97-3102A-10SL-4P

Name: 97-3102A-10SL-4P
SKU: 97-3102A-10SL-4P

Business

Product Category

Circular MIL Spec Connector

Standard Package

Bulk

RoHS	Contains lead / RoHS non-compliant	EU RoHS	Not Compliant
MIL Type	MIL-DTL-5015	Tariff No	85366910
Rad Hardened	No	Approval Agency Marking	UL/CSA

Voltage Rating

500VAC, 700VDC

Current Rating (Max)

13A

Depth	25.4 mm	Height	25.4 mm
Weight	0.009	Packaging	Bulk
Cable Exit	No	Shell Size	10
Wire Gauge	16-22	Orientation	N (Normal)
Shell Style	Box Mount	Termination	Solder
Contact Form	2Signal	Contact Type	2Signal
Mounting Type	Box Mount	Shell Plating	Cadmium
Angle of Throw	Straight	Connector Type	Receptacle, Male Pins
Contact Finish	Silver	Fastening Type	Threaded
Housing Finish	Olive Drab Cadmium	Mounting Style	Panel
Package / Case	Metal	Shell Material	Aluminum Alloy
Connector Usage	Threaded	Insertion Angle	10SL-4
Material - Body	:Aluminium Alloy	Housing Material	Aluminum Alloy
Length - Overall	24.21 mm	Primary Material	5015 Commercial
Termination Style	Solder	1st Contact Gender	PIN
Number of Contacts	2	Dielectric Material	Diallyl-Phthalate
Number of Positions	2	Shell Size - Insert	10SL-4
Mounting Hole Diameter	0.12 "	Shell Material, Finish	Aluminum, Olive Drab Cadmium Plated
Contact Layout, Typical	2#16	1st Connector Mounting Type	:Box
Shell Size - Insert (Convert To)	10SL-4
