97-3101A-16S-8P
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 973101A16S8P | Product Category | Circular MIL Spec Connector |
| Standard Package | Bulk | ||
Compliance
| RoHS | No | MIL Type | MIL-DTL-5015 |
| Approval Agency Marking | UL/CSA | ||
Electrical
| Voltage Rating | 700 V | Current Rating (Max) | 13 A |
Mechanical
| Packaging | Bulk | Cable Exit | Solid |
| Shell Size | 16 | Wire Gauge | 16-22 |
| Orientation | N (Normal) | Shell Style | In-Line |
| Termination | Solder | Contact Type | Pin |
| Mounting Type | Cable Mount | Shell Plating | Olive Drab Chromate over Cadmium |
| Angle of Throw | Straight | Connector Type | Receptacle, Male Pins |
| Contact Finish | Silver | Fastening Type | Threaded |
| Housing Finish | Olive Drab Cadmium | Mounting Style | Cable |
| Package / Case | Metal | Shell Material | Aluminum Alloy |
| Connector Usage | Threaded | Insertion Angle | 16S-8 |
| Housing Material | Aluminum Alloy | Primary Material | 5015 Commercial |
| Termination Style | Solder | 1st Contact Gender | Pin (Male) |
| Number of Contacts | 5 | Dielectric Material | Diallyl-Phthalate |
| Number of Positions | 5 | Shell Size - Insert | 16S-8 |
| Mounting Hole Diameter | 0.12 " | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Layout, Typical | 5#16 | ||
Product Info
| Type | MIL-C-5015 Circular | Class | A |
| Gender | RCP | Series | 97 |
| Manufacturer | 97 Series | Product Type | Receptacles |
| Application Specifics | Commercial | ||
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 97-3100A_ht.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
