97-3102A-20-29S(946)
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 973102A2029S946 | Product Category | Circular MIL Spec Connector |
| Standard Package | 1 | ||
Compliance
| RoHS | Lead free / RoHS Compliant | MIL Type | MIL-DTL-5015 |
| Approval Agency Marking | UL Recognized/CSA | ||
Electrical
| Voltage Rating | 500VAC, 700VDC | Current Rating (Max) | 13A |
Mechanical
| Packaging | Bulk | Cable Exit | Solid |
| Shell Size | 20 | Wire Gauge | 16-22 |
| Orientation | N (Normal) | Shell Style | box mount receptable |
| Termination | Solder Cup | Contact Type | socket contacts |
| Mounting Type | Panel Mount, Flange | Shell Plating | Black Zinc Alloy |
| Angle of Throw | Straight | Connector Type | Amphenol 97 Series - Standard Cylindrical Connector - solder type |
| Contact Finish | special variation code | Fastening Type | Threaded |
| Housing Finish | Olive Drab Cadmium | Mounting Style | Panel |
| Package / Case | Metal | Shell Material | solid backshell |
| Connector Usage | Threaded | Insertion Angle | 20-2 |
| Housing Material | Aluminum Alloy | Primary Material | 5015 Commercial |
| Termination Style | Solder | 1st Contact Gender | Socket (Female) |
| Number of Contacts | 1 | Dielectric Material | Diallyl-Phthalate |
| Number of Positions | 17 | Shell Size - Insert | 20-29 |
| Mounting Hole Diameter | 0.12 " | Shell Material, Finish | Aluminum, Zinc Plated, Black |
| Contact Layout, Typical | 17#16 | ||
Product Info
| Type | Panel Socket | Class | A |
| Series | 97 | Features | Environmental Resistant, Single Key/Keyway Shell Polarization |
| Manufacturer | 97 Series | Product Type | Receptacles |
| Insert Configuration | 20-29 | Application Specifics | Commercial |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
.jpg&w=3840&q=75)
Sourcing & traceability
- Datasheet
- 97-3102A_ht.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
