cigen-PCD-25
PCD-25 optoelectronic Series
mean-well25W single-output LED drivers with various voltage and current options
The PCD-25 series from MEAN WELL is a lineup of 25W single-output LED drivers that offer a range of voltage and current options. These drivers are designed for small to medium-sized LED lighting applications where precise control over power and light output is essential. If you're working on projects involving architectural lighting, signage, or any application requiring dimmable LEDs, these drivers are a solid choice.
One thing worth noting is the flexibility in voltage and current settings. This allows engineers to match the driver perfectly to the specific LED requirements, ensuring optimal performance and longevity. Another practical observation is their compact size, which makes them suitable for installations where space is limited. They also come with built-in protection features such as overvoltage, overcurrent, and short-circuit protection, which adds a layer of safety and reliability to your design. Engineers tend to reach for this when they need a reliable, flexible, and compact solution for LED lighting systems without the complexity of multi-output configurations.
Series Images (8)
Documents & Media
Frequently Asked Questions
PCD-25 optoelectronic - Part List
9 parts in total| Mfr Part # | Quantity Available | Price | Category | Product | Product Category | RoHS | Input | Output | Operation | Efficiency | Output Power | Power (Watts) | Operating Mode | Voltage Rating | Number of Outputs | Secondary Winding(s) | Voltage - Input (Min) | Power Factor Correction | Current Regulation - Line | Current - Output / Channel | Mounting Style | Package Quantity | Size / Dimension | Series | Features | Stock Status | Ingress Protection | Operating Temperature | Power - Output | Mounting Type | Primary Material | Type | Manufacturer | Configuration | Protection | Dimming | Frequency | Power - Max | Power - Rated | Current - Output | Voltage - Supply | Power Supply Type | DC Voltage - Input (Max) | Size | Depth | Width | Height | Weight | Size - Body | Termination Style | Color - Connectors | Function | Electrical Life | Number of Units | Application Specifics | Current Rating (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 PCD-25-700A LED Drivers Power Supplies 25.2W 24-36Vout 700mA 90-135VAC AC/DC Power Supply Single-OUT 24V to 36V 0.7A 25.2W 4-Pin Power Supply; AC-DC; 36V@0.7A; 90-135V In; LED Driver; Constant Current; PCD Series PCD-25-700A from Mean Well, 25 Watt, Single Output Mean Well | 58 | 1: ¥106.284 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 36VDC@0.7A | PFC | 81.00% | 25.2 W | 25 W | Constant Current (CC) | 90 VAC to 135 VAC | 1 | Required | 24 V to 36 V | PFC | CC | 700 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | MEAN WELLPCD-25 | 3-Years Warranty, High Reliability, Constant Current Design, 100% Full Load Burn-In Test, Short Circuit, Over Temperature Protections | 385 | IP30 | -30~+60C | 25.2 W | Panel | AC-DC | LED Driver | PCD Series | Enclosed | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
