T series is a solid addition to any engineer’s toolkit, especially when precision and reliability are key factors in the design.
Series Images (7)
Documents & Media
Frequently Asked Questions
BRC1608T passive component - Part List
14 parts in total| Mfr Part # | Quantity Available | Price | Category | Standard Package | RoHS | Tolerance | Inductance | Test Frequency | DC Resistance (DCR) | Current Rating (Max) | Frequency - Self Resonant | Resistance - Initial (Ri) (Min) | Width | Packaging | Package / Case | Size / Dimension | Termination Style | Type | Series | Operating Temperature | Other Names | Current Saturation - Series | Shielding | Mounting Type | Height - Seated (Max) | Supplier Device Package | Tariff No | Rad Hardened | Military Standard | Range deg/s | Inductance Range | DC Resistance (DCR) (Max) | Current - DC Forward (If) (Max) | Depth | Height | Length | Weight | Diameter | Core Material | Length - Overall | Technology | Failure Rate | Number of Pins | Product | Mechanical Life | メーカ | Resistance - Input | Center / Cutoff Frequency | Current - Supply (Disable) (Max) | Size | End - Size | Size - Body | Height (Max) | Operating Temperature - Junction |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 BRC1608T1R0M Ind Power Chip Wirewound 1uH 20% 7.96MHz Ferrite 520mA 0603 T/R INDUCTOR 1.0UH 850MA 20% SMD Inductor SMD 0603 wirewound 1.0uH Fixed Inductors INDCTR BTM-SRF WND 0603 1.0uH 20% Inductor Power Chip Wirewound 1uH 20% 7.96MHz Ferrite 520mA 234mOhm DCR 0603 T/R INDUCTOR, 1UH, 520MA, ±20%, 140MHz taiyo yuden | 21018 | 1: ¥0.9316 | - | Tape & Reel | Lead free / RoHS Compliant | 20 % | 1 uH | 7.96MHz | 234 mOhm Max | 520 mA | 140MHz | 180(Typ) mOhm | 0.8 mm | Tape & Reel (TR) | 0603 | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Power Chip | BRC | -40°C ~ 105°C | 587-2061-2 | 850mA | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.18ohm | 520 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | - | - | - | - | - | - | - | - | - | - | - | - |
 BRC1608T1R5M Ind Power Chip Wirewound 1.5uH 20% 7.96MHz Ferrite 410mA 0603 T/R Inductor SMD 0603 wirewound 1.5uH Fixed Inductors INDCTR BTM-SRF WND 0603 1.5uH 20% Inductor Power Chip Wirewound 1.5uH 20% 7.96MHz Ferrite 410mA 390mOhm DCR 0603 T/R INDUCTOR, 1.5UH, 410MA, 20% taiyo yuden | 3000 | 1: ¥0.9316 | - | Tape & Reel | Compliant | 20 % | 1.5 uH | 7.96 MHz | 0.39 ohm | 410 mA | 120MHz | 300(Typ) mOhm | 0.8 mm | Reel | 0603 | 1.6 x 0.8 x 0.8mm | SMD/SMT | Power Chip | BRC | +105°C | - | - | - | - | - | - | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.3ohm | 410 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | :2 | - | - | - | - | - | - | - | - | - | - | - |
BRC1608T2R2M Ind Power Chip Wirewound 2.2uH 20% 7.96MHz Ferrite 280mA 0603 T/R 固定インダクタ INDCTR BTM-SRF WND 0603 2.2uH 20% INDUCTOR 2.2UH 550MA 20% SMD Inductor SMD 0603 wirewound 2.2uH Fixed Inductors INDCTR BTM-SRF WND 0603 2.2uH 20% Inductor Power Chip Wirewound 2.2uH 20% 7.96MHz Ferrite 280mA 715mOhm DCR 0603 T/R INDUCTOR, 2.2UH, 280MA, 20% taiyo yuden | 25 | 1: ¥0.4441 | - | Tape & Reel | RoHS 認証 | 20 % | 2.2 uH | 7.96MHz | 550 mOhm | 280 mA | 100MHz | 550(Typ) mOhm | 0.8 mm | Tape & Reel (TR) | 0603 | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Power Chip | BRC | -40°C ~ 105°C | 587-2062-2 | 550mA | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.55ohm | 280 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | :2 | - | Mouser 初 | Taiyo Yuden | 550 mOhms | 100 MHz | 550 mA | 0.8 mm W x 1.6 mm L x 0.8 mm H | SMD/SMT | 1.6 mm | 0.8 mm | - 40 C to + 105 C |
