10236-0210EC
| Manufacturer | |
| Description | D-Sub Micro-D Connectors 36P RECEPT SHIELDED IDC WIREMNT PANELMNT Wiremount/Panelmount Receptacle, IDC, Shielded CONN MDR RECPT 36POS IDC GOLD Plug IDC Panel Mount MDR Series 36 way SOCKET, MDR, IDC, 36WAY PlugIDCPanelMountMDRSeries36way 3M 102 系列 1.27mm 节距 36 路 IDC Mini-D 带状电缆连接器, 插头, 钢外壳 |
| Category |
商业参数
| 零件号别名 | 90169009058 JE150182408 | 产品类别 | D-Sub Micro-D Connectors |
| 标准包装数量 | 100 | 工厂包装数量 | 100 |
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85366990 |
电气参数
| 量程（°/s） | :3M - 102 Series | 最大额定电流 | 1 A |
机械参数
| 深度 | 9.1mm | 间距 | 1.27mm |
| 宽度 | 12.7mm | 长度 | 32.2mm |
| 重量 | 1 lb | 端接方式 | IDC |
| 安装类型 | Vertical | 连接器类型 | Receptacle |
| 接触镀层 | Gold | 法兰特征 | Insert, Threaded (M2.5); Latchblocks |
| 安装样式 | Wire | 排数 | 2 |
| 连接器样式 | Outer Shroud Contacts | 触头材料 | Beryllium Copper |
| 壳体材料 | Glass Fibre Reinforced PET | 尺寸/外形 | 32.2 x 12.7 x 9.1mm |
| 端接样式 | IDC | 触点数 | 36 |
| 接触件端接 | :IDC / IDT | 位数 | 36 |
| 接触镀层厚度 | 30µin (0.76µm) | ||
产品信息
| 连接器性别 | Male | 系列 | 102 |
| 产品特性 | Shielded | ||
环境参数
| 工作温度 | +85°C | ||
Documents & Media
相关型号
10136-3000PE
3M Electronic Solutions Division
D-Sub Micro-D Connectors WIREMT/MDR/PLUG/36PO Wiremount Plug, Solder, Shielded CONN MDR PLUG 36POS SLD CUP 36 way shielded I/O solder plug,1A PLUG, MDR, SOLDER, 36WAY Conn;D-Sub;Mini-D-Ribbon;CablePlug;36Pos;STR;101Series;Solder;30-24AWG;).050In. Connector: MDR; plug; male; shielded; PIN:36; 1.27mm; 24÷30AWG; 1A MDR plug 36P, 10136-3000PE, 3M 3M 101 系列 电缆安装 36 路 焊接 D-sub 连接器 插头 , 1A