PCD-25-700B LED Drivers Power Supplies 25.2W 24-36Vout 700mA 180-295VAC Triac Dimmable LED Driver, 700mA,25W AC/DC Power Supply Single-OUT 24V to 36V 0.7A 25.2W 4-Pin Pwr sup.unit: pulse; for LED diodes; 25.2W; 24÷36VDC; 700mA; IP67 PCD-25-700B from Mean Well, 25 Watt, Single Output LED driver, PCD-25-700B, Mean Well Mean Well LED 驱动器 , 24 → 36V, 0.7A, 25.2W Mean Well | 222 | 3: ¥141.7018 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 24.0V @ 0.70A | Constant Current | 81.00% | 25.2 W | 25 W | Constant Current (CC) | 180 VAC to 295 VAC | 1 | Required | 24 V to 36 V | PFC | CC | 700 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | PCD-25 | rated parameters obtained at full load | Please Call | IP67 | -30...60°C | - | - | - | - | - | - | overload, overheating, short-circuit | Triac | 47...63 Hz | 25.2W | 25.2W | 700mA | 180...295V AC | pulse | AC | 84 x 57 x 29.5 mm | 57 | 84 | 29.5 | 190g | 57 x 84 x 29.5mm | Stranded Wires, Input: 75 cm AWG18, Output: 150 cm AWG18 | white | power factor correction function | wires | 1 | Indoor Lighting | 0.7A |
PCD-25-1050A LED Drivers Power Supplies 25.2W 16-24Vout 1050mA 90-135VAC AC/DC Power Supply Single-OUT 16V to 24V 1.05A 25.2W 4-Pin Power Supply; AC-DC; 24V@1.05A; 90-135V In; LED Driver; Constant Current; PCD Series PCD-25-1050A from Mean Well, 25 Watt, Single Output Mean Well | 38 | 1: ¥123.71 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 24VDC@1.05A | PFC | 80.50% | 25.2 W | 25 W | Constant Current (CC) | 90 VAC to 135 VAC | 1 | Required | 16 V to 24 V | PFC | CC | 1050 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | MEAN WELLPCD-25 | 3-Years Warranty, High Reliability, Constant Current Design, 100% Full Load Burn-In Test, Short Circuit, Over Temperature Protections | Please Call | IP30 | -30~+60C | 25.2 W | Panel | AC-DC | LED Driver | PCD Series | Enclosed | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
PCD-25-350A LED Drivers Power Supplies 20.3W 40-58Vout 350mA 90-135VAC AC/DC Power Supply Single-OUT 40V to 58V 0.35A 20.3W 4-Pin Power Supply; AC-DC; 58V@0.35A; 90-135V In; LED Driver; Constant Current; PCD Series PCD-25-350A from Mean Well, 25 Watt, Single Output Mean Well | 50 | 1: ¥105.74 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 58VDC@0.35A | PFC | 82.00% | 20.3 W | 25 W | Constant Current (CC) | 90 VAC to 135 VAC | 1 | Required | 40 V to 58 V | PFC | CC | 350 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | MEAN WELLPCD-25 | 3-Years Warranty, High Reliability, Constant Current Design, 100% Full Load Burn-In Test, Short Circuit, Over Temperature Protections | 52 | IP30 | -30~+60C | 20.3 W | Panel | AC-DC | LED Driver | PCD Series | Enclosed | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
PCD-25-1050B LED Drivers Power Supplies 25.2W 16-24Vout 1050mA 180-295VAC Triac Dimmable LED Driver, 1050mA,25W AC/DC Power Supply Single-OUT 16V to 24V 1.05A 25.2W 4-Pin Pwr sup.unit: pulse; for LED diodes; 25.2W; 16÷24VDC; 1050mA; IP67 PCD-25-1050B from Mean Well, 25 Watt, Single Output LED driver, PCD-25-1050B, Mean Well Mean Well | 16 | 1: ¥102.68 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 16.0V @ 1.05A | Constant Current | 80.50% | 25.2 W | 25 W | Constant Current (CC) | 180 VAC to 295 VAC | 1 | Required | 16 V to 24 V | PFC | CC | 1050 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | MEAN WELLPCD-25 | rated parameters obtained at full load | Please Call | IP67 | -30...60°C | - | - | - | - | - | - | overload, overheating, short-circuit | Triac | 47...63 Hz | 25.2W | 25.2W | 1050mA | 180...295V AC | pulse | AC | 84 x 57 x 29.5 mm | 57 | 84 | 29.5 | 190g | 57 x 84 x 29.5mm | Stranded Wires, Input: 75 cm AWG18, Output: 150 cm AWG18 | white | power factor correction function | wires | 1 | Indoor Lighting | - |
