Business
| Product | Connectors | Other Names | ACX1421 |
| Product Category | RF Connectors / Coaxial Connectors | Standard Package | Bag |
Compliance
| RoHS | Lead free / RoHS Compliant | Tariff No | 85366910 |
Electrical
| Frequency | 0 to 12.4 GHz | Impedance | 50 Ohm |
| Voltage Rating | 375V | Coupling Factor | Threaded |
| Frequency - Max | 12.4GHz | ||
Mechanical
| Weight | 0 | Packaging | Bulk |
| Cable Type | RG-174, RG-188A, RG-316, Belden 7805A | Body Finish | Gold |
| Cable Group | RG-174, 316, LMR-100 | Orientation | Straight |
| Termination | Crimp | Body Material | Brass |
| Housing Color | Gold | Mounting Type | Panel Mount |
| Angle of Throw | Straight | Connector Type | Jack, Female Socket |
| Contact Finish | Gold | Fastening Type | Threaded |
| Housing Finish | Gold | Connector Style | SMA |
| Connector Usage | Threaded | Contact Material | Beryllium Copper |
| Housing Material | Brass | Primary Material | SMA |
| Termination Style | Cable - Crimp | Shield Termination | Crimp |
| Contact Termination | Solder | Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Center Contact Plating | Gold | Center Contact Material | Beryllium Copper |
| Supplier Device Package | :Straight Bulkhead Jack | 1st Connector Mounting Type | :Cable |
Product Info
| Type | SMA | Gender | RCP |
| Series | :- | Polarity | Standard |
| Connection Type | Flexible Cable | RF Family/Standard | SMA |
| Application Specifics | Commercial | ||
Environmental
| Mating Cycles | 500 | Ingress Protection | Weatherproof |
| Operating Temperature | -65°C ~ 165°C | ||
Documents & Media
PDF Document
PDF Document
PDF Document
PDF Document
Sourcing & traceability
- Datasheet
- 132284_customer_drawing.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
