97-4100A-28-12S
| Category |
对参数有疑问？问 AI 助手
Business
| Other Names | 974100A2812S | Part # Aliases | U10-824014-12S |
| Product Category | Circular MIL Spec Connector | Standard Package | Bulk |
Compliance
| RoHS | Lead free / RoHS non-compliant | MIL Type | MIL-DTL-5015 |
| Approval Agency Marking | UL/CSA | Material Flammability Rating | UL94-V0 |
Electrical
| Voltage Rating | 700 V | Current Rating (Max) | 13 A |
Mechanical
| Packaging | Bulk | Cable Exit | Solid |
| Shell Size | 28 | Wire Gauge | 16-22 |
| Orientation | N (Normal) | Shell Style | Wall Mount |
| Termination | Crimp | Contact Size | 16 |
| Contact Type | Crimp | Mounting Type | Wall Mount |
| Shell Plating | Chromate over Cadmium, Olive Drab | Angle of Throw | Straight |
| Connector Type | Insert Shell, Receptacle | Contact Finish | Silver |
| Fastening Type | Threaded | Housing Finish | Clear Cadmium |
| Mounting Style | Panel | Package / Case | Metal |
| Shell Material | Aluminum Alloy | Connector Usage | Threaded |
| Insertion Angle | 28-12 | Housing Material | Aluminum Alloy |
| Primary Material | 5015 Commercial | Termination Style | Crimp |
| 1st Contact Gender | Socket (Female) | Number of Contacts | 26 |
| Number of Positions | 26 | Shell Size - Insert | 28-12 |
| Mounting Hole Diameter | 0.147 " | Shell Material, Finish | Aluminum, Olive Drab Cadmium Plated |
| Contact Layout, Typical | 26#16 | ||
Product Info
| Note | Contacts Not Provided | Type | MIL-C-5015 Circular |
| Class | A | Gender | RCP |
| Series | 97 | Features | Rear Release |
| Manufacturer | 97 Series | Product Type | Receptacles |
| Application Specifics | Commercial | ||
Documents & Media
PDF Document
.JPG&w=3840&q=75)
Sourcing & traceability
- Datasheet
- 97-4100A_ht.pdf
Lot-level traceability (date code, original factory packaging) is confirmed on every quote and shipment.
