97-3106A-18-1P(946)
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 973106A181P946 | Product Category | Circular MIL Spec Connector |
| Standard Package | 1 | ||
Compliance
| RoHS | Compliant | MIL Type | MIL-DTL-5015 |
| Approval Agency Marking | UL Recognized/CSA | ||
Electrical
| Voltage Rating | 700 V, 250 V | Current Rating (Max) | 13A |
Mechanical
| Packaging | Bulk | Cable Exit | Solid |
| Shell Size | 18 | Wire Gauge | 22-16 |
| Orientation | N (Normal) | Shell Style | In-Line |
| Termination | Solder Cup | Contact Type | Pin |
| Mounting Type | Free Hanging (In-Line) | Shell Plating | Black Zinc Alloy |
| Angle of Throw | Straight | Connector Type | Plug, Male Pins |
| Contact Finish | Silver | Fastening Type | Threaded |
| Housing Finish | Olive Drab Cadmium | Mounting Style | Free Hanging |
| Package / Case | Metal | Shell Material | Aluminum Alloy |
| Connector Usage | Threaded | Insertion Angle | 18-1 |
| Housing Material | Aluminum Alloy | Primary Material | 5015 Commercial |
| Termination Style | Solder | 1st Contact Gender | Pin (Male) |
| Number of Contacts | 10 | Dielectric Material | Diallyl-Phthalate |
| Number of Positions | 10 | Shell Size - Insert | 18-1 |
| Shell Material, Finish | Aluminum, Zinc Plated, Black | Contact Layout, Typical | 4#16, 6#16 |
Product Info
| Type | Cable Plug | Class | A |
| Series | 97 | Features | Environmental Resistant, Single Key/Keyway Shell Polarization |
| Manufacturer | 97 Series | Product Type | Plugs |
| Application Specifics | Commercial | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
PDF Document
.jpg&w=3840&q=75)
Sourcing & traceability
- Datasheet
- 108266.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
