97-3106A-24-7S(946)
| Category |
对参数有疑问？问 AI 助手
Business
| Product Category | Circular MIL Spec Connector | Standard Package | 1 |
Compliance
| RoHS | RoHS Compliant | MIL Type | MIL-DTL-5015 |
| Approval Agency Marking | UL Recognized/CSA | ||
Electrical
| Voltage Rating | 500VAC, 700VDC | Current Rating (Max) | 23 A to 13 A |
Mechanical
| Packaging | Bulk | Cable Exit | Solid |
| Shell Size | 24 | Wire Gauge | 12, 16 |
| Orientation | N (Normal) | Shell Style | Potting |
| Termination | Solder Cup | Contact Type | Socket |
| Mounting Type | Straight | Shell Plating | Olive Drab Chromate over Cadmium |
| Angle of Throw | Straight | Connector Type | Plug, Female Sockets |
| Contact Finish | Silver | Fastening Type | Threaded |
| Housing Finish | Olive Drab Cadmium | Mounting Style | Wire |
| Package / Case | Metal | Shell Material | Aluminum Alloy |
| Connector Usage | Threaded | Insertion Angle | 24-7 |
| Contact Material | Copper Alloy | Housing Material | Aluminum Alloy |
| Primary Material | 5015 Commercial | Termination Style | Solder |
| 1st Contact Gender | Socket (Female) | Mating Orientation | Threaded |
| Number of Contacts | 16 | Dielectric Material | Diallyl-Phthalate |
| Number of Positions | 16 | Shell Size - Insert | 24-7 |
| Shell Material, Finish | Aluminum, Zinc Plated, Black | Contact Layout, Typical | 2#12, 14#16 |
Product Info
| Type | Cable Plug | Class | A |
| Series | 97 | Features | Environmental Resistant, Single Key/Keyway Shell Polarization |
| Manufacturer | 97 Series | Product Type | Plugs |
| Application Specifics | Commercial | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
.jpg&w=3840&q=75)
Sourcing & traceability
- Datasheet
- 10-820060@079_F_hto.PDF
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
