Electrical
| Memory | 128（程序存储器）kB、14（数据存储器）kB | Fall Time | 0.08（二进制）μs、0.1（字操作）μs、1.2（浮点）μs |
| Input Type | Digital | EEPROM Size | 128 kB |
| Memory Size | 128 (Program Memory) kB, 14 (Data Memory) kB | Output Type | Digital |
| Response Time | 0.08 (Binary) μs, 0.1 (Word Operations) μs, 1.2 (Floating Point) μs | Voltage Rating | 24 V dc |
| Current - Output | 0.5 A | Number of Inputs | 328 (Digital) |
| Number of Outputs | 246 (Digital) | Program Memory Size | 128 kB |
| Current Rating (Max) | 0.5 A | ||
Mechanical
| Depth | 148mm | Width | 82mm |
| Length | 74mm | Contact Type | Ethernet, RJ45, RS485 |
| Mounting Type | DIN Rail, Panel Mount | Connector Type | 以太网、RJ45、RS485 |
| Package / Case | 是 | Size / Dimension | 74 x 82 x 148 mm |
Product Info
| Series | AC500-eC0 | Language | ANSI-C、C |
| Programmable | ANSI-C, C | Tape Included | Yes |
| Adapter Series | AC500-eC0 | Number of Ports | 3 |
| Network Technology | Ethernet | Channels per Circuit | 560 (Digital) |
| Other Specifications | Yes | Battery Type, Function | 是 |
| For Use With/Related Products | AC500-eCo Series | ||
