PT02E12-3P(025)
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | 1 | ||
Compliance
| Tariff No | 85366930 | Approval Agency | :MIL-C-26482 Series I |
Electrical
| Voltage Rating | 1000VAC | Current Rating (Max) | 13A |
Mechanical
| Weight | 0.001 | Packaging | Bulk |
| Orientation | N (Normal) | Termination | Solder Cup |
| Weight (g): | 10.33700 | Mounting Type | Panel Mount, Flange |
| Connector Type | Receptacle, Male Pins | Contact Finish | Gold |
| Fastening Type | Bayonet Lock | Insertion Angle | :12-3 |
| Material - Body | :Aluminium | Contact Material | :Copper |
| 1st Contact Gender | :Pin | Number of Contacts | :3 |
| Contact Termination | :Solder | Number of Positions | 3 |
| Shell Size - Insert | 12-3 | Shell Material, Finish | Aluminum, Black Zinc Cobalt Plated |
| 1st Connector Mounting Type | :Panel | ||
Product Info
| Gender | :Socket | Series | :PT |
Environmental
| Ingress Protection | Environment Resistant | Operating Temperature | -55°C ~ 125°C |
Documents & Media
PDF Document
.JPG&w=3840&q=75)
Sourcing & traceability
- Datasheet
- MIL-C-26482, Series 1
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
