cigen-S 102 A
S 102 A Series
IP68-rated circular push-pull connectors with cable mounting
The S 102 A series from Fischer Connectors is a robust line of IP68-rated circular push-pull connectors designed for harsh environments. These connectors feature a unique push-pull mechanism that ensures easy and secure mating while maintaining a tight seal. They come with cable mounting options, making them ideal for applications where cables need to be directly connected without additional strain relief devices.
If you're working on projects involving underwater equipment, offshore drilling platforms, or any environment where dust, water, and other contaminants are a concern, these connectors are a go-to solution. The IP68 rating means they are fully protected against dust and submersion under water indefinitely, which is crucial in many industrial settings.
One thing worth noting is the ease of installation and maintenance. The push-pull design allows for quick disconnection and reconnection, which is a significant advantage in maintenance-heavy environments. Engineers tend to reach for this when they need a reliable connection that can withstand harsh conditions without compromising on the convenience of regular use.
Series Images (14)
Documents & Media
Frequently Asked Questions
S 102 A - Part List
12 parts in total| Mfr Part # | Quantity Available | Price | Category | Voltage Rating | Current Rating (Max) | Mounting Type | Connector Type | Contact Finish | Contact Material | Housing Material | Number of Contacts | Series | Operating Temperature | Connector Impedance | Orientation | Contact Type | Termination Rows | Base Product Number | Ingress Protection | SVHC | Tariff No | Connector - Voltage Input | Weight | Shell Size | Termination | Connector Usage | Insertion Angle | Material - Body | Material Finish | 1st Contact Gender | Contact Termination | Shell Size - Insert | 1st Connector Mounting Type | Gender | Seal Rating | Mating Cycles | Outline |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 S 102 A054-130+ PLUG, IP68, PUSH-PULL, 5WAY CIRCULAR CONNECTOR, PLUG, 5 WAY, CABLE Fischer Connectors 102 系列 5路 电缆安装 直向 连接器 插头 , 公触点, 推挽式接合 Fischer Connectors | 10 | 1: ¥179.452 | - | 160 V ac | 5.2A | Straight | :Circular Industrial | Gold | Brass | Brass | 5 | 102 | +150°C | - | - | - | - | - | - | :No SVHC (20-Jun-2013) | 85366990 | Standard | 0.00758 | 9mm | Solder | Push-Pull | :- | :Brass | :- | Male | :Solder | :- | :Cable | Male | IP68 | - | - |
S 102 A052-130+ PLUG, IP68, PUSH-PULL, 3WAY CIRCULAR CONNECTOR, PLUG, 3 WAY, CABLE Fischer Connectors 102 系列 3路 电缆安装 直向 连接器 插头 , 公触点, 推挽式接合 Fischer Connectors | 10 | 1: ¥164.90 | - | 250 V ac | 8.2A | Straight | :Circular Industrial | Gold | Brass | Brass | 3 | 102 | +150°C | - | - | - | - | - | - | :No SVHC (20-Jun-2013) | 85366990 | Standard | 0.00758 | 9mm | Solder | Push-Pull | :- | :Brass | :- | Male | :Solder | :- | :Cable | Male | IP68 | :10000 | - |
S 102 A056-130+ PLUG, IP68, PUSH-PULL, 7WAY CIRCULAR CONNECTOR, PLUG, 7 WAY, CABLE Fischer Connectors 102 系列 7路 电缆安装 直向 连接器 插头 , 公触点, 推挽式接合 Fischer Connectors | 10 | 1: ¥191.352 | - | 160 V ac | 2A | Straight | :Circular Industrial | Gold | Brass | Brass | 7 | 102 | +150°C | - | - | - | - | - | - | :No SVHC (20-Jun-2013) | 85366990 | Standard | 0.00758 | 9mm | Solder | Push-Pull | :- | :Brass | :- | Male | :Solder | :- | :Cable | Male | IP68 | :10000 | - |
 | 0 | - | 250 V ac | 8.2A | 电缆安装 | 公插 | 金镀镍 | 黄铜 | 黄铜 | 3 | Core | +200°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 200 V ac | 5.5A | 电缆安装 | 公插 | 金镀镍 | 黄铜 | 黄铜 | 4 | Core | +200°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 250 V ac | 9.2A | 电缆安装 | 公插 | 金镀镍 | 黄铜 | 黄铜 | 2 | Core | +200°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 160 V ac | 1.7A | 电缆安装 | 公插 | 金镀镍 | 青铜 | 黄铜 | 9 | Core | +130°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 250 V ac | 9.2A | 电缆安装 | 公插 | 金镀镍 | 黄铜 | 黄铜 | 2 | Core | +200°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 160 V ac | 5.2A | 电缆安装 | 公插 | 金镀镍 | 黄铜 | 黄铜 | 5 | Core | +200°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 200 V ac | 5.5A | 电缆安装 | 公插 | 金镀镍 | 黄铜 | 黄铜 | 4 | Core | +200°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 160 V ac | 2A | 电缆安装 | 公插 | 金镀镍 | 黄铜 | 黄铜 | 7 | Core | +200°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | |
 | 0 | - | 160 V ac | 1.7A | 电缆安装 | 公插 | 金 | 黄铜 | 黄铜 | 9 | Core | +130°C | 标准 | 直 | 公插 | 焊接 | 102 | IP50 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 102 |
