98464-F61-18ULF

Manufacturer	Amphenol Corporation
Description	18 Positions Header, Shrouded Connector 0.079" (2.00mm) Through Hole, Right Angle Gold

对参数有疑问？问 AI 助手

Specifications

Mfr	Amphenol ICC (FCI)	Style	Board to Board or Cable
Series	Minitek® 2.00mm	Features	Keying Slot
Packaging	Tube	Shrouding	Shrouded - 4 Wall
Part Status	Active	Termination	Solder
Applications	-	Contact Type	Male Pin
Contact Shape	Square	Mounting Type	Through Hole, Right Angle
Connector Type	Header	Fastening Type	Latch Holder
Number of Rows	2	Pitch - Mating	0.079" (2.00mm)
Voltage Rating	200V (AC/DC)	Contact Material	Copper Alloy
Insulation Color	Cream	Insulation Height	0.240" (6.10mm)
Ingress Protection	-	Base Product Number	98464
Insulation Material	Thermoplastic	Number of Positions	18
Row Spacing - Mating	0.079" (2.00mm)	Contact Finish - Post	Tin
Contact Length - Post	0.098" (2.50mm)	Current Rating (Amps)	2A (AC/DC)
Operating Temperature	-	Mated Stacking Heights	-
Overall Contact Length	-	Contact Finish - Mating	Gold
Contact Length - Mating	0.157" (4.00mm)	Number of Positions Loaded	All
Material Flammability Rating	UL94 V-0	Contact Finish Thickness - Post	78.7µin (2.00µm)
Contact Finish Thickness - Mating	Flash
