WM093R wm Series

Standard-sized wall-mount enclosures with label recesses in various colors

The WM093R series from Serpac Electronic Enclosures are standard-sized wall-mount enclosures designed to house small to medium-sized electronic devices. These enclosures come in various colors, each featuring recessed areas specifically for labels, making them easy to identify and organize in any industrial or commercial setting. If you're working on projects that require a simple yet robust solution for mounting electronics on walls, these enclosures are a solid choice.

One thing worth noting is their versatility; they can be used in a wide range of applications from home automation to industrial control systems. The recessed label areas are particularly handy for quick identification and maintenance. Engineers tend to reach for these when they need something straightforward without the need for complex customization. They provide a neat and organized look while keeping components secure and protected from environmental factors.

Series Images (11)

Documents & Media

PDF Document
PDF Document
PDF Document
Online Document

Frequently Asked Questions

Content generated by AI, for reference only
Loading...
03

WM093R wm - Part List

9 parts in total

Color

Material

Type

Other Names

Mfr Part #Quantity AvailablePriceCategoryStandard PackageColorHeightWeightMaterialThicknessArea (L x W)Size / DimensionDesignFeaturesShipping InfoContainer TypeRatingsProduct CategoryRoHSMaterial Flammability RatingProductTypeOther NamesDepthWidth - OverallDiameter - Outside, Non-ExpandedSeriesSeal RatingNEMA Frame Size
WM093RI,GY
2
WM093RI,GY

WALLMNT ENCLOSURE 9.50X6.34X2.10 Enclosures, Boxes, & Cases 9.50 x 6.34 x 2.11 RECES FOR LABL, GRAY

Serpac

101: ¥131.308-1Gray2.100" (53.34mm)0.682 lb (309.35g)Plastic, ABS0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1Enclosures, Boxes, & CasesRoHS CompliantUL94 HBElectronics EnclosuresLabel Recess-------
WM093R,AL
2
WM093R,AL

WALLMNT ENCLOSURE 9.50X6.34X2.10 Enclosures, Boxes, & Cases 9.50 x 6.34 x 2.11 ALMOND

Serpac

101: ¥101.524-1Almond2.100" (53.34mm)0.682 lb (309.35g)Plastic, ABS0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1Enclosures, Boxes, & CasesRoHS CompliantUL94 HB---------
WM093R,BK
2
WM093R,BK

WALLMNT ENCLOSURE 9.50X6.34X2.10 Enclosures, Boxes, & Cases 9.50 x 6.34 x 2.11 BLACK

Serpac

101: ¥101.524-1Black2.100" (53.34mm)0.682 lb (309.35g)Plastic, ABS0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1Enclosures, Boxes, & CasesRoHS CompliantUL94 HB---------
WM093R,GY
2
WM093R,GY

WALLMNT ENCLOSURE 9.50X6.34X2.10 Enclosures, Boxes, & Cases 9.50 x 6.34 x 2.11 GRAY

Serpac

101: ¥101.524-1Gray2.100" (53.34mm)0.682 lb (309.35g)Plastic, ABS0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1Enclosures, Boxes, & CasesRoHS CompliantUL94 HB---------
WM093RI,AL
2
WM093RI,AL

WALLMNT ENCLOSURE 9.50X6.34X2.10 Enclosures, Boxes, & Cases 9.50 x 6.34 x 2.11 RECES FR LABL ALMND

Serpac

101: ¥101.524-1Almond2.100" (53.34mm)0.682 lb (309.35g)Plastic, ABS0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1Enclosures, Boxes, & CasesRoHS CompliantUL94 HBElectronics EnclosuresLabel Recess-------
WM093RI,BK
2
WM093RI,BK

WALLMNT ENCLOSURE 9.50X6.34X2.10 Enclosures, Boxes, & Cases 9.50 x 6.34 x 2.11 RECES FOR LABEL, BLK

Serpac

991: ¥131.308-1Black2.100" (53.34mm)0.682 lb (309.35g)Plastic, ABS0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1Enclosures, Boxes, & CasesRoHS CompliantUL94 HBElectronics EnclosuresWall Mount-10.49 in6.39 in2.1 inWMIP 401
WM093RC,BK
2
WM093RC,BK

WALLMNT ENCLOSURE 9.50X6.34X2.10

Serpac

101: ¥157.08-1Black, Clear Cover/Door2.100" (53.34mm)0.682 lb (309.35g)Plastic, Polycarbonate0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1------------
WM093RC,AL
2
WM093RC,AL

WALLMNT ENCLOSURE 9.50X6.34X2.10

Serpac

101: ¥147.356-1Almond, Clear Cover/Door2.100" (53.34mm)0.682 lb (309.35g)Plastic, Polycarbonate0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1-----SRW093-RCA------
WM093RC,GY
2
WM093RC,GY

WALLMNT ENCLOSURE 9.50X6.34X2.10

Serpac

101: ¥147.356-1Gray, Clear Cover/Door2.100" (53.34mm)0.682 lb (309.35g)Plastic, Polycarbonate0.100" (2.54mm)60.2" (388cm)9.500" L x 6.340" W (241.30mm x 161.04mm)Cover IncludedFront Access, PCB Supports, Wall MountShipped from Digi-KeyBox with Mounting FlangeIP40, NEMA 1-----SRW093-RCG------
