D38999/26FF18PN
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| RoHS | No | MIL Type | MIL-DTL-38999 III |
| Tariff No | 85369010 | Approval Agency | :MIL-DTL-38999 Series III |
Electrical
| Insertion Loss | Normal | Voltage Rating | 400VAC, 550VDC |
| Current Rating (Max) | 5A & Twinax | Voltage - Supply (Min) | 1300 |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Shielding | Yes | Shell Size | 19 |
| Wire Gauge | 28,26,24,22,Twinax | Orientation | N (Normal) |
| Shell Style | In-Line | Termination | Crimp |
| Contact Size | 14#22D,4#8(Twinax) | Contact Type | pin contacts |
| Housing Color | Silver | Mounting Type | Straight |
| Shell Plating | Electroless Nickel | Connector Type | MIL-DTL-38999 Series III Connector |
| Contact Finish | Gold | Fastening Type | Threaded |
| Mounting Style | Wire | Shell Material | Aluminum |
| Connector Style | Plug | Insert Material | Hard Dielectric |
| Insertion Angle | 19-18 | Material - Body | :Aluminium |
| Shell Size, MIL | F | Contact Material | Copper Alloy |
| Termination Style | Crimp | 1st Contact Gender | Pin (Male) |
| Mating Orientation | Self Locking | Number of Contacts | 18 |
| Contact Termination | :Crimp | Number of Positions | 18 |
| Shell Size - Insert | 19-18 | Bushing, Grommet Type | Silicone |
| Shell Material, Finish | Aluminum, Nickel Plated, Electroless | Contact Finish Thickness | 50µin (1.27µm) |
| 1st Connector Mounting Type | :Cable | ||
Product Info
| Gender | :Plug | Series | TV |
| Features | Shielded | Product Type | Plugs |
| Service Class | electroless nickel plated aluminum, EMI -65dB @ 10GHz, 48 hour salt spray, 200°C | Specifications | MIL-DTL-38999 |
Environmental
| Ratings | M | Mechanical Life | 500 |
| Ingress Protection | Environment Resistant | Operating Temperature | 200°C |
