97-3106A-20-4P(946)
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Circular MIL Spec Connector | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | MIL Type | MIL-DTL-5015 |
Electrical
| Voltage Rating | 900VAC, 1250VDC | Current Rating (Max) | 23 A |
Mechanical
| Packaging | Bulk | Shell Size | 20 |
| Orientation | N (Normal) | Shell Style | Potting |
| Termination | Solder Cup | Mounting Type | Straight |
| Shell Plating | Olive Drab Chromate over Cadmium | Connector Type | Plug, Male Pins |
| Contact Finish | Silver | Fastening Type | Threaded |
| Mounting Style | Wire | Shell Material | Aluminum Alloy |
| Insertion Angle | 20-4 | Contact Material | Copper Alloy |
| Termination Style | Solder | 1st Contact Gender | Pin (Male) |
| Mating Orientation | Threaded | Number of Contacts | 4 |
| Number of Positions | 4 | Shell Size - Insert | 20-4 |
| Shell Material, Finish | Aluminum, Zinc Plated, Black | ||
Product Info
| Series | 97 | Product Type | Plugs |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
.jpg&w=3840&q=75)
.jpg&w=3840&q=75)
Sourcing & traceability
- Datasheet
- 10-820060@079_F_hto.PDF
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