 BRC1608TR20M Ind Power Chip Wirewound 200nH 20% 7.96MHz Ferrite 980mA 0603 T/R Fixed Inductors INDCTR BTM-SRF WND 0603 0.2uH 20% INDUCTOR 0.2UH 1.75A 20% SMD Inductor SMD 0603 wirewound 0.2uH Inductor Power Chip Wirewound 200nH 20% 7.96MHz Ferrite 980mA 78mOhm DCR 0603 T/R INDUCTOR, 200NH, 980MA, 20% taiyo yuden | 2420 | 31: ¥1.122 | - | Tape & Reel | RoHS Compliant | 20 % | 200 nH | 7.96MHz | 60 mOhm | 980 mA | 400 MHz | 78 mOhm | 0.8 mm | Reel | 0603 | 0.8 mm W x 1.6 mm L x 0.8 mm H | SMD/SMT | Power Chip | BRC | - 40 C to + 105 C | 587-2056-2 | 1.75A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.06ohm | 980 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | :2 | - | New At Mouser | - | - | - | - | - | - | - | - | - |
BRC1608TR35M Ind Power Chip Wirewound 350nH 20% 7.96MHz Ferrite 810mA 0603 T/R INDUCTOR 0.35UH 1.4A 20% SMD Inductor SMD 0603 wirewound 0.35uH Fixed Inductors INDCTR BTM-SRF WND 0603 0.35uH 20% Inductor Power Chip Wirewound 350nH 20% 7.96MHz Ferrite 810mA 104mOhm DCR 0603 T/R INDUCTOR, 350NH, 810MA, 20% taiyo yuden | 800 | 1: ¥2.7195 | - | Tape & Reel | Lead free / RoHS Compliant | 20 % | 350 nH | 7.96MHz | 80 mOhm | 810 mA | 300MHz | 104 mOhm | 0.8 mm | Tape & Reel (TR) | 0603 | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Power Chip | BRC | -40°C ~ 105°C | 587-2057-2 | 1.4A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.08ohm | 810 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | :2 | - | - | - | - | - | - | - | - | - | - | - |
BRC1608TR45M Ind Power Chip Wirewound 450nH 20% 7.96MHz Ferrite 800mA 0603 T/R INDUCTOR 0.45UH 1.25A 20% SMD Inductor SMD 0603 wirewound 0.45uH Fixed Inductors INDCTR BTM-SRF WND 0603 0.45uH 20% Inductor Power Chip Wirewound 450nH 20% 7.96MHz Ferrite 800mA 117mOhm DCR 0603 T/R INDUCTOR, 450NH, 800MA, 20% taiyo yuden | 3005 | 100: ¥1.0608 | - | Tape & Reel | Lead free / RoHS Compliant | 20 % | 450 nH | 7.96MHz | 90 mOhm | 800 mA | 200MHz | 117 mOhm | 0.8 mm | Tape & Reel (TR) | 0603 | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Power Chip | BRC | -40°C ~ 105°C | 587-2058-2 | 1.25A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.09ohm | 800 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | :2 | - | - | - | - | - | - | - | - | - | - | - |
BRC1608TR56M Ind Power Chip Wirewound 560nH 20% 7.96MHz Ferrite 760mA 0603 T/R INDUCTOR 0.56UH 1.15A 20% SMD Inductor SMD 0603 wirewound 0.56uH Fixed Inductors INDCTR BTM-SRF WND 0603 0.56uH 20% Inductor Power Chip Wirewound 560nH 20% 7.96MHz Ferrite 760mA 123.5mOhm DCR 0603 T/R INDUCTOR, 560NH, 760MA, 20% taiyo yuden | 20500 | 1: ¥0.9316 | - | Tape & Reel | Lead free / RoHS Compliant | 20 % | 560 nH | 7.96MHz | 95 mOhm | 760 mA | 170MHz | 123.5 mOhm | 0.8 mm | Tape & Reel (TR) | 0603 | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Power Chip | BRC | -40°C ~ 105°C | 587-2059-2 | 1.15A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.095ohm | 760 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | :2 | - | - | - | - | - | - | - | - | - | - | - |
BRC1608TR77M Ind Power Chip Wirewound 770nH 20% 7.96MHz Ferrite 660mA 0603 T/R INDUCTOR 0.77UH 1.0A 20% SMD Inductor SMD 0603 wirewound 0.77uH Fixed Inductors INDCTR BTM-SRF WND 0603 0.77uH 20% Inductor Power Chip Wirewound 770nH 20% 7.96MHz Ferrite 660mA 143mOhm DCR 0603 T/R INDUCTOR, 770NH, 660MA, 20% taiyo yuden | 11810 | 1: ¥2.516 | - | Tape & Reel | Lead free / RoHS Compliant | 20 % | 770 nH | 7.96MHz | 110 mOhm | 660 mA | 150MHz | 143 mOhm | 0.8 mm | Tape & Reel (TR) | 0603 | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Power Chip | BRC | -40°C ~ 105°C | 587-2060-2 | 1A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | 85045095 | No | Not Required | :TAIYO YUDEN - BR Series | :± 20% | :0.11ohm | 660 mA | 0.8mm | 1 mm | 1.6mm | 0 | Not Required mm | Ferrite | 1.8 mm | Wirewound | Not Required | :2 | - | - | - | - | - | - | - | - | - | - | - |
