VC 16 Series

The VC 16 series from Block Transformatoren-Elektronik GmbH consists of 16VA PCB-mount transformers offering a range of AC output voltages. These compact transformers are ideal for projects requiring space-efficient power conversion solutions, such as electronic devices, test equipment, and medical instruments. If you're working on anything that needs a small footprint but still demands reliable power transformation, these might be just what you need.

One thing worth noting is their suitability for low-power applications where board space is at a premium. Engineers tend to reach for these when they need to integrate power conversion directly onto a circuit board without taking up valuable real estate. Another practical advantage is their robustness; despite being small, they handle the required load capacity well, making them a solid choice for projects where durability and performance are key.

These transformers come in handy for applications like powering small sensors, microcontrollers, and other low-power electronics. They also find use in portable devices where minimizing the overall size and weight is crucial. Given their compact nature and wide range of output voltages, the VC 16 series is a versatile tool for any engineer looking to simplify their design while ensuring reliable power delivery.

Mfr Part #	Quantity Available	Price	Category	Power - Rated	Number of Outputs	Voltage - Primary	Voltage - Secondary	Voltage - Supply (Vcc/Vdd)	Voltage - Secondary (Full Load)	Depth	Width	Length	Weight	Mounting Type	Size / Dimension	Maximum Temperature Limit	Frequency	Voltage - Test	Current - Output	Height	Body Color	Weight (g):	Primary Material	Diameter - Outside	Form	Amplifier Type	Temperature	CAD Drawing	Frequency - Max	Frequency - Min	Frequency - Operating
VC 16/2/9 Transformer PCB 16VA 2x9V PCB transformer 16 VA 9 VAC (2x), VC 16/2/9, Block Block 2输出通孔 PCB 变压器, 230V ac初级电压, 9V ac次级电压, 16VA Block	26	1: ¥100.72	-	16VA	2	230V	9 VAC(2x)	230V 交流	18 V, 9 V	48mm	39mm	57mm	420g	Through Hole	57 x 39 x 48mm	+40°C	30	5000	2x888	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	3D CAD Model	-	-	-
3 VC 16/1/18 PCB mount transformer 16VA 1x18 o/p PCB transformer 16 VA 18 VAC (1x), VC 16/1/18, Block Block 通孔 PCB 变压器, 230V ac初级电压, 18V ac次级电压, 16VA, 50 → 60 Hz工作范围 Block	17	1: ¥86.07	-	16VA	1	230V	18 VAC(1x)	230V 交流	18 V	39mm	48mm	57mm	0.42kg	Through Hole	57 x 48 x 39mm	+40°C	30	5000	888	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	-	60Hz	50Hz	50Hz
3 VC 16/1/24 PCB mount transformer 16VA 1x24 o/p PCB transformer 16 VA 24 VAC (1x), VC 16/1/24, Block Block 通孔 PCB 变压器, 230V ac初级电压, 24V ac次级电压, 16VA, 50 → 60 Hz工作范围 Block	29	1: ¥65.17	-	16VA	1	230V	24 VAC(1x)	230V 交流	24 V	39mm	48mm	57mm	0.42kg	Through Hole	57 x 48 x 39mm	+40°C	30	5000	666	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	-	60Hz	50Hz	50Hz
