200-6313-9UN-1900
| Category |
对参数有疑问？问 AI 助手
Business
| Product | PGA Sockets | Part # Aliases | 05113869654 JE150901278 |
| Product Category | IC & Component Sockets | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85369010 |
| RoHS Compliance | Yes | Material Flammability Rating | :UL94V-0 |
Electrical
| Connector - Voltage Input | :PGA | ||
Mechanical
| Pitch | 0.100" (2.54mm) | Width | :36.8mm |
| Length | :10.2mm | Weight | 1 lb |
| Lead Spacing | :2.54mm | Mounting Type | Through Hole |
| Connector Type | :PGA | Contact Finish | Gold |
| Mounting Style | Press Fit | Package / Case | :13x13 |
| Contact Material | :Beryllium Copper | Number of Contacts | :169 |
| Contact Termination | :Surface Mount Vertical | Contact Finish Thickness | 30µin (0.76µm) |
| 1st Connector Mounting Type | :PC Board | Number of Positions or Pins (Grid) | 169 (13 x 13) |
Product Info
| Type | Kit | Series | :- |
| Features | Closed Frame, Without Contacts | RF Family/Standard | 200 |
Environmental
| Operating Temperature | - 55 C to + 150 C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 5696.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
