Business
| Product | Connectors | Other Names | ACX1100 |
| Part # Aliases | 319-0085 | Product Category | RF Connectors / Coaxial Connectors |
| Standard Package | Bag | ||
Compliance
| RoHS | Lead free / RoHS Compliant | EU RoHS | Compliant |
Electrical
| Frequency | 0 to 11 GHz | Impedance | 50 Ohm |
| Voltage Rating | 500V | Coupling Factor | Threaded |
| Frequency - Max | 11GHz | ||
Mechanical
| Depth | 17.5 | Height | 17.5 |
| Weight | 0.569322 oz | Packaging | Bulk |
| Cable Type | RG-178, RG-196 | Body Finish | Nickel |
| Cable Group | RG-178, 196 | Orientation | Straight |
| Termination | Crimp | Body Material | Brass |
| Housing Color | Silver | Mounting Type | Panel Mount |
| Angle of Throw | Straight | Connector Type | Jack, Female Socket |
| Contact Finish | Gold | Fastening Type | Threaded |
| Housing Finish | Nickel | Plating - Body | Nickel |
| Connector Style | TNC | Connector Usage | Threaded |
| Contact Material | Brass | Housing Material | Brass |
| Length - Overall | 27.2 | Primary Material | TNC |
| Termination Style | Cable - Crimp | Shield Termination | Crimp |
| Contact Termination | Crimp | Dielectric Material | Polyoxymethylene (POM) Acetal |
| Insulation Material | Delrin | Center Contact Plating | Gold |
| Center Contact Material | Brass | ||
Product Info
| Type | TNC | Gender | RCP |
| Features | Captivated Contact | Polarity | Standard |
| Manufacturer | TNC Series | Connection Type | Coaxial Cable |
| RF Family/Standard | TNC | Application Specifics | Commercial |
Environmental
| Mating Cycles | 500 | Ingress Protection | Weatherproof |
| Operating Temperature | - 40 C to + 155 C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 122370_customer_drawing.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