BRC1608T1R0M6 INDUCTOR 1UH 680MA 20% SMD Fixed Inductors INDCTR BTM-SRF WND 0603 1.0uH 20% Ind Power Chip Wirewound 1uH 20% 6MHz Ferrite 680mA 0603 T/R Taiyo Yuden | 89 | 1: ¥0.3955 | - | 3,000 | Lead free / RoHS Compliant | ±20% | 1µH | 6MHz | 188 mOhm | 680mA | 550MHz | 188 mOhms | 0.8 mm | Tape & Reel (TR) | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Wirewound | BR | -40°C ~ 105°C | 587-3219-2 | 890mA | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Power Inductor Wire Wound Type | - | - | - | - | - | - | - | - | - | - |
BRC1608TR43M6 INDUCTOR 0.43UH 1.1A 20% SMD Fixed Inductors INDCTR BTM-SRF WND 0603 0.43uH 20% Ind Power Chip Wirewound 430nH 20% 6MHz Ferrite 1.1A 0603 T/R Taiyo Yuden | 3000 | 1: ¥0.9316 | - | 3,000 | Lead free / RoHS Compliant | ±20% | 430nH | 6MHz | 82 mOhm | 1.1A | 740MHz | 82 mOhms | 0.8 mm | Tape & Reel (TR) | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Wirewound | BR | -40°C ~ 105°C | 587-3220-2 | 1.4A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Power Inductor Wire Wound Type | - | - | - | - | - | - | - | - | - | - |
BRC1608TR50M6 INDUCTOR 0.5UH 1.05A 20% SMD Fixed Inductors INDCTR BTM-SRF WND 0603 0.50uH 20% Ind Power Chip Wirewound 500nH 20% 6MHz Ferrite 1.05A 0603 T/R Taiyo Yuden | 2900 | 1: ¥0.9316 | - | 3,000 | Lead free / RoHS Compliant | ±20% | 500nH | 6MHz | 90 mOhm | 1.05A | 710MHz | 90 mOhms | 0.8 mm | Tape & Reel (TR) | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Wirewound | BR | -40°C ~ 105°C | 587-3221-2 | 1.2A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Power Inductor Wire Wound Type | - | - | - | - | - | - | - | - | - | - |
BRC1608TR60M6 INDUCTOR 0.6UH 940MA 20% SMD Fixed Inductors INDCTR BTM-SRF WND 0603 0.60uH 20% Ind Power Chip Wirewound 600nH 20% 6MHz Ferrite 940mA 0603 T/R Taiyo Yuden | 3000 | 1: ¥0.9316 | - | 3,000 | Lead free / RoHS Compliant | ±20% | 600nH | 6MHz | 99 mOhm | 940mA | 630MHz | 99 mOhms | 0.8 mm | Tape & Reel (TR) | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Wirewound | BR | -40°C ~ 105°C | 587-3222-2 | 1.1A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Power Inductor Wire Wound Type | - | - | - | - | - | - | - | - | - | - |
BRC1608TR72M6 INDUCTOR 0.72UH 810MA 20% SMD Fixed Inductors INDCTR BTM-SRF WND 0603 0.72uH 20% Ind Power Chip Wirewound 720nH 20% 6MHz Ferrite 810mA 0603 T/R Taiyo Yuden | 3000 | 1: ¥0.9316 | - | 3,000 | Lead free / RoHS Compliant | ±20% | 720nH | 6MHz | 144 mOhm | 810mA | 600MHz | 144 mOhms | 0.8 mm | Tape & Reel (TR) | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Wirewound | BR | -40°C ~ 105°C | 587-3223-2 | 1A | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Power Inductor Wire Wound Type | - | - | - | - | - | - | - | - | - | - |
BRC1608TR82M6 INDUCTOR 0.82UH 730MA 20% SMD Fixed Inductors INDCTR BTM-SRF WND 0603 0.82uH 20% Ind Power Chip Wirewound 820nH 20% 6MHz Ferrite 730mA 0603 T/R Taiyo Yuden | 1300 | 1: ¥0.9316 | - | 3,000 | Lead free / RoHS Compliant | ±20% | 820nH | 6MHz | 176 mOhm | 730mA | 560MHz | 176 mOhms | 0.8 mm | Tape & Reel (TR) | 0603 (1608 Metric) | 0.063" L x 0.031" W (1.60mm x 0.80mm) | SMD/SMT | Wirewound | BR | -40°C ~ 105°C | 587-3224-2 | 950mA | Unshielded | Surface Mount | 0.039" (1.00mm) | 0603 (1608 Metric) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Power Inductor Wire Wound Type | - | - | - | - | - | - | - | - | - | - |