VC 16/2/24 Transformer PCB 16VA 2x24V Block 2输出通孔 PCB 变压器, 230V ac初级电压, 24V ac次级电压, 16VA Block	63	28: ¥37.54	-	16VA	2	230V	24V 交流	230V 交流	24 V, 48 V	48mm	39mm	57mm	420g	Through Hole	57 x 39 x 48mm	+40°C	-	-	-	-	-	-	-	-	-	-	-	3D CAD Model	-	-	-
3 VC 16/1/15 PCB mount transformer 16VA 1x15 o/p PCB transformer 16 VA 15 VAC (1x), VC 16/1/15, Block Block 通孔 PCB 变压器, 230V ac初级电压, 15V ac次级电压, 16VA, 50 → 60 Hz工作范围 Block	10	1: ¥92.28	-	16VA	1	230V	15 VAC(1x)	230V 交流	15 V	39mm	48mm	57mm	0.42kg	Through Hole	57 x 48 x 39mm	+40°C	30	5000	1066	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	-	60Hz	50Hz	50Hz
VC 16/2/12 Transformer PCB 16VA 2x12V PCB transformer 16 VA 12 VAC (2x), VC 16/2/12, Block Block 2输出通孔 PCB 变压器, 230V ac初级电压, 12V ac次级电压, 16VA Block	23	1: ¥81.86	-	16VA	2	230V	12 VAC(2x)	230V 交流	12 V, 24 V	48mm	39mm	57mm	420g	Through Hole	57 x 39 x 48mm	+40°C	30	5000	2x666	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	3D CAD Model	-	-	-
3 VC 16/1/12 PCB mount transformer 16VA 1x12 o/p PCB transformer 16 VA 12 VAC (1x), VC 16/1/12, Block Block 通孔 PCB 变压器, 230V ac初级电压, 12V ac次级电压, 16VA, 50 → 60 Hz工作范围 Block	81	1: ¥70.28	-	16VA	1	230V	12 VAC(1x)	230V 交流	12 V	39mm	48mm	57mm	0.42kg	Through Hole	57 x 48 x 39mm	+40°C	30	5000	1333	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	-	60Hz	50Hz	50Hz
VC 16/2/15 Transformer PCB 16VA 2x15V PCB transformer 16 VA 15 VAC (2x), VC 16/2/15, Block Block 2输出通孔 PCB 变压器, 230V ac初级电压, 15V ac次级电压, 16VA Block	46	28: ¥73.75	-	16VA	2	230V	15 VAC(2x)	230V 交流	15 V, 30 V	48mm	39mm	57mm	420g	Through Hole	57 x 39 x 48mm	+40°C	30	5000	2x533	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	3D CAD Model	-	-	-
3 VC 16/1/6 PCB mount transformer 16VA 1x6 o/p PCB transformer 16 VA 6 VAC (1x), VC 16/1/6, Block Block 通孔 PCB 变压器, 230V ac初级电压, 6V ac次级电压, 16VA, 50 → 60 Hz工作范围 Block	10	1: ¥66.15	-	16VA	1	230V	6 VAC(1x)	230V 交流	6 V	39mm	48mm	57mm	0.42kg	Through Hole	57 x 48 x 39mm	+40°C	30	5000	2666	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	-	60Hz	50Hz	50Hz
VC 16/2/6 Transformer PCB 16VA 2x6V Block 2输出通孔 PCB 变压器, 230V ac初级电压, 6V ac次级电压, 16VA Block	39	28: ¥37.54	-	16VA	2	230V	6V 交流	230V 交流	12 V, 6 V	48mm	39mm	57mm	420g	Through Hole	57 x 39 x 48mm	+40°C	-	-	-	-	-	-	-	-	-	-	-	3D CAD Model	-	-	-
3 VC 16/1/9 PCB mount transformer 16VA 1x9 o/p PCB transformer 16 VA 9 VAC (1x), VC 16/1/9, Block Block 通孔 PCB 变压器, 230V ac初级电压, 9V ac次级电压, 16VA, 50 → 60 Hz工作范围 Block	27	1: ¥99.87	-	16VA	1	230V	9 VAC(1x)	230V 交流	9 V	39mm	48mm	57mm	0.42kg	Through Hole	57 x 48 x 39mm	+40°C	30	5000	1777	39	48	5	1 x 230 VAC, 50...60 Hz	30	VC 16	57	max.40 °C	-	60Hz	50Hz	50Hz
VC 16/2/18 Transformer PCB 16VA 2x18V Block 2输出通孔 PCB 变压器, 230V ac初级电压, 18V ac次级电压, 16VA Block	28	28: ¥73.75	-	16VA	2	230V	18V 交流	230V 交流	18 V, 36 V	48mm	39mm	57mm	420g	Through Hole	57 x 39 x 48mm	+40°C	-	-	-	-	-	-	-	-	-	-	-	3D CAD Model	-	-	-
