Business
| Part # Aliases | 05400734341 80610132740 | Product Category | Standard Card Edge Connectors |
| Standard Package | 1,000 | Factory Pack Quantity | 100 |
Compliance
| RoHS | RoHS Compliant | Standards | cUL,ULListed,RoHSComplaint |
| Tariff No | 85366910 | Approval Agency | cUL,UL |
| Material Flammability Rating | UL94V-0 | ||
Electrical
| Voltage - Rated | 1000V(RMS)@seaLevel | Current Rating (Max) | 1A |
| Insulation Resistance | 1x10^9(Max.)@500VDC | ||
Mechanical
| Color | Gray | Pitch | 2.54 mm |
| Weight | 8.800 lbs | Material | Polyester, Glass Filled |
| Packaging | Bulk | Wire Gauge | 26AWG(Solid),28AWG(Stranded) |
| Termination | IDC | Angle of Throw | Straight |
| Contact Finish | Gold | Mounting Style | PCB |
| Number of Rows | 2 | Contact Material | CopperAlloy |
| Housing Material | GlassFilledPolyester | Length - Overall | 2.97" |
| Primary Material | CardEdge | Pin Hole Diameter | 0.1" |
| Number of Contacts | 58 | Number of Positions | 50 |
| Material - Insulation | :Glass Filled Polyester | ||
Product Info
| Type | PCBSocket | Series | 3448 |
| Manufacturer | 3000Series | Product Type | Strain Reliefs |
| Accessory Type | Strain Relief | For Use With/Related Products | Pak 100, 3000 Series |
Environmental
| Temperature Rating | -55to+105°C | Operating Temperature | -55to+105°C |
Documents & Media
Archive
Archive
Online Document
Sourcing & traceability
- Datasheet
- 3448-58.igs
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