PCD-25-350B LED Drivers Power Supplies 20.3W 40-58Vout 350mA 180-295VAC Triac Dimmable LED Driver, 350mA,25W AC/DC Power Supply Single-OUT 40V to 58V 0.35A 20.3W 4-Pin Pwr sup.unit: pulse; for LED diodes; 20.3W; 40÷58VDC; 350mA; IP67 PCD-25-350B from Mean Well, 25 Watt, Single Output LED driver, PCD-25-350B, Mean Well Mean Well LED 驱动器 , 40 → 58V, 0.35A, 20.3W Mean Well | 51 | 1: ¥105.74 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 40.0V @ 0.35A | Constant Current | 82.00% | 20.3 W | 25 W | Constant Current (CC) | 180 VAC to 295 VAC | 1 | Required | 40 V to 58 V | PFC | CC | 350 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | MEAN WELLPCD-25 | rated parameters obtained at full load | Please Call | IP67 | -30...60°C | - | - | - | - | - | - | overload, overheating, short-circuit | Triac | 47...63 Hz | 20.3W | 20.3W | 350mA | 180...295V AC | pulse | AC | 84 x 57 x 29.5 mm | 57 | 84 | 29.5 | 190g | 57 x 84 x 29.5mm | Stranded Wires, Input: 75 cm AWG18, Output: 150 cm AWG18 | white | power factor correction function | wires | 1 | Indoor Lighting | 0.35A |
PCD-25-1400B LED Drivers Power Supplies 25.2W 12-18Vout 1400mA 180-295VAC Triac Dimmable LED Driver, 1400mA,25W AC/DC Power Supply Single-OUT 12V to 18V 1.4A 25.2W 4-Pin Pwr sup.unit: pulse; for LED diodes; 25.2W; 12÷18VDC; 1400mA; IP67 PCD-25-1400B from Mean Well, 25 Watt, Single Output LED driver, PCD-25-1400B, Mean Well Mean Well LED 驱动器 , 12 → 18V, 1.4A, 25.2W Mean Well | 11 | 1: ¥102.68 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 12.0V @ 1.40A | Constant Current | 80.00% | 25.2 W | 25 W | Constant Current (CC) | 180 VAC to 295 VAC | 1 | Required | 12 V to 18 V | PFC | CC | 1400 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | MEAN WELLPCD-25 | rated parameters obtained at full load | Please Call | IP67 | -30...60°C | - | - | - | - | - | - | overload, overheating, short-circuit | Triac | 47...63 Hz | 25.2W | 25.2W | 1400mA | 180...295V AC | pulse | AC | 84 x 57 x 29.5 mm | 57 | 84 | 29.5 | 190g | 57 x 84 x 29.5mm | Stranded Wires, Input: 75 cm AWG18, Output: 150 cm AWG18 | white | power factor correction function | wires | 1 | Indoor Lighting | 1.4A |
PCD-25-1400A LED Drivers Power Supplies 25.2W 12-18Vout 1400mA 90-135VAC AC/DC Power Supply Single-OUT 12V to 18V 1.4A 25.2W 4-Pin Power Supply; AC-DC; 18V@1.4A; 90-135V In; LED Driver; Constant Current; PCD Series PCD-25-1400A from Mean Well, 25 Watt, Single Output Mean Well | 11 | 1: ¥101.388 | - | Linear Supplies | LED Drivers Power Supplies | RoHS Compliant | 90-135 or 180-295 VAC | 18VDC@1.4A | PFC | 80.00% | 25.2 W | 25 W | Constant Current (CC) | 90 VAC to 135 VAC | 1 | Required | 12 V to 18 V | PFC | CC | 1400 mA | Chassis | PLASTIC3.31 x 2.24 x 1.16" | 84 mm L x 57 mm W x 29.5 mm H | MEAN WELLPCD-25 | 3-Years Warranty, High Reliability, Constant Current Design, 100% Full Load Burn-In Test, Short Circuit, Over Temperature Protections | 24 | IP30 | -30~+60C | 25.2 W | Panel | AC-DC | LED Driver | PCD Series | Enclosed | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 PCD-25 Mean Well Enterprises | 10 | 1: ¥153.816 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
