97-3106A-14S-2P
| Category |
对参数有疑问？问 AI 助手
Business
| Standard Package | Bulk | ||
Compliance
| RoHS | Contains lead / RoHS non-compliant | Tariff No | 85369010 |
| Approval Agency Marking | UL/CSA | ||
Electrical
| Voltage Rating | 200VAC, 250VDC | Current Rating (Max) | 13A |
Mechanical
| Weight | 13.61 | Packaging | Bulk |
| Cable Exit | Solid | Shell Size | 14S |
| Wire Gauge | 16 | Orientation | N (Normal) |
| Shell Style | straight plug | Termination | Solder |
| Contact Type | pin contacts | Mounting Type | Cable Mount |
| Angle of Throw | Straight | Connector Type | Amphenol 97 Series - Standard Cylindrical Connector - solder type |
| Contact Finish | Silver | Fastening Type | Threaded |
| Housing Finish | Olive Drab Cadmium | Package / Case | Metal |
| Shell Material | solid backshell | Connector Usage | Threaded |
| Insertion Angle | 14S-2 | Material - Body | :Aluminium |
| Contact Material | :Copper | Housing Material | Aluminum Alloy |
| Primary Material | 5015 Commercial | 1st Contact Gender | :Pin |
| Number of Contacts | :4 | Contact Termination | :Solder |
| Dielectric Material | Diallyl-Phthalate | Number of Positions | 4 |
| Shell Size - Insert | 14S-2 | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Layout, Typical | 4#16 | 1st Connector Mounting Type | :Cable |
Product Info
| Type | MIL-C-5015 Circular | Class | A |
| Gender | PL | Series | :97 |
| Manufacturer | 97 Series | Application Specifics | Commercial |
Environmental
| Operating Temperature | -55°C ~ 125°C | ||
Documents & Media
PDF Document
Sourcing & traceability
- Datasheet
- 12-022.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
