LP-34 transformer Series

Semi-toroidal and power transformers for various voltage and current applications

The LP-34 series from Signal Transformer Co. comprises semi-toroidal and power transformers designed for a range of voltage and current applications. These transformers are particularly useful in systems that require efficient power transfer and isolation. If you're working on audio equipment, they can help maintain high-fidelity signal transmission while reducing hum and noise. In industrial settings, these transformers are often used in motor control circuits and power supplies, where their compact design and high efficiency make them a preferred choice. One thing worth noting is that their semi-toroidal shape allows for better magnetic flux containment, which is crucial for minimizing leakage and improving overall performance. Engineers tend to reach for this series when they need reliable transformers that can handle both low and high power demands efficiently, especially in environments where space is limited and performance is critical.

Series Images (9)

Documents & Media

PDF Document

Frequently Asked Questions

Content generated by AI, for reference only
Loading...
03

LP-34 transformer - Part List

5 parts in total

Power - Max

Current - Output

Height - Seated (Max)

Size / Dimension

Lead Time

Standard Package

Subcategory

Mfr Part #Quantity AvailablePriceCategoryLead TimeSubcategoryStandard PackageRoHSPower - MaxCurrent - OutputVoltage - PrimaryVoltage - IsolationSecondary Winding(s)Voltage - Secondary (Full Load)Mounting TypeSize / DimensionTermination StylePrimary Winding(s)Height - Seated (Max)TypeCenter Tap
LP-34-75
4
LP-34-75

XFRMR PWR 115/230V 17VAC 150MA XFRMR SEMI-TORO 2VA THRU HOLE

Signal Transformers

221: ¥78.676-56 DaysNot Specified100Lead free / RoHS Compliant2 VAParallel 150mA, Series 75mA115V, 230V1500VrmsDualParallel 17V, Series 34VThrough Hole47.50mm L x 39.60mm WPC PinDual16.50mmSemi-ToroidalNo
LP-34-170
5
LP-34-170

XFRMR PWR 115/230V 17VAC 340MA XFRMR SEMI-TORO 6VA THRU HOLE

Signal Transformers

2881: ¥77.724-56 DaysPower Transformer100Lead free / RoHS Compliant6 VAParallel 340mA, Series 170mA115V, 230V1500VrmsDualParallel 17V, Series 34VThrough Hole47.50mm L x 39.60mm WPC PinDual21.60mmSemi-ToroidalNo
LP-34-340
4
LP-34-340

XFRMR PWR 115/230V 17VAC 680MA XFRMR SEMI-TORO 12VA THRU HOLE

Signal Transformers

4851: ¥105.128-20 DaysPower Transformer50Lead free / RoHS Compliant12 VAParallel 680mA, Series 340mA115V, 230V1500VrmsDualParallel 17V, Series 34VThrough Hole63.50mm L x 50.80mm WPC PinDual27.10mmSemi-ToroidalNo
LP-34-700
4
LP-34-700

XFRMR PWR 115/230V 17VAC 1.4A XFRMR SEMI-TORO 24VA THRU HOLE

Signal Transformers

2381: ¥115.532-24 DaysPower Transformer50Lead free / RoHS Compliant24 VAParallel 1.4A, Series 700mA115V, 230V1500VrmsDualParallel 17V, Series 34VThrough Hole72.90mm L x 57.20mm WPC PinDual31.80mmSemi-ToroidalNo
LP-34-1400
4
LP-34-1400

XFRMR PWR 115/230V 17VAC 2.8A XFRMR SEMI-TORO 48VA THRU HOLE

Signal Transformers

2041: ¥123.216-56 DaysPower Transformer20Lead free / RoHS Compliant48 VAParallel 2.8A, Series 1.4A115V, 230V1500VrmsDualParallel 17V, Series 34VThrough Hole79.20mm L x 63.50mm WPC PinDual34.90mmSemi-ToroidalNo
