ABLS2-8.000MHZ-D4Y-T
| Category |
对参数有疑问?问 AI 助手
Business
| Lead Time | 23 Days | Other Names | 535-9864-1 |
| Subcategory | Crystals | Product Category | Crystals |
| Standard Package | Tape & Reel | ||
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85416000 |
Electrical
| Core Type | :HC-49/US | Frequency | 8MHz |
| Tolerance | 30 PPM | Operating Mode | Fundamental |
| Oscillator Type | Fundamental | Load Capacitance | 18 pF |
| Frequency Stability | ±30ppm | Frequency Tolerance | ±30 ppm |
| Resistance - Series | 80 Ohm | Frequency - Operating | 8 MHz |
| ESR (Equivalent Series Resistance) | 80 Ohm | Common Mode Transient Immunity (Min) | Industrial |
Mechanical
| Depth | 4.7 mm | Height | 0.130" (3.30mm) |
| Weight | 0 | Packaging | Tape and Reel |
| Mounting Type | Surface Mount | Mounting Style | SMD/SMT |
| Number of Pins | :2 | Package / Case | 2HC-49/US |
| Length - Overall | 11.4 mm | Size / Dimension | 0.449" L x 0.185" W (11.40mm x 4.70mm) |
| Termination Style | SMD/SMT | 1st Connector Mounting Type | :SMD |
Product Info
| Type | Crystal | Series | ABLS2 |
Environmental
| Operating Temperature | 85 °C | ||
Documents & Media
PDF Document
PDF Document
Online Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- Datasheets
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
